The category covers bench, modular, and field instruments used to develop, validate, and repair electronic hardware. Analog Technologies (S1) and Analog Devices (S3) both describe test and measurement as the discipline of quantifying electrical signals with calibrated hardware and signal chain components. SIGLENT (S2), Honeytek (S4), and Tektronix (S5) organize their catalogs around the same core families: oscilloscopes, multimeters, signal sources, spectrum analyzers, and supporting accessories.
Selection spans from entry level handheld meters rated for field troubleshooting to broadband laboratory oscilloscopes with multi gigahertz analog bandwidth and gigasample per second real time sampling. Mouser (S6) traces the lineage of the benchtop oscilloscope to Karl Ferdinand Braun's 1897 cathode ray tube design and notes the centrality of reliable power sources in measurement setups. The remainder of this page details working principles, key specifications, instrument types, procurement criteria, applicable standards, and the vendor landscape.
Electronic test and measurement encompasses the instruments, methods, and supporting software used to characterize voltage, current, frequency, impedance, and signal integrity in electronic circuits. Modern product lines span digital oscilloscopes, spectrum and vector network analyzers, digital multimeters, source measure units, waveform generators, and electronic loads. Procurement decisions balance bandwidth, sampling rate, accuracy, channel count, and lifecycle services such as calibration and warranty.
Chapter 1 / 06
Fundamentals and Working Principle
Test and measurement instruments convert physical electrical quantities into numerical readings through analog front ends, analog to digital converters, and digital signal processing. An oscilloscope, as catalogued by SIGLENT (S2) and Tektronix (S5), acquires voltage versus time through one or more input channels, samples the waveform, and reconstructs it for display and analysis. The 1897 Braun cathode ray tube oscilloscope referenced by Mouser (S6) established the time domain display concept still in use, although the storage and processing chain is now entirely digital.
Digital multimeters measure DC and AC voltage, current, and resistance by switching precision resistor networks and digitizing the resulting signal, with higher end units adding capacitance, frequency, and temperature. Honeytek (S4) lists digital multimeters, clamp meters, automotive multimeters, insulation testers, and capacitance multimeters under a single measurement family, demonstrating the shared signal conditioning architecture applied to multiple physical quantities. SIGLENT (S2) shows benchtop multimeters in the SDM series with display counts up to 600,000 on certain units, requiring correspondingly higher resolution analog to digital conversion.
Spectrum and vector network analyzers (S2, S5) operate in the frequency domain, separating input signals into spectral components through mixing with local oscillators and filtering. Arbitrary waveform generators synthesize complex stimulus signals through direct digital synthesis, while source measure units (SMU) and DC electronic loads (S2, S5) force or sink precise voltage and current to characterize devices under test. Signal chain components from vendors such as Analog Devices (S3) provide the amplifiers, converters, and reference circuits that determine the ultimate accuracy of any assembled instrument.
Calibration closes the loop between physical standards and instrument readout. SIGLENT (S2) lists calibration and certificate services alongside firmware and warranty support, and Tektronix (S5) maintains a dedicated calibration services portfolio with factory verified and multi brand compliant tiers, location directories, and service level options. Accuracy specifications across the category are only as trustworthy as the traceability chain supporting them.
Voltage, current, and resistance measurement through precision analog front ends
Time domain signal acquisition and reconstruction in digital storage oscilloscopes
Frequency domain analysis through mixing, filtering, and fast Fourier transforms in spectrum analyzers
Stimulus synthesis through direct digital synthesis in arbitrary waveform generators
Force and measure operation through source measure units and DC electronic loads
Calibration traceability through factory and multi brand compliant service tiers
Chapter 2 / 06
Specifications and Key Parameters
Oscilloscope specifications center on analog bandwidth, real time sampling rate, vertical resolution, record length, and waveform update rate. SIGLENT (S2) describes the SDS7000A series with bandwidth up to 8 GHz, 12 bit ADC resolution, real time sampling up to 20 GSa/s, record length up to 2 Gpts/ch, and a waveform capture rate up to 1,000,000 waveforms per second. These parameters govern the instrument's ability to resolve fast transients, long sequences, and rare events, and they are the primary axes along which bench oscilloscopes are compared.
Multimeter specifications emphasize display count, basic DC accuracy, ranging, and supported measurement functions. Honeytek (S4) describes multimeters with counts from 2,000 to 600,000 digits across its product range, while SIGLENT (S2) lists digital multimeter series including the SDM4065A, SDM4055A, SDM3065X, SDM3055, and SDM3045X. Tektronix (S5) groups digital multimeters with data acquisition and switching, low level instrumentation, and sensitive specialty instruments, reflecting the way accuracy and noise performance are specified at the high end.
Spectrum and vector network analyzer specifications cover frequency range, resolution bandwidth, phase noise, and analysis bandwidth. SIGLENT (S2) lists the SNA6000A and SNA5000A vector network analyzer series along with the SSA5000A, SSA3000X-R, SSA3000X, and SSA3000X Plus spectrum analyzer series, the SVA1000X combined unit, and the SHA860A and SHA850A handheld spectrum analyzers. Tektronix (S5) lists spectrum analyzers, parameter analyzers, optical modulation analyzers, and frequency counters as separate families under its analyzers group.
Source and load specifications address voltage range, current range, power envelope, accuracy, and transient response. SIGLENT (S2) lists the SMM3000X source measure unit series, SPS6000X, SPS5000X, SPD4000X, SPD3303X, SPD3303C, and SPD1000X DC source series, and the SDL1000X DC electronic load series. Tektronix (S5) covers source measure units, DC power supplies, DC electronic loads, DC bidirectional supplies, and battery test and simulation under its sources and supplies group. Signal generator specifications from SIGLENT (S2) include the SDG8000A, SDG7000A, SDG6000X, SDG3000X, SDG2000X, SDG1000X Plus, and SDG800 arbitrary waveform series, plus SSG6000A, SSG6082A-V, SSG5000A, SSG5000X, and SSG3000X RF generators, with Tektronix (S5) listing arbitrary function and arbitrary waveform generators separately.
SigScopeLab signal analysis, SigIQPro signal generation, SigVSA vector signal analysis supporting 5G NR/NR-A and 5G NR-NTN
varies by model
SigVSA listed
varies by model
Differential probe (example accessory)
SAP5000D 5 GHz high speed differential probe
varies by model
varies by model
varies by model
Chapter 3 / 06
Types and Configurations
The category divides naturally into time domain instruments, frequency domain instruments, stimulus sources, precision meters, and specialized test families. SIGLENT (S2) lists digital oscilloscopes, handheld oscilloscopes, vector network analyzers, spectrum analyzers, RF switch systems, waveform generators, RF generators, SMU and DC sources, DC electronic loads, and digital multimeters as primary product lines, with PC software and accessories as supporting categories. Tektronix (S5) groups oscilloscopes and probes, software, analyzers, signal generators, sources and supplies, meters, and additional products such as semiconductor test systems, reference solutions, and refurbished equipment.
Within oscilloscopes, form factors include benchtop, modular, and handheld. SIGLENT (S2) lists bench SDS series such as SDS7000A, SDS6000A, SDS6000L, SDS5000X HD, SDS5000L, SDS5000X, SDS3000X HD, SDS2000X HD, SDS2000X Plus, SDS1000X HD, SDS800X HD, SDS1000X-E, SDS1000X-U, SDS1000CML+, and SDS1000DL+, with handheld SHS1000X and SHS800X series. Obsolete product listings (S2) show legacy SDS2000X-E, SDS2000X, SDS1000X/X+, and SDS1000CFL series, indicating the depth of vendor product line management.
Multimeter configurations span handheld, clamp, automotive, and bench formats. Honeytek (S4) lists digital multimeters, clamp meters, automotive multimeters, insulation testers, clamp earth resistance testers, capacitance multimeters, voltage detectors, environmental testers, laser distance meters, infrared thermometers, and thermal imagers. This breadth illustrates how the same digital measurement core is repackaged for applications such as photovoltaic systems, automotive diagnostics, and environmental surveying.
Signal source configurations range from arbitrary waveform generators to dedicated RF generators and source measure units. SIGLENT (S2) separates the SDG series arbitrary waveform generators from the SSG series RF generators, and the SMM3000X source measure unit from the SPD and SPS DC source series. Tektronix (S5) similarly separates arbitrary function generators from arbitrary waveform generators, and groups source measure units with DC power supplies, DC electronic loads, DC bidirectional supplies, and battery test and simulation. Specialized families such as optical modulation analyzers, parameter analyzers, and frequency counters (S5) address niche measurement domains not covered by mainstream product lines.
Benchtop and handheld digital storage oscilloscopes across multiple series
Vector network analyzers and spectrum analyzers including handheld variants
Arbitrary waveform generators and RF signal generators
Source measure units, DC power supplies, DC electronic loads, and bidirectional supplies
Digital multimeters, clamp meters, automotive multimeters, and insulation testers
Specialized analyzers covering optical modulation, parameters, and frequency
Chapter 4 / 06
Selection Criteria for Procurement
The first procurement axis is the measurement domain. Time domain work favors oscilloscopes with sufficient analog bandwidth and sampling rate, exemplified by the SIGLENT SDS7000A bandwidth up to 8 GHz and real time sampling up to 20 GSa/s (S2). Frequency domain work shifts selection toward spectrum and vector network analyzers such as the SIGLENT SSA and SNA families (S2) or the Tektronix spectrum and parameter analyzer portfolios (S5). Precision DC work, device characterization, and battery testing map onto source measure units, DC electronic loads, and bidirectional supplies (S2, S5).
Accuracy and resolution come next. Honeytek (S4) describes its product range as covering 2,000 to 600,000 count digital multimeters, allowing procurement to match display count to required resolution. SIGLENT (S2) cites 12 bit ADC resolution in the SDS7000A series, and lists 5 GHz high speed differential probes such as the SAP5000D for high bandwidth probing. Tektronix (S5) extends the resolution conversation to low level and sensitive specialty instrumentation grouped under meters.
Software and analysis packages increasingly determine usable value. SIGLENT (S2) offers SigScopeLab for signal analysis, SigIQPro for signal generation, and SigVSA for vector signal analysis supporting 5G NR, NR-A, and NR-NTN. Tektronix (S5) groups bench software, data analysis, and test automation as separate categories, reflecting the centrality of automation in modern validation labs. RF switch systems such as the SIGLENT SSU5000A and SSM5000A (S2) further extend automated multi port measurement capability.
Lifecycle services are the final procurement axis. SIGLENT (S2) provides firmware and software downloads, warranty information, calibration and certificate services, an Orbital Care support program, and a defined return policy. Tektronix (S5) offers factory verified and multi brand compliant calibration, quality and accreditation documentation, calibration capabilities, locations, service levels, factory calibration status tracking, factory service plans, asset management through CalWeb, field service managed calibration, and dedicated repair and parts operations. Honeytek (S4) advertises OEM and ODM services, partner programs, downloads, video, and FAQ support for its installation base.
Match instrument family to measurement domain: time, frequency, stimulus, or precision DC
Confirm analog bandwidth, sampling rate, ADC resolution, and display count against the device under test
Evaluate analysis software, automation interfaces, and switch matrix integration
Verify RF and signal integrity analysis coverage such as 5G NR options (S2)
Compare calibration tiers, warranty, and return policy structures (S2, S5)
Assess OEM, ODM, and partner program availability for branded procurement (S4)
Chapter 5 / 06
Standards, Compliance, and Testing
Test and measurement vendors operate within accreditation frameworks that govern calibration traceability and service quality. Tektronix (S5) describes its calibration services as factory verified calibration and multi brand compliant calibration, supported by a quality and accreditation program, calibration capabilities documentation, multiple service locations, defined service levels, and factory calibration status tracking. These programs anchor instrument accuracy to national measurement standards through documented uncertainty budgets.
Application specific compliance testing is offered alongside instrument sales. Tektronix (S5) lists EMI and EMC testing, high speed serial communication, material science and engineering, power efficiency, RF testing, and test automation as distinct application areas, and groups 3D sensing and image characterization alongside them. Testing services (S5) include environmental testing, HALT and HASS, NEMA compliance testing, package testing, and shock and vibration testing, providing third party validation against industry specific standards.
Software and firmware compliance is treated as a controlled artifact. SIGLENT (S2) lists firmware and software, warranty information, calibration and certificate issuance, an Orbital Care support program, and a return policy under service and support, indicating that compliance evidence is delivered with each instrument. Tektronix (S5) provides software downloads and a TekAMS software license management system, which together support controlled distribution and license tracking across instrument fleets.
Solution and industry frameworks complete the compliance picture. Tektronix (S5) maps its portfolio to industries including advanced research, aerospace and defense, AI data center, automotive, education and teaching labs, medical devices and systems, power semiconductor, renewable energy, and semiconductor design and manufacturing, and groups product lines such as Keithley products and EA Elektro-Automatik products under the same compliance umbrella. SIGLENT (S2) groups its products under solutions alongside service and support, resources, and authorized partner programs, ensuring that compliance engagement spans the full instrument lifecycle.
Factory verified and multi brand compliant calibration programs (S5)
Quality and accreditation documentation for calibration traceability (S5)
EMI/EMC, RF, high speed serial, and power efficiency compliance testing (S5)
Environmental, HALT/HASS, NEMA, package, and shock-vibration testing services (S5)
Firmware, software license, and certificate management with each instrument (S2, S5)
Industry specific solution frameworks covering aerospace, automotive, medical, and semiconductor (S5)
Chapter 6 / 06
Market Landscape and Buying Process
The vendor landscape covers global platform suppliers, Asian headquartered manufacturers, and component specialists. SIGLENT (S2) is presented as an electronic test and measurement systems vendor with regional presences in China, Europe, Japan, Korea, India, and other areas, and a North American contact number 877-515-5551. Tektronix (S5) operates an international website with French, German, Vietnamese, Simplified Chinese, Japanese, Korean, and Traditional Chinese language options, distributes Keithley and EA Elektro-Automatik product families, and runs a Buy Online channel, a distributor locator, a GSA program, and refurbished equipment offerings.
Specialist and OEM oriented suppliers round out the field. Honeytek (S4) describes itself as a leading factory founded in 1998 with 28 years of history in precision measurement, addressing testing centers, industrial technicians, commercial electricians, and DIY users worldwide, and offering OEM and ODM services. Analog Technologies (S1) describes more than 24 years of experience in using and distributing electronic instruments, focusing on a product line that includes power meters, multimeters, and noise amplifiers. Analog Devices (S3) frames electronic test and measurement as a solution area built on signal chain components serving wired and wireless communication, autonomous vehicles, energy storage, AI/ML, and cloud connected sensors.
Buying processes differ by channel. SIGLENT (S2) provides a How to Buy section, authorized partner listings, and a clearance center. Tektronix (S5) supports a distributor locator, GSA program, online purchasing, and dedicated product selectors and calculators. Honeytek (S4) advertises an instant quote capability, a partner program, OEM and ODM services, and a download center. Mouser (S6) describes itself as a source for development boards and components, including power supplies and test instruments, indicating the role of electronic component distributors in the test and measurement supply chain.
After sales engagement is multi tiered. SIGLENT (S2) maintains document downloads, application notes, operating tips, video resources, and a news and events channel covering company news, marketing events, product releases, and promotions. Tektronix (S5) supplies datasheets and manuals, order status, product registration, warranty status, parts ordering, technical support, a support center, and FAQs. Honeytek (S4) operates blogs, contact, and FAQ channels, and Analog Technologies (S1) and Analog Devices (S3) deliver technical content through their respective web properties. Together these channels define the post purchase support environment that procurement teams must evaluate alongside instrument specifications.
Global platform vendors with multi region presence (S2, S5)
Specialist manufacturers offering OEM and ODM services (S4)
Component suppliers entering the test and measurement solution area (S1, S3)
Distribution through authorized partners, online purchasing, and distributor locators (S2, S5)
Specialty channels including GSA programs and refurbished equipment (S5)
Post purchase engagement through documentation, application notes, and support centers (S2, S4, S5)
FAQ
What is electronic test and measurement?
Electronic test and measurement is the discipline of quantifying electrical signals using calibrated instruments such as oscilloscopes, multimeters, spectrum and vector network analyzers, signal generators, and source measure units. Vendors including SIGLENT (S2), Tektronix (S5), and Honeytek (S4) organize their catalogs around these instrument families, supported by signal chain components from suppliers such as Analog Devices (S3) and Analog Technologies (S1).
Which specifications matter most when selecting an oscilloscope?
Primary oscilloscope specifications are analog bandwidth, real time sampling rate, ADC resolution, record length, and waveform capture rate. SIGLENT (S2) illustrates the range with the SDS7000A series offering bandwidth up to 8 GHz, real time sampling up to 20 GSa/s, 12 bit ADC resolution, record length up to 2 Gpts/ch, and a capture rate up to 1,000,000 waveforms per second. Probes such as the SAP5000D 5 GHz high speed differential probe extend usable bandwidth at the measurement node.
How do benchtop and handheld oscilloscopes differ?
Benchtop oscilloscopes such as the SIGLENT SDS series (S2) provide the highest bandwidth, channel count, record length, and analysis options, while handheld oscilloscopes in the SHS1000X and SHS800X series (S2) trade peak performance for portability in field troubleshooting. Both families use the same underlying digital acquisition architecture, so accuracy and noise performance track the selected series rather than the form factor alone.
What types of multimeters are commonly procured?
Procurement typically covers general purpose digital multimeters, clamp meters, automotive multimeters, insulation testers, capacitance multimeters, and voltage detectors. Honeytek (S4) lists all of these families, with display counts from 2,000 to 600,000 across its product range. SIGLENT (S2) and Tektronix (S5) focus their multimeter lines on higher count bench instruments, with Tektronix also offering data acquisition and switching alongside sensitive specialty instruments.
Why are calibration services important in test and measurement?
Calibration services connect instrument readings to national measurement standards, ensuring that specifications such as bandwidth, accuracy, and display count remain trustworthy over time. SIGLENT (S2) offers calibration and certificate issuance as part of its service portfolio, while Tektronix (S5) operates factory verified and multi brand compliant calibration programs with quality and accreditation documentation, defined service levels, and multi site support. Both vendors also track factory calibration status to support audit trails.
Which software options extend instrument capability?
Software packages typically include signal analysis, signal generation, vector signal analysis, and test automation modules. SIGLENT (S2) provides SigScopeLab for signal analysis, SigIQPro for signal generation, and SigVSA for vector signal analysis with 5G NR, NR-A, and NR-NTN support, while Tektronix (S5) groups bench software, data analysis, and test automation as separate solution categories. RF switch systems such as the SIGLENT SSU5000A and SSM5000A (S2) complement the software layer by extending automated multi port measurement.
How should a buyer approach procurement of test and measurement equipment?
Procurement should start with the measurement domain and select the matching instrument family, then verify specifications such as bandwidth, sampling, ADC resolution, and display count against the device under test. Software, automation, and probe ecosystems should be checked for fit, followed by service terms such as warranty, calibration tiers, and return policy (S2, S5). OEM and ODM options, partner programs, and authorized distributor networks (S2, S4, S5) should be evaluated last to confirm commercial fit and lifecycle support.
