For general fabrication work in 2026, polyurethane elastomer is best framed as a thermoset castable whose properties are set by prepolymer chemistry, not by filler loading, giving a usable hardness range from 50 Shore A to 75 Shore D within a cured service window of -60°C to +85°C [S3].
That single envelope drives most of the selection logic. Once a part is cast, it cannot be remelted or reshaped, so the hardness, polyol backbone, and curative system have to be locked in before the mold is poured, with MOCA or amine curatives melted at 100°C to 180°C and degassed under vacuum to keep the casting clean [S1][S3].
Where Polyurethane Sits Against Rubber, Silicone, and Plastic
Polyurethane is not a default substitute for every elastomer, and the 2026 industrial guide from ENRI is explicit that silicone, polyurethane, and rubber are not interchangeable on a roller covering, since their behaviour against temperature, load, abrasion, chemistry, and surface-release conditions diverges sharply [S2]. Silicone rollers run continuously to roughly 250°C with controlled peaks approaching 280°C to 300°C, well above the polyurethane ceiling [S2]. Polyurethane wins on abrasion, cut, and tear energy per unit volume, and on rebound control in high-impact mounts, which is why stock-shapes suppliers in New Zealand market it as combining the toughness of metal, the elasticity of rubber, and the wear resistance of engineering plastics [S2][S3].
For gasket and sealing duties the same logic flips. Universal Gaskets maps the elastomer landscape with EPDM and nitrile as the general-purpose defaults, HNBR and FKM (Viton) covering elevated oil and aromatic-solvent service to 200°C and above, VMQ silicone rated -60°C to +230°C for food and high-temperature seals, and FFKM reserved for the extreme chemical envelope with a soft ceiling around 325°C [S4]. Polyurethane is rarely the right pick for static gasketing because its compression-set recovery and chemical breadth sit below NBR and FKM, but it dominates dynamic abrasion duties such as rollers, scraper blades, and wear pads [S2][S3][S4].
Hardness Map and What Each Shore Window Buys You
Hardness is the first design dial. Castable polyester and polyether prepolymers deliver roughly 50 Shore A at the soft end, climbing through 90 Shore A for general industrial bushings and pads, and reaching 75 Shore D for rigid load-bearing parts such as rollover pads, heavy machinery wear strips, and certain gear replacements [S3]. At the soft Shore A 50 to 80 band the material behaves like a high-rebound rubber, taking impact without cracking, which is the band specified for vibration mounts, suspension bushings, bump stops, and shock pads including the bonded Norzorb anti-rebound pads mated to steel backing plates with UHMW-PE slip surfaces used in quarry and forestry service [S3].
As hardness climbs above 90 Shore A and into the Shore D range, the modulus rises steeply, deflection under static load drops, and machining behaviour shifts from rubber-like to engineering-plastic-like, so the part can be turned, milled, and bored from stock rod, sheet, and tube on standard tooling [S3]. That is also the band where polyurethane displaces rubber components that wear too quickly, plastics that deform under impact, and metal parts that transmit excessive vibration, since at 75 Shore D the load-bearing capacity per unit volume is high enough to substitute for many cast iron and mild steel wear parts at a fraction of the weight [S3].
Service Envelope: Temperature, Chemistry, and Load
The cured thermoset working window is -60°C to +85°C for general-purpose grades, which covers most fabrication shops, agricultural machinery, transport fleets, and OEM lines outside the chemical process industries [S3]. Above 85°C the hard-segment phase softens, compression set accelerates, and the long-term dimensional stability ENRI flags as a critical drift parameter on rollers starts to move [S2][S3]. Below -60°C the material glass-transitions and loses rebound, although it typically remains ductile rather than brittle down to that point [S3].
Chemical compatibility is backbone-dependent. Polyester-based polyurethanes resist oils, fuels, and many solvents but hydrolyse in hot water and humid steam, while polyether polyurethanes hold up better to water and biological growth but swell more against hydrocarbon fuels; for marine duty the polyether-versus-polyester split is the central choice and is covered in detail in this marine polyurethane selection guide. For general fabrication not exposed to continuous hot water or concentrated acids, either backbone is acceptable, and selection defaults to the polyol already used in the shop's inventory to avoid cross-contamination. Abrasion resistance is the headline property and is the reason polyurethane replaces both rubber and many plastics in wear strips, chute liners, and screen panels [S2][S3].
Process Equipment: Dispensing, Degassing, and Curing
Cast polyurethane production is equipment-bound, and Pacific Urethanes documents a typical 2026 cast line built around dynamic mixing and metering at speeds up to 2800 RPM, MOCA melting units operating from 100°C to 180°C with a 20 L/h melt rate, hot-air circulation ovens for post-cure, and plate vulcanising presses held at 110°C to 130°C with plate flatness held to 0.1 mm or better [S1]. A planetary vacuum degassing mixer sits in front of the casting head to strip entrained air from the mixed prepolymer, since voids are the dominant defect in open-pour cast parts and propagate as crack initiators under cyclic load [S1].
For a low-to-medium volume fabrication shop, casting beats injection moulding on tooling cost and beats metal fabrication on geometry complexity, so most custom bushings, pads, and rollers up to a few hundred parts per year go through this cast-and-cure route rather than a moulded or machined-from-billet route [S1][S3]. The trade-off is post-cure time: thick sections need staged heating in a hot-air circulation oven to drive the reaction to completion and stabilise dimensions before the part is put into service, which is one reason fabricators stock standard rod, sheet, and tube in cut-to-size lengths for fast-turn jobs [S1][S3]. For background on the broader material class and its engineering uses, the polyurethane elastomer encyclopedia entry covers hardness, rebound, and chemical families in more detail.
Selection Criteria Comparison: PU vs Silicone vs NBR/FKM
Lining the three families up against the constraints ENRI and Universal Gaskets treat as decisive gives a structured view a specifier can quote directly. On maximum continuous temperature, silicone leads at roughly 250°C with peaks to 280°C to 300°C, FKM sits at 200°C and above, NBR holds around 100°C, and general-purpose polyurethane stops at 85°C, so any duty above 100°C rules standard PU out [S2][S3][S4]. On abrasion and tear, polyurethane leads, silicone trails, and NBR/FKM sit in the middle, which is why PU dominates dynamic scraper, roller, and chute duties [S2][S3].
On chemical breadth, FKM and FFKM cover the widest envelope, including steam, amines, and aromatic solvents, while polyurethane is selective and depends on polyol backbone; on cost per kilogram, NBR and SBR are cheapest, silicone and FFKM are most expensive, and polyurethane sits in the upper-middle band but often wins on cost-per-service-hour because of longer wear life [S3][S4]. On rebound and shock absorption, natural rubber and polyurethane lead, with Shore A 50 to 80 PU grades used specifically for vibration mounts and impact pads, while silicone damps less and recovers slower at room temperature [S3][S4]. For a fabricator weighing all four criteria, the rule of thumb that follows is to default to PU when abrasion and impact dominate the duty, switch to NBR or FKM when sealing and chemical resistance dominate, and reach for silicone only when sustained temperature exceeds 150°C [S2][S3][S4].
Limits, Failure Modes, and What to Avoid
Polyurethane fails in characteristic ways and the 2026 guide set is consistent on the warning signs. Above 85°C continuous service the material softens, takes a permanent set, and loses rebound, which ENRI flags as a process-drift failure mode that is hard to diagnose because the roller does not rupture, it just stops holding tolerance [S2][S3]. In hot, humid, or steam service, polyester-based PU hydrolyses, losing tensile strength and cracking from the inside out, which is the standard reason to specify a polyether backbone in wash-down, food-contact, and marine applications [S3]. In heavy aromatic-solvent or strong acid service, both backbones swell and degrade, and the right move is an FKM or FFKM seal rather than a PU part [S4].
Bonding is the other common pitfall. A cast PU pad poured against a steel plate without the correct bonding agent and without proper surface preparation will debond under cyclic load, turning a wear pad into a loose shim; the integrated bonding systems Pacific Urethanes lists alongside its processing equipment exist precisely to remove that failure mode [S1]. Finally, machining cast PU requires sharp tooling, light cuts, and good dust extraction, because the swarf is fine and tends to clog standard rubber-cutting geometry, especially in the Shore D 60 to 75 window where the material behaves more like a filled engineering plastic than a soft elastomer [S3].
Specification Anchors and Trackable Signals
The current 2026 product landscape gives a fabricator four trackable spec anchors: a 50 Shore A to 75 Shore D hardness envelope for castable grades, a -60°C to +85°C cured working window for general-purpose formulations, a 100°C to 180°C MOCA melt range with a 20 L/h throughput on standard melting units, and a 110°C to 130°C cure window on plate vulcanising presses held to 0.1 mm flatness [S1][S3]. For the next step, watch the 2026 wave of self-healing TPU research exemplified by the phosphorus/nitrogen biphenyl-segment system published in Advanced Materials, which is targeting the long-standing trade-off between mechanical strength, fire retardancy, and ambient self-healing in TPU, and may shift the spec sheet on impact-resistant parts within a few product cycles [S5].
