Manufacturer profile

NKK Switches of America, Inc.

NKK Switches of America, Inc. is a manufacturer based in Scottsdale, United States. [S2][S1]

Country
United States [S1]
City
Scottsdale [S2]

Procurement snapshot

Only hard product-level facts retained from the cited source route are shown below. A missing buying field is handled separately, rather than estimated from the listed series.

Circuit and rating
The item is DPDT On-Mom and rated 5 A AC/DC at 125 V AC or 30 V DC. [S4]
Illumination and mounting
It uses a red 1.85 V DC LED, snap-in mounting, solder lugs and a 16.20 mm square cutout. [S5]
NKK UB25KKW015C illuminated pushbutton
Official product image [S6]

Evidence scope

The retained official product route documents: NKK Switches documents UB25KKW015C as a finished low-profile illuminated pushbutton. This dossier uses that cited route as the editorial scope. [S6]

The retained research coverage separates company identity from the named product evidence. It does not turn one model or series into a claim about unlisted company-wide operations. [S9]

Pushbutton Pilot Light

Documented series: NKK UB25KKW015C illuminated pushbutton

NKK Switches documents UB25KKW015C as a finished low-profile illuminated pushbutton. [S6]

Documented specifications for Pushbutton Pilot Light
Service temperature-40°C [S10]
Ingress protectionIP65 [S11]
Circuit and rating
The item is DPDT On-Mom and rated 5 A AC/DC at 125 V AC or 30 V DC. [S4]
Illumination and mounting
It uses a red 1.85 V DC LED, snap-in mounting, solder lugs and a 16.20 mm square cutout. [S5]
  • NKK UB25KKW015C illuminated pushbutton [S6]

Selection fit: All circuit, LED, terminal, mounting and electrical facts are limited to UB25KKW015C. [S8]

Selector Switch

Documented series: NKK TS1N-AT432 rotary selector

NKK documents TS1N-AT432 as a finished panel-mount rotary selector switch. [S7]

Documented specifications for Selector Switch
Ingress protectionIP68 [S16]
Current rating10A [S17]
StandardIEC 60529 [S18]
Service temperature30°C [S19]
Positions and throw
The SP11T article supports an adjustable two-to-eleven-position stop range with 30° throw. [S12]
Terminals and rating
TS1N-AT432 uses screw terminals and lists 6 A at 125 V AC. [S13]
  • NKK TS1N-AT432 rotary selector [S7]

Selection fit: Expose the not-recommended-for-new-designs lifecycle caveat and re-check availability before procurement. [S14]

Product range and documented series

NKK Switches documents UB25KKW015C as a finished low-profile illuminated pushbutton. [S6]

  • NKK UB25KKW015C illuminated pushbutton [S6]Source note: NKK UB25KKW015C illuminated pushbutton
  • NKK TS1N-AT432 rotary selector [S7]Source note: NKK TS1N-AT432 rotary selector

Procurement fit

The illuminated pushbutton UB25KKW015C is documented under a procurement fit that restricts all circuit, LED, terminal, mounting, and electrical facts to that single part number. The TS1N-AT432 rotary selector carries a not-recommended-for-new-designs lifecycle caveat. Availability should be reconfirmed prior to procurement actions for the rotary selector, as the part is flagged for design refresh.

Technical capabilities

The UB25KKW015C illuminated pushbutton operates as DPDT On-Mom, rated 5 A AC/DC at 125 V AC or 30 V DC. Illumination is supplied by a red 1.85 V DC LED, with snap-in mounting, solder lugs, and a 16.20 mm square cutout. The TS1N-AT432 rotary selector is configured as SP11T with an adjustable two-to-eleven-position stop range and 30° throw, using screw terminals at 6 A 125 V AC.

Markets and applications

The documented facts do not specify end markets or applications for either UB25KKW015C or TS1N-AT432. The two part numbers represent distinct switching formats, an illuminated DPDT momentary pushbutton and an SP11T adjustable rotary selector, but the available evidence does not include industry verticals, customer use cases, or application notes. Specific market fit remains not publicly documented.

Evidence limitations

Several common procurement fields are not publicly documented, including lead times, minimum order quantities, pricing, distribution channels, and authorized stockists. The not-recommended-for-new-designs status of TS1N-AT432 warrants re-verification at the time of inquiry. Certifications, compliance marks, environmental ratings, and material declarations are also not publicly documented in the supplied facts. No additional part numbers are recorded in the source.

Editorial summary

NKK Switches of America, Inc. is a United States based manufacturer of electromechanical switching components, with the directory entry located in Scottsdale. The documented category coverage comprises pushbutton pilot light devices and selector switches, supported by two specific part numbers: the UB25KKW015C illuminated pushbutton and the TS1N-AT432 rotary selector. This profile is limited to facts documented for those two items.

Compiled prose, not a quotation. It restates facts drawn from the cited rows above and adds none of its own. It is not itself a sourced record, so read the cited sections for the authoritative wording.

Not published in retained sources

These common buyer fields were explicitly outside the retained source coverage for this dossier. They are shown as omissions, not filled with a proxy, a related model or an assumption.

  • Annual sales [S9]
  • Availability or stock [S9]
Research coverage

Evidence states describe the public material reviewed for this profile; they do not rate the company or assert an undisclosed fact.

  • Identity and location are retained from the cited official source. Product facts and visual are limited to NKK UB25KKW015C illuminated pushbutton; no unlisted company-wide performance, availability, production or revenue claim is asserted. [S9]Company-stated
  • Identity and location are retained from the cited official source. Product facts and visual are limited to NKK TS1N-AT432 rotary selector; no unlisted company-wide performance, availability, production or revenue claim is asserted. [S15]Company-stated

Frequently asked questions

What Pushbutton & Pilot Light product is documented for NKK Switches of America, Inc.?

The retained product material names NKK UB25KKW015C illuminated pushbutton. The dossier keeps this as a product-level statement rather than using it as a claim about the company's entire catalogue. [S6]

Which published circuit and rating should a buyer compare?

The cited product material records: The item is DPDT On-Mom and rated 5 A AC/DC at 125 V AC or 30 V DC. Use the value as a product-level comparison point, while keeping the exact model and installation boundaries in the cited route. [S4]

Which published illumination and mounting should a buyer compare?

The cited product material records: It uses a red 1.85 V DC LED, snap-in mounting, solder lugs and a 16.20 mm square cutout. Use the value as a product-level comparison point, while keeping the exact model and installation boundaries in the cited route. [S5]

Which common buying fields are not published in the retained sources?

The retained source packet does not publish Annual sales, Availability or stock. Those fields are intentionally left out of the procurement snapshot rather than inferred from a related series, a product image or the company identity. [S9]

Research notes

The retained first-party packet supports a richer product-level reading surface, but it does not yet contain 600 words of distinct cited content. This noindex dossier remains in reviewing status until additional source-backed facts are retained.
