Ball spline shafts are grooved along their full axial length, and the number of ball tracks ranges from 2 to 6 depending on nominal diameter and load requirement, with 4 tracks dominating standard product lines [S1][S2].
Thomson publishes a track-count table tying groove count to inner-race ball-circle diameter, listing 3 tracks for a 0.375 in ball circle and 6 tracks for 0.625 in [S1]. NB Corporation frames the same design space as 2 to 6 grooves on a single shaft, with the 4-groove gothic-arch geometry flagged as the most popular layout because it leaves room for in-nut side-by-side recirculation [S2].
Track Count vs Shaft Diameter: The Published Mapping
Thomson's inner-race track table maps 0.375 in ball-circle diameter to 3 tracks and 0.625 in to 6 tracks, so a larger shaft diameter generally carries more tracks, not just deeper ones [S1]. NB Corporation's 2017 spec writeup confirms the full range is 2 to 6 grooves and notes that at 6 tracks the shaft surface is so heavily interrupted that there is no room next to the active ball paths for ball recirculation inside the nut envelope, forcing the nut to protrude beyond the shaft so balls can return above the shaft [S2].
THK's product page uses a 3-crest, 120° equidistant geometry, with two rows of balls running along each crest flank, totalling 6 rows, which is a different counting convention from NB's "groove count" but the same physical outcome of 6 loaded rows per shaft [S4]. For a deeper look at how track count changes the ball spline load envelope, the relationship between groove geometry and moment capacity is the lever to pull first.
Why 4 Tracks Is the Default: Recirculation and Contact
In a 4-groove gothic-arch configuration, the nut can carry side-by-side active and recirculating paths in a compact envelope, and all four tracks stay in contact with their raceways in every loading direction, whereas in some 6-groove designs only half the tracks are loaded at any one time [S2]. The 4-point gothic-arch groove is the standard choice on larger spline sizes and is preferred where maximum precision and moment rigidity are required, because the geometry removes the clearance that would otherwise allow deflection under side load [S2].
Track count also sets the contact count per shaft. Machine Design's rotary-spline analysis puts a 4-groove, 4-point-contact design at 16 ball-to-groove contacts per shaft, against 12 contacts for a 3-groove, 2-point-contact geometry, which is roughly a 33% jump in contact population from a 3-track to a 4-track design [S6]. That contact count is the first-order driver of dynamic load rating, and it explains why a 4-track ball spline is rated at 5 to 12 times the basic dynamic load of a same-size plain slide bush [S2].
Three-Track and Six-Track Trade-Offs
A 3-crest shaft with two rows per crest (6 rows total in THK's convention) keeps the grooves widely spaced at 120° and is the standard high-torque form factor in THK's catalogue [S4]. Going to 6 grooves (in NB's convention, meaning 6 individual tracks) buys load capacity but costs envelope, because the recirculation path has to exit above the shaft and the nut must overhang the shaft end, and the balls will spill out of the nut if it is separated from the shaft, so handling becomes a controlled procedure rather than casual assembly [S2].
Two-track designs exist at the small-diameter end of the range and are effectively the minimum-count configuration; they are the easiest to recirculate inside the nut but carry the lowest moment and torque capacity per unit length. A useful adjacent comparison is the rotary ball spline, which is a standard spline plus a rotating element (gears, crossed rollers, or angular contact ball bearings) on the nut's outer diameter, and is built on the same 3- or 4-groove shaft [S3].
Raceway Hardness, Materials, and the Load Multiplier
Nook Industries publishes raceway hardness at Rc 56-60 on a black-oxide-protected inner and outer race, which is the industry-standard case depth for ball-spline shafts and is what makes the 4-point gothic-arch geometry durable under cyclic moment loading [S5]. Nippon Bearing's product line covers spline outer sleeves from 4 to 100 mm shaft diameter, and the standard construction is a cage plus side rings plus steel balls inside the sleeve, so the track count is set by the inner-shaft groove geometry, not the sleeve [S7].
Rotary ball spline whitepapers from NB and Machine Design converge on the same component set: grooved shaft, spline nut, and ball bearings, with the rotary nut and spline nut integrated into one unit when a ball screw is married to a rotary spline for combined linear and rotational motion [S3][S8]. For reference, the bearing-grade steel used for the shaft is the same family that goes into a precision ball bearing, so the track-count decision is independent of the steel specification but directly tied to the case-hardening depth.
Selection Criteria: Track Count as a Decision Variable
Use a 2- or 3-track (3-groove) spline when envelope and shaft diameter are small, when the application is light-duty, and when the gothic-arch 4-point contact is not required for precision; dynamic load rating will be the lowest of the options, but the nut stays compact and recirculation fits inside the nut body [S2][S4].
Use a 4-track (4-groove) gothic-arch spline as the default for general automation, robotics, indexing, and any application with meaningful moment load; this is the most popular configuration across NB, THK, and Nook product lines, and gives 16 ball-to-groove contacts per shaft in rotary-spline service [S2][S5][S6]. Use a 6-track (6-groove) spline only when load capacity and rigidity demand the maximum contact population, and accept the larger nut envelope, the overhanging recirculation path, and the handling discipline that comes with a non-separable nut-and-shaft assembly [S2].
When Track Count Alone Is Not the Answer
Track count sets contact population, but it does not set life. Life is governed by the basic dynamic load rating, which scales with the cube of the ball diameter, so a 4-track spline on a larger ball can out-carry a 6-track spline on a smaller ball, and the shaft rigidity, mounting, and nut length are the other three levers on the NB "six load and accuracy factors" list [S2]. For a ball-screw-spline combination, the screw's own lead accuracy and the rotary-spline's angular-contact bearing stack become the dominant error sources, and the track count on the spline shaft is secondary to those [S3].
For a deeper dive on how the contact geometry changes with track count, NB's 2017 spec article and the Machine Design rotary-spline piece are the two engineering references that line up track count, contact count, and moment load in the same equations, and both confirm 4 tracks as the baseline rather than 3 or 6 [S2][S6].
Track next: a ball-spline sizing pass should also fix the ball diameter, nut length, and shaft material case depth in the same step, and the resulting dynamic load rating should be checked against the application's required L10 life at the calculated equivalent load. Vendors to watch for design-rule updates in the coming year include THK, NB Corporation, Thomson, Nook Industries, and Nippon Bearing, all of whom publish track-count tables tied to shaft diameter on their product pages [S1][S4][S5][S7].
