Bellows seals are split into two top-level families, metal bellows and elastomer bellows, and within the metal family the engineering choice comes down to edge-welded versus formed construction [S3]. The metal-bellows subclass is widely specified for hot hydrocarbons, refinery charge stock, cryogenic LNG, and high-temperature boiler feedwater because the bellows itself replaces the dynamic secondary seal of a pusher-type design [S5][S6].
Operating envelope is the discriminator: edge-welded metal bellows cover roughly 800°F (425°C) down to −350°F (−212°C) when built from corrosion-resistant alloys, while formed (cold-formed, hydroformed, electroformed) constructions historically run narrower mechanical-strength and temperature limits [S3]. This article maps the principal classifications, the form-factor options (single, double, tandem, component), the materials that show up in real bid lists, and the failure modes a process engineer should price in.
Primary Classification: Metal vs Elastomer Bellows
Mechanical seals are grouped into pusher and non-pusher designs, and the bellows seal sits in the non-pusher column because the bellows element provides axial spring force and face loading without sliding on the shaft [S5]. The mechanical-seal taxonomy lists three main categories: O-ring (pusher), elastomer bellows (non-pusher), and metal bellows (non-pusher) [S5]. The defining engineering difference from a pusher seal is the secondary seal: metal bellows seals remove the semi-dynamic sliding elastomer that drives hang-up and shaft/sleeve fretting in conventional pusher designs [S2].
Elastomer bellows are the lower-cost option for water, light chemicals, and general-service pumps where temperatures stay inside the elastomer rating (commonly under 250°F / 121°C for FKM or EPDM, with specialty elastomers going higher). Metal bellows take over when temperature, chemical compatibility, or solids exposure rules elastomers out, and they are a staple of API 682 pump seal chambers in refinery and petrochemical service [S6][S7]. For the full taxonomy across all mechanical seal types, the mechanical seal reference lays out pusher, bellows, and cartridge categories side by side.
Secondary Classification: Edge-Welded vs Formed Metal Bellows
Inside the metal-bellows family the build process splits the field in two: edge-welded metal bellows and formed metal bellows [S3]. Edge-welded bellows are produced by stamping individual diaphragms, microscopically welding them at the inner diameter to form two-piece convolutions, and then welding those convolutions together at the outer diameter to build a stack [S3]. The result is a robust, leak-tight core used across aerospace, oil and gas, semiconductor, and medical service [S3].
Formed bellows split into cold-formed, hydroformed, and electroformed variants. Cold-formed and hydroformed types are typically made from welded or seamless tubing using heavy automation, while electroformed bellows are built by plating metal onto an aluminum mandrel [S3]. Manufacturing automation cuts cost, but historically the mechanical strength and temperature ceiling of formed bellows are narrower than edge-welded designs, which excludes them from heavy oil-and-gas, cryogenic, and power-generation duty [S3]. Operating-temperature spread is the headline metric: edge-welded metal bellows span roughly 800°F (425°C) down to −350°F (−212°C) when built from corrosion-resistant alloys and specialty metals [S3].
Form Factor: Single, Double, Tandem, Component
Form factor is the second decision axis and it is largely driven by process safety and emissions requirements. A single bellows seal uses one set of faces and is the value-engineered default for general service. Cartridge single designs such as the AESSEAL BSIV and BQFD lines are built for drop-in installation, with the BQFD adding a quench/flush/drain feature set [S2].
Double and tandem arrangements add a second set of faces with a barrier fluid between them. The AESSEAL BDFI (Bellows Double Flow Induction) and BDFC (Bellows Double Flow Convection) are hybrid designs pairing the inboard BQFD geometry with an outboard DMSF-style cartridge for improved heat removal [S2]. The BDTP (Bellows Double Tandem Pumping) configuration uses a directed barrier-fluid flow path to optimize heat removal at both seal-face sets, which is the typical API 682 Plan 53/54 hardware pattern [S2]. For services that must avoid any elastomer at the primary seal, the BSFG (Bellows Single Full Graphite) cartridge uses graphite rings at every primary sealing surface [S2]. Component seals, the BSAI and BSAIG range, ship as parts rather than cartridges and are available with self-aligning, DIN, CURC, T, L-shaped, or boot-mounted stationaries [S2].
Materials of Construction and Convolution Geometry
Alloy selection is where most field failures start, and 300-series stainless, Alloy 20, and Alloy 276 (Hastelloy C-276) are the three names that show up most often on real nameplates. AESSEAL publishes Alloy 276 as its standard bellows material, citing higher mechanical strength and corrosion resistance than 300-series stainless or Alloy 20 [S2][S4]. Higher-grade options such as titanium, Alloy 718, and other nickel-based superalloys are available for sour service, seawater, and acidic chloride streams where NACE MR0175 compliance is required.
Convolution count drives spring rate and fatigue life. AESSEAL uses 12 convolutions in its standard stack against an industry baseline of 8, a 50% increase that lowers per-convolution stress and is credited with longer seal life in OEM literature [S2][S4]. Fewer, thicker convolutions give a stiffer spring and longer axial travel; more, thinner convolutions reduce stress per cycle but compress the allowable axial deflection window. Matching convolution count to the pump's axial movement and pressure-driven face load is the mechanical design step most often skipped on retrofits.
Selection Criteria vs Other Mechanical Seal Types
Bellows seals are the right call when the process combines high temperature, high pressure, tight axial tolerances, or a fluid that attacks elastomers. Against cartridge pusher seals, bellows designs win on the absence of a sliding secondary seal, which removes hang-up and shaft fretting [S2][S6]. Against gas seals and dual unidirectional dry-gas seals, bellows seals are usually lower cost and simpler to install but cannot match dry-gas sealing on fugitive-emissions control or on services with very low leak tolerances such as volatile organic compounds (VOC) and light hydrocarbons.
They are not the right call when the fluid carries heavy abrasives or large solids (the convolution edges collect debris), when budget rules out cartridge hardware, or when the seal chamber is too short to accept the bellows stack axial travel. Cartridge pusher seals remain the economic default for clean, cool water and light chemical service; bellows designs step in when the operating envelope forces a non-pusher geometry [S6].
Failure Modes and Engineering Constraints
The three failure modes that dominate field service are fatigue cracking of the bellows, corrosion-driven pitting or stress-corrosion cracking, and solid-particle fouling between convolutions. Edge-welded designs are more resistant to fatigue cycling than formed designs because the welded grain structure handles higher stress amplitudes, which is why edge-welded is the refinery and cryogenic default [S3]. Corrosion resistance moves with alloy: Alloy 276 covers most refinery and chemical streams, while 300-series stainless is restricted to milder aqueous service.
Solid handling is a hard limit, not a soft one. Once a process carries sand, scale, or polymer particles, those materials pack into the convolution gaps and either lock the bellows or score the faces. For those services, hard-face or flushing plans plus a non-bellows geometry usually beat forcing a bellows seal into a slurry. Operating limits worth pinning on the data sheet at the quote stage: temperature ceiling, pressure rating, pH range, maximum solids size and concentration, maximum allowable axial movement, and ATEX/IECEx zone classification for hazardous-area service.
Use Cases and Standards Anchors
Real use cases line up with the classification: edge-welded Alloy 276 single cartridge seals on refinery hot-oil and boiler-feedwater pumps, double tandem bellows with API 682 Plan 53B barrier fluid on light-hydrocarbon and VOC services, full-graphite bellows where elastomers are excluded by chemistry, and cryogenic edge-welded designs in LNG and ethylene service down toward −212°C [S2][S3]. Equipment builders such as AESSEAL, John Crane, and Flowserve publish product lines that map directly onto this taxonomy, with model families named by configuration (single, double, tandem, component) and material [S1][S2][S8].
For specification discipline, two anchors carry the most weight: API 682 (shaft seals for centrifugal and rotary pumps), which defines the Plan arrangements and qualification testing that double and tandem bellows seals are built to, and ASME B73.1 / B73.2 for the pump dimensional envelope that the seal cartridge must fit. Hazardous-area classification under ATEX 2014/34/EU or IECEx, and material compliance to NACE MR0175 for sour H₂S service, are the next items to pin on the data sheet. A practical deeper cut on the temperature decision is in the Metal Bellows vs Elastomer Bellows Decision Map, which lines up the same two families against real operating envelopes.
Trackable signals for the next buying cycle: follow API 682 updates for any new Plan arrangements specific to metal bellows hardware, watch for expanded cryogenic certification on edge-welded designs from the major OEMs, and monitor Alloy 276 and superalloy price movement as a direct input into seal-spec cost.
