A load cell turns applied force into a low-level differential voltage (typically 1-3 mV/V at full scale), and the weighing indicator supplies regulated excitation, amplifies that signal, then linearises and digitises it for display or PLC hand-off [S3][S4].
Strain gauges bonded to a metal element form a Wheatstone bridge; deformation under load unbalances the bridge, and the resulting millivolt signal travels over a 4 or 6-wire cable to the indicator's analogue front end [S3][S4].
From Force to Millivolts: The Transducer Stage
A load cell is a force transducer: mechanical deformation under load changes the resistance of bonded strain gauges, and the bridge output scales linearly with that deformation [S4]. Single-point, S-type, bending/shear beam, double-ended shear beam, and compression canister are the five common form factors, each mapped to a different mounting geometry and capacity class [S4]. When weight is applied, the cell bends slightly, the gauges stretch or compress, and a proportional electrical output is generated for the indicator to read [S5].
Strain gauges are routinely described as the "heart" of the load cell because the bridge balance, gauge layout, and creep compensation all sit at this stage [S3]. Excitation voltage (commonly 5-15 V DC) is forced into the bridge from the indicator, and the return signal sits in the millivolt range, which is why cable shielding, gauge length, and lead-wire resistance matter to noise and zero stability [S3][S4].
Signal Lines, Excitation, and the 4-Wire vs 6-Wire Question
With no load on the cell, the two signal lines sit at equal voltage; under load, one line rises and the other falls by a few millivolts, and the indicator reads the differential [S3]. A standard 4-wire cable carries +Excitation, -Excitation, +Signal, and -Signal, while a 6-wire variant adds +Sense and -Sense leads so the indicator can correct for voltage drop in long cable runs [S3][S4].
Sense-line feedback is the practical fix for cable-length error: in a 4-wire hook-up the indicator assumes the excitation at the cell equals the excitation at its terminals, but a 100 m run of 24 AWG copper can drop tens of millivolts and steal accuracy; 6-wire sense compensation removes that error source, which is why tank and silo installations with remote junction boxes almost always specify 6-wire [S3]. A load cell module typically integrates the cell, mounting hardware, and a junction box, and is the cleanest way to keep the 6-wire run short and the sense loop intact [S1].
Inside the Indicator: A/D, Filtering, and Linearisation
The indicator amplifies the millivolt signal, filters it, then converts it with an analogue-to-digital converter before applying calibration constants to produce engineering units [S2]. Most modern indicators store mV/V sensitivity, zero balance, and a multi-point linearity table per channel, so the same indicator can read one load cell on a bench scale or sum four cells on a truck scale through a junction box [S2][S5].
Digital indicators do not just read the bridge; they also drive excitation, perform temperature compensation, and handle tare, net/gross, and unit conversion before the value is sent to a display, printer, or PLC [S2]. A weighing indicator is therefore a small signal-conditioning computer: a regulated supply, an instrumentation amp, an ADC, and a microprocessor running calibration and comms in one enclosure [S2][S3].
Calibration, Sensitivity, and What the Spec Sheet Actually Means
Calibration maps raw counts to mass using two endpoints (zero and span) plus, on better units, a multi-point linearity correction tied to the cell's rated output in mV/V [S2][S3]. A load cell rated 2 mV/V at 10 V excitation will deliver 20 mV at full scale, and a 100 kg cell rated 2 mV/V driven from 10 V produces 20 mV at 100 kg, or 0.0002 mV per gram, which sets the resolution floor for the indicator's ADC [S3].
Morehouse-style precision cells used as reference standards cover a verified range of 4% to 100% of system capacity, which is why three cells (600,000 lbf, 25,000 lbf, 1,000 lbf) can replace a much larger stack of deadweights from 40 lbf up to 600,000 lbf [S3]. For process weighing, OIML R60 and NTEP Handbook 44 set the accuracy classes, and the indicator's resolution, excitation stability, and warm-up drift must all be specified below the cell's combined error budget or the chain will be limited by the instrument, not the transducer.
Where the Signal Path Breaks: Noise, Drift, and Common Failure Modes
The most common field failures are zero drift from moisture in the cell or junction box, mV-level noise from broken shields, and span shift after mechanical overload, all of which show up at the indicator long before the cell itself fails outright [S2][S4]. Load cells in tank and silo service are routinely paired with load cell module assemblies that include lift-off protection, check rods, and integrated surge arrestors, so an overpressure event or a lightning strike does not propagate into the indicator's input stage [S1][S4].
Bending-beam and single-point cells are more sensitive to side load than canister or double-ended shear beam designs, so the indicator's filtering and zero-tracking constants must be tuned to the mechanical environment or the displayed weight will wander by a few divisions at empty [S4]. For platforms and truck scales, the indicator's corner-load adjustment (each of the 4 cells trimmed independently) is the software fix for mechanical misalignment, and it only works if the indicator supports per-channel mV/V entry [S2][S5].
Who This Signal Chain Is For, and Where It Is Not
This architecture is the right fit for static and quasi-static weighing from a few grams up to several hundred tonnes: bench scales, hopper scales, tank and silo inventories, truck and rail scales, checkweighers, and force calibration rigs [S1][S4]. It is a poor fit for high-speed dynamic weighing above roughly 5 m/s conveyor travel, for in-line mass flow at percent-level accuracy, and for any application where the measurand is not a downward force, which is where Coriolis, strain-gauge-based electronic load cells, and piezoelectric sensors take over instead [S4][S5].
Engineers specifying a new weigh station should treat the cell, the cable, the junction box, the surge protection, and the indicator as one signal-integrity problem; choosing a 6-wire cell and then landing it on a 4-wire indicator, or vice versa, is the single most common way to lose accuracy before calibration even starts. If the cell and indicator are mismatched, the next decision is whether the application warrants a dial indicator for local readout, a filling weighing scale controller for dosing, or a load cell with a higher protection class for washdown or hazardous-area service [S1][S4].
Watch for two trackable signals in the next buying cycle: indicator firmware that exposes raw mV/V and per-corner diagnostics over Ethernet/IP or PROFINET, and load cell datasheets that publish sense-line resistance and creep in ppm/10 min alongside the standard mV/V rating, both of which will make the cell-to-indicator handoff auditable rather than a black-box calibration [S2][S4].
