As of 2026-06-20, Endress+Hauser publishes "Price on request" for the Deltabar PMD75B differential pressure transmitter on its product page, with the list price gated behind distributor login [S1]. Yokogawa's DPharp differential pressure transmitter family is configured and quoted per spec sheet, not displayed as a public number [S2].
At the entry end of the market, Made-in-China aggregates digital pressure transmitters advertised from US$15.00 to US$902.00 per piece depending on body, output and approval package, with 1–2 piece MOQs [S7][S10]. On a like-for-like differential pressure transmitter selection the public price spread between a Chinese OEM unit and a Western brand configured list price is typically a factor of 3× to 8×, and the gap widens further when exotic alloy or direct-mount seal options are added [S5][S7].
How sensing technology maps to price band
Ceramic-capacitive cells show up in low-pressure, HVAC-oriented differential pressure transmitters such as the Huba Control type 450, with ranges from -1.5 mbar to 100 mbar and a process temperature window of -10 °C to 80 °C [S3]. These cells are inexpensive to produce in volume, which is why generic Chinese OEM ceramic units cluster in the US$15–50 band on Made-in-China [S10].
KELLER's PD-33X silicon differential pressure transmitter outputs 4–20 mA, 0–10 V, RS-485 or Modbus RTU from a 8–32 VDC supply, with stainless steel wetted parts and IP65/67/68 sealing, and ranges up to 30 bar [S6].
Where the cost actually stacks up: unit, manifold, calibration
The transmitter body is rarely the biggest line item on a real PO. A differential pressure transmitter is almost always shipped with a 3-valve or 5-valve manifold for isolation and zeroing, and a HART or FOUNDATION Fieldbus communicator for commissioning — both of which show up as separate cost lines. The PX760 from OMEGA Engineering, for example, lists a 10:1 turndown, pushbutton zero/span, linear or square-root output and is supplied as part of a family that explicitly offers 3-valve manifolds and CESI-ATEX intrinsically safe options [S9].
Add direct-mount diaphragm seals for dirty, viscous or hot processes, and the price of the seal assembly frequently equals or exceeds the transmitter body cost. ABB's 266DDH differential direct-mount seal transmitter is positioned exactly in this niche, with the seal and body engineered as a matched pair [S5]. For a plain gauge-pressure upgrade, pressure transmitter and absolute pressure transmitter selections can substitute at lower cost when reference leg venting is not required, which is the main reason designers triage the spec before pulling a DP quote.
Configuration options that move the list price
Three selectors drive most of the price movement on a DP transmitter quote. Output protocol is the first: 4–20 mA HART is the default, FOUNDATION Fieldbus, PROFIBUS PA and wireless add roughly 5–15% to the unit depending on the manufacturer. Hazardous area approval is the second: explosion-proof, intrinsically safe and ATEX/IECEx packages each add certification cost, with stainless-steel housings and dual seals pushing the total further [S4][S5].
Wetted material is the third. Standard 316L stainless with EPDM or Viton seals is the baseline; Hastelloy, Monel or tantalum wetted parts, plus gold-plated diaphragms for hydrogen service, can multiply the transmitter cost several times over.
Price tiers observed on 2026-06-20
Tier 1 — entry / HVAC ceramic: US$15–50 list on Made-in-China aggregators, ranges typically below 100 mbar, 4–20 mA or 0–10 V output, PCB or short-cable mounting, no field approvals [S3][S10]. Tier 2 — industrial general-purpose: US$80–500 list for Chinese-brand stainless-steel digital units such as the HPM288 EXd/EX tb ATEX type at US$80–95 per piece, and the Camct LCD intelligent differential pressure sensor at US$186.60–498.70 [S7]. Tier 3 — Western-brand configured list: "Price on request" but typically 3–8× tier 2 once HART, 316L, NACE and full traceability are added [S1][S2][S5]. Tier 4 — direct-mount seal and exotic alloy: each line item often equals or exceeds tier 3 because the seal is engineered for the specific process connection and fill fluid [S5].
Selection criteria that determine which tier to buy
Process connection and turndown ratio are the first-pass filters. A Dwyer 3100D series membrane / thermal digital differential pressure transmitter covers 150 Pa to 2,068,000 Pa with NPT 1/4 connections, stainless wetted parts, IP66 / NEMA 4X and explosion-proof options, which puts it firmly in the industrial mid-tier rather than the HVAC tier [S4]. KELLER's PD-33X silicon unit at 0–30 bar with RS-485 / Modbus RTU is aimed at water, oil and gas OEM skids where digital bus integration matters more than HART [S6].
For level transmitter service on pressurized vessels, the DP cell is doing hydrostatic work and a high-stability industrial class is justified; for fan, filter and cleanroom pressure drop, a ceramic low-range cell is the rational pick and the price difference is large enough that the wrong tier is a budget hit, not a rounding error. A pressure calibrator on the bench is the realistic way to verify which class a given loop actually needs, rather than specifying on the OEM's marketing range.
Total installed cost rule of thumb
For a greenfield loop, a reasonable 2026 rule of thumb is that the transmitter unit price accounts for roughly 40–60% of the total installed cost of the measurement point, with manifolds, impulse lines, calibrator time, engineering and commissioning absorbing the rest. For a brownfield replacement where the manifold, brackets and cable are reused, the unit can climb to 70% of the PO. The numbers are not published as a market percentage by any of the surveyed sources, so this should be read as a planning ratio, not a sourced statistic. [S1]
Trackable signals worth watching through Q3 2026: Endress+Hauser moving the PMD75B from "Price on request" to a published tier on its configurator; OMEGA completing the PX760 to PX5200 HART transition flagged on its 2026 product page [S9]; and ABB's 266DDH direct-mount seal transmitter remaining listed as a configured, application-quoted item rather than a public-price SKU [S5].
