Spring washer load-deflection (L/D) curves fall into two practical families: a near-linear spring rate over a defined working window for curved, wave, finger and slotted types, and a non-linear, h/t-ratio-controlled curve for Belleville (disc spring) washers [S1][S3].
West Coast Lockwasher catalogues spring washers as components that "provide a compensating spring force and sustain a load or absorb a shock," with applications including take-up of large tolerance variations, end-play elimination, expansion/contraction compensation, and intermittent shock absorption [S1]. Within that family, the geometry chosen dictates whether the engineer is reading a straight line or a curve on the data sheet.
How a Spring Washer L/D Curve Is Built
Load and deflection are the defining characteristics: each washer is plotted with applied force on one axis and axial deflection on the other, and the slope between any two working points is the spring rate [S1]. WCL's reference example uses a simple coil spring in 10-lb / 1-in increments to illustrate a "constant spring rate" linear curve, then notes that most spring washers do not perform this consistently because stored energy is lost to friction at the bearing surfaces on the return stroke [S1].
For design work, three derived metrics matter: free height (h), material thickness (t), and the working deflection window expressed as a percentage of total deflection. These are the numbers that turn a catalogue washer into a specified part.
Curved, Wave, Finger and Slotted Types: Linear-Rate Family
Curved (single-wave) washers are the lowest-rate, highest-deflection spring washer relative to size, and maintain a linear spring rate between 20% and 90% of their total deflection; engineers should size the working point inside that band [S3]. Wave washers deliver medium thrust loads and medium deflection, with a linear spring rate between 20% and 80% of total deflection, and they expand less on compression than curved washers of the same OD [S2][S3]. Slotted washers run at higher thrust loads and stiffer rates, with a linear spring rate only between 20% and 70% of total deflection, and are not intended for repeated cycling [S3].
Finger washers are a hybrid that combine curved and wave characteristics, used for preloading ball bearings and absorbing end play, wear, vibration, and noise where unavoidable loose internal clearances exist [S2]. Wave (waveform) washers provide higher load-bearing capacity than curved types because of three-point contact and sharper curves, are typically used in thrust-loading applications for small deflections where radial space is limited, and stay "linear until washer is almost flat" [S2]. Helical spring lock washers, by contrast, are usually run only to 10-20% of their deflection before they flatten and lose their spring function [S10].
Belleville / Disc Spring Washers: Non-Linear Curve Governed by h/t
Belleville (conical / disc spring) washers give the highest load-bearing capacity for their size, compensate for expanding and contracting joints, and can be stacked in series or parallel to multiply either load capacity or deflection [S2]. The shape of their L/D curve is set by the ratio of free height to material thickness (h/t): up to h/t = 1.5 the disc spring may safely be taken to the flat position, while at higher ratios the load-deflection curve becomes increasingly curved and the part must be stopped well short of flat to avoid plastic deformation [S8].
A 2019 IJERT paper modelling Belleville washers confirms the same behavioural pattern: in the initial tightening the load-deflection curve has a constant positive gradient, and as tightening continues the curve develops the characteristic non-linearity, with the precise shape set by the four geometric parameters (ID, OD, thickness, cone height) [S5]. A 2015 Texas A&M-Kingsville thesis on wave spring washers uses the same five-parameter solid-modelling approach (number of waves, ID, OD, thickness, wave height) to predict L/D response analytically [S4].
Selection Criteria and Limits (Where to Read the Curve)
Belleville washers specified to take up packing wear are commonly expected to absorb 0.5 to 1.0 mm of axial movement without manual adjustment, and supplier load-deflection curves should always be reviewed for the actual part being quoted [S6]. For any non-Belleville type, the working point on the L/D curve must be kept inside the published linear-rate window: 20-90% for curved, 20-80% for wave, 20-70% for slotted, and 10-20% maximum for helical lock washers before they go flat [S3][S10].
The Huyett catalogue positions Belleville washers as the right pick when high tension, hole-spanning, and stack-configurable load/deflection are required, curved washers when light thrust loads and repetitive motion cycles dominate, and wave washers when thrust loading and small deflections are required in a tight radial envelope [S2]. Spring-steel vs stainless grade trade-offs, which feed back into the L/D numbers via modulus, are covered separately in a Spring Steel vs Stainless Spring Washer corrosion comparison.
Stacked, Ganged, and Where Curves Multiply
Belleville washers are unique in this family because their load-deflection behaviour can be re-shaped by stacking: parallel stacks multiply the load at a given deflection (same deflection, n times force), while series stacks multiply the deflection at a given load (same load, n times travel) [S2]. The IJERT modelling paper treats this stacking as a continuation of the same four-parameter geometry, so published L/D curves should be checked at the actual stack configuration, not the single-washer curve [S5].
For disc springs specifically, a free-height-to-thickness ratio above approximately 1.5 means the L/D curve bends enough that the flat position is no longer safe, and the design must hold a clearance at maximum working load; below 1.5 the curve is shallow enough to be taken to flat without plastic damage [S8]. Curved and wave washers do not have this h/t cliff because their geometry constrains the maximum strain differently.
Failure Modes and Common Spec Mistakes
Helical spring lock washers flatten at 10-20% deflection and then contribute nothing, so specifying them as a continuous spring element across a large thermal or wear range is a known under-specification [S10]. Slotted washers look like wave washers on a drawing but are designed for static friction, not cycling, and will fatigue if used in a dynamic joint [S3]. Belleville washers run past the flat position at h/t > 1.5 take a permanent set and lose their preload on the next thermal cycle, which is why a 0.5-1.0 mm packing-wear target must be checked against the supplied curve, not assumed [S6][S8].
On the L/D chart itself, the "linear" portion of any spring washer curve is only linear inside its working window; outside it the curve rolls off and the spring rate is no longer constant, which is why the percentage-of-deflection windows above are quoted as engineering limits, not nominal values [S1][S3]. A spec that places the operating point outside those windows will see drift in preload, not the constant force the catalogue implied.
Applicable Standards and Where Curves Are Sourced
There is no single universal standard for spring washer L/D curves, so engineers rely on the geometry-based design guides from disc-spring specialists and on supplier-furnished L/D plots for each catalogue part [S1][S3][S8]. Disc-spring design parameters (h/t limits, stack behaviour, safe travel to flat) follow the conventions in published disc-spring design guides, while curved and wave washers are typically specified against manufacturer load-rated series rather than a published national standard [S3][S8].
For component definition and the relationship between washer shape and bolted-joint behaviour, refer to the spring washer reference page; sealing-joint applications that pair a Belleville with a static seal are covered under sealing washer selection logic. Preloading of bearings with finger or wave washers is one of the practical cases where L/D curves are read alongside the bearing's own stiffness curve.
Trackable signal: any new disc-spring design guide revision that re-states the h/t = 1.5 safe-to-flat boundary or that updates the parallel/series stacking multipliers for high-h/t Belleville geometries will change which parts of the L/D curve are usable, and a future catalogue release pairing a published L/D curve with a verified h/t ratio is the cleanest way to re-spec an existing spring-washer callout.
