AISI 9310 is the standard carburizing steel for aircraft gear applications where high core toughness, large section size, and elevated pitting fatigue life are mandatory design drivers [S1].
AISI 8620 remains the default low-alloy carburizing steel for automotive, tractor, and general industrial gears where cost and small-to-medium cross-sections dominate the decision [S4].
Chemistry and Hardenability: Why 9310 Outperforms 8620 in Core Toughness
AISI 9310 contains roughly 3.0% nickel and 1.0% chromium, giving it markedly higher through-hardenability than AISI 8620, which carries about 0.55% nickel and 0.50% chromium [S2]. The extra nickel in 9310 stabilises a tough, ductile martensitic core after carburizing and quenching, while 8620's leaner nickel content limits the case-plus-core strength combination to smaller sections [S4].
That hardenability advantage is the primary reason NASA Technical Paper 1390 identifies AISI 9310 as the material most frequently used to manufacture gears for aircraft, where reliability under high Hertzian contact stress and shock loading outweighs material cost [S1]. For process engineers comparing alloy steel grades for gear duty, the rule of thumb is: pick 8620 when the effective case section stays below roughly 0.6 inches and 9310 when sections, tooth root fillet stresses, or duty cycles push beyond what 8620's hardenability envelope can support.
Operating Temperature Limit: 9310 Above 250°F Becomes a Risk
AISI 9310 loses significant hardness above approximately 394 K (250°F), which limits its use in advanced helicopter, VSTOL, and geared-fan jet engine transmissions that may run hot because of oil cooling limitations [S1]. When gearbox bulk oil temperature routinely exceeds this threshold, the material must be replaced with a higher-temperature carburizing grade such as CBS 600, which retains Rockwell C 58 to 505 K (450°F) for long-term service and 589 K (600°F) short-term [S1].
For most industrial and automotive gearboxes, sump temperatures stay well below the 250°F boundary, so AISI 8620's lower temperature ceiling is not a practical constraint, and the 8620/9310 selection is driven by section size and toughness rather than thermal headroom.
Carburizing Response and Case Hardness Comparison
Both AISI 8620 and AISI 9310 are designed for case-carburizing followed by quench and temper, producing a hard wear-resistant case over a tougher core. Industrial practice carburizes 8620 to a case depth of 0.05 to 0.06 inches, after roughly 14 hours in an ammonia-bearing atmosphere furnace at around 1600°F, where the surface effectively becomes a 86100-equivalent hardenable layer [S3].
AISI 9310 responds to the same carburizing cycle but retains more hardenability in the core because of its higher nickel, which means the transition zone between case and core is less likely to be the weak link under high Hertzian contact stress [S1][S4]. For carbon steel vs alloy steel decisions, the practical takeaway is: 8620 carburized to 0.05 to 0.06 inches is adequate for heavy-duty automotive and tractor gears, while 9310 is the correct pick when a deeper effective case plus a stronger core is required to resist tooth bending fatigue and pitting.
Decision Criteria: 8620 vs 9310 vs Cast Iron vs 4320
Four options dominate the carburized-gear material choice, and a side-by-side comparison helps the specifier pick: AISI 8620 (low cost, small/medium sections, automotive default) [S4]; AISI 9310 (high nickel, high core toughness, aerospace default) [S1]; AISI 4320 (super-duty gears, core responds to heat treat to reinforce the case under extreme loads) [S3]; and cast iron (no heat treat, only viable when gear size and inertia constraints allow it) [S3].
By selection criteria: (1) Cost, 8620 is lowest, 4320 next, 9310 highest. (2) Maximum case depth / through-hardenability, 9310 leads, 4320 second, 8620 lowest of the carburizing trio. (3) Operating temperature ceiling, 8620 and 9310 both lose hardness above 250°F and need replacement by CBS 600 or similar for sustained 400 to 600°F service [S1]. (4) Tooth profile finishing, all three carburizing steels typically require lapping or hard grinding after heat treat to correct distortion, because the carburized layer expands during quench and distorts the involute profile [S3].
The Strange Engineering S-Trac differential spec sheet makes this trade-off explicit: the S60/Dana 60 case uses case-hardened AISI 8620 for case halves and internal gears where input torque and shock are within its design window, while the Ford 9 inch application upgrades to case-hardened AISI 9310 for added toughness at the internal gears, using ten pinion gears for the ultimate torque carrying capacity [S2].
Section Size, Tooth Geometry, and When 9310 Is Mandatory
A practical decision rule from machinist consensus: choose 8620 when the gear is small or medium, the section at the tooth root stays within the 8620 hardenability band, and the duty cycle is conventional industrial or automotive [S3]. Choose 9310 when the gear must be compact but heavily loaded, when tooth root bending stress or Hertzian contact stress pushes toward aerospace transmission limits, or when tooth root radii are small and require a tougher core to prevent catastrophic tooth fracture [S1][S3].
Forged 9310 pancake forgings are recommended over bar-stock machining when maximum life and strength are required, because forged stock gives better grain flow direction at the tooth root than cut-from-bar [S3]. Machinists also note that when section size is not a constraint, simply making the gear larger and using cast iron without heat treat can match the reliability of a carburized alloy steel gear, but this is rarely an option in aerospace or high-power-density drivelines.
Standards, Specifications, and Sourcing Notes
AISI 8620 is covered by ASTM A29 / A29M-2015 for hot-forged and cold-processed carbon and alloy steel bars, the standard reference for the hardenability-guaranteed structural grade used in carburizing state for transmission gears and pinion shafts [S4]. AISI 9310 is produced to ASTM A322, the standard for high-hardenability alloy steel bars intended for components with large cross-sections requiring high toughness and core strength, mainly used in critical aircraft engine gears [S4].
For stockists, both grades are routinely supplied as round bar, gauge plate, pipe, tube, rod, square, hexagonal bar, blanks, plate, sheet, and precision-ground flat stock, with hollow bar and black surface available in alloy steel bar form [S4]. When the stainless steel or silicon steel alternatives come up, they are not direct substitutes: stainless gearing is reserved for corrosion-only service, and silicon steel is an electrical laminations material, not a gear material.
Verification and Post-Heat-Treat Finishing
Regardless of whether the choice is 8620 or 9310, the post-carburizing finishing step is non-negotiable for reliable gear geometry: the tooth profile changes during heat treat because the carburized layer increases in volume, so either precision lapping or hard grinding of the tooth profile must follow quench and temper [S3]. Skipping this step leads to poor tooth contact pattern, edge loading, and accelerated pitting or tooth fracture, particularly in 9310 aerospace gears where the consequence of failure is severe [S1].
Two trackable signals for future spec updates: (1) the SAE AMS / ASTM revision cycle for 9310 bar products, since AMS 6260 and AMS 6265 govern the aircraft-quality vacuum-melted 9310 variant referenced by most aerospace transmission drawings, and (2) the spread of CBS 600 and similar high-temperature carburizing grades into helicopter and wind-turbine gearbox designs as bulk oil temperatures continue to climb in next-generation drivetrains [S1].
