NBR is a random copolymer of butadiene and acrylonitrile, first industrialised in 1937 by I.G. Farbenindustrie as Buna N, and remains the lowest-cost elastomer for oil, fuel, and grease service [S2]. Commercial supply now exceeds 300 grades globally, differentiated mainly by acrylonitrile (ACN) content, Mooney viscosity, and pre-crosslinking [S3].
Typical ACN range spans 18% to 50%, and that single number is the primary design lever: low ACN (≈18%) gives the same oil swell as chloroprene rubber (CR) but better low-temperature flexibility, while high ACN (≈40-50%) maximises fuel resistance and gas barrier behaviour at the cost of Tg [S2]. Nitrile rubber is therefore a graded material family, not a single compound, and selection starts with ACN content.
What NBR Does Well: Hydrocarbon Resistance, Abrasion, and Processability
The polar nitrile (-C≡N) side group is the chemical reason NBR resists mineral oils, liquid fuels, and technical lubricant greases; the same polarity raises Tg and reduces chain-segment mobility, which improves barrier properties [S2]. The same reference quantifies the trade-off: as oil swell falls, Tg rises, and at 18% ACN the NBR's oil resistance drops to the level of a CR rubber that itself only offers "moderate" oil resistance [S2].
Beyond oil/fuel behaviour, NBR delivers good hot-air resistance within defined windows (long-term 90°C, 40 days at 120°C, 3 days at 150°C), good abrasion resistance, low gas permeability, low permanent set, and compatibility with polar thermoplastics such as PVC and phenolics [S3]. A current 2026 catalogue listing confirms the dominant industrial use case as oil-resistant and wear-resistant sealing O-rings, reflecting the same property package [S5].
Where NBR Fails: Polar Solvents, Ozone, Cold, and Heat
NBR is not a general-purpose elastomer; it is deliberately weak against ketones, esters, and chlorinated hydrocarbons, and is described in current gasket literature as "not resistant to ketones, esters, and chlorinated solvents" [S7]. Specifying an NBR O-ring in a solvent containing methyl ethyl ketone, ethyl acetate, or methylene chloride leads to rapid volume swell and seal failure, regardless of ACN level.
Ozone resistance is "moderate" unless NBR is blended with PVC, the only commonly cited route to ozone-tolerant NBR compounds [S3]. Continuous hot-air service above ~120°C accelerates ageing, and compression set recovery degrades faster than in EPDM rubber or silicone [S3]. For arctic or sub-zero hydrocarbon service, low-ACN grades are required; a 33% ACN grade (medium-ACN, the most common general-purpose type) has a Tg around -25 to -30°C, and 50% ACN grades approach -10°C, restricting low-temperature flexibility [S2].
Selection by ACN Content: Three Practical Bands
Industry practice groups NBR into three ACN bands, and this is the first decision a design engineer should lock down before cure system, filler, and hardness are even discussed. The bands are: low ACN (≈18-25%) for cold-flexible seals and moderate oil contact, medium ACN (≈30-35%) for general-purpose fuel and oil seals including automotive and hydraulic work, and high ACN (≈40-50%) for maximum fuel resistance, low gas permeability, and direct fuel immersion [S2][S3].
Comparing the three bands on four decision criteria makes the trade-off explicit. Oil/fuel resistance: low < medium < high, rising with ACN. Low-temperature flexibility: low > medium > high, falling as Tg climbs with ACN. Tensile and abrasion: medium ≈ high > low, with mid-range ACN typically giving the best balanced mechanical set. Cost: high-ACN grades carry a small premium and lower-volume supply; low-ACN grades are the most widely stocked commodity NBR [S2][S3].
Material Position vs Neighbouring Elastomers
Against the three most common alternatives the position of NBR is clear-cut. Versus silicone rubber: silicone wins the temperature envelope (≈-60°C to +200°C and beyond) but loses badly in oil and fuel, where NBR is the default [S3]. Versus EPDM rubber: EPDM is the polar opposite, with excellent weather, ozone, and hot-water/steam resistance but poor oil resistance, so the NBR/EPDM choice is set by which fluid dominates the service envelope, not by price alone.
Versus natural rubber (NR) and industrial rubber general-purpose families: NBR sacrifices NR-class resilience and tear strength for fluid resistance, and the comparison with polychloroprene (CR) is the closest — CR offers better flame and weathering behaviour with only moderate oil resistance, while NBR covers a wider ACN-tunable oil-resistance range [S2][S3]. Hydrogenated NBR (HNBR) and NBR/PVC blends are the two most common modification routes: HNBR pushes the heat envelope to ≈150°C continuous and adds ozone resistance, and NBR/PVC upgrades ozone and abrasion without the HNBR price step [S3].
Processing, Compounding, and Sustainability Constraints
Standard NBR processes on rubber-industry equipment: internal mixing, calendering, extrusion, and compression or transfer moulding on rubber-platen vulcanising presses, with cure systems adjustable across sulphur, peroxide, and mixed packages depending on the application [S3][S6]. The material is a thermoset elastomer, not a thermoplastic, so post-mould shrinkage must be allowed for in tool design and the part stabilises dimensionally only after a relaxation period that varies with compound and ambient conditions [S6].
End-of-life is a live engineering concern: a 2023 open-access study in Scientific Reports (metrics updated 2026-05-02) proposed a facile devulcanization method to predict the properties of recycled waste NBR, and as of that metrics pull had logged 3,170 article accesses and 2 citations, signalling active but still early-stage research interest [S1]. Practical reuse today is mostly mechanical — grinding to reclaim and blending at 10-30% into virgin compounds for non-critical rubber goods — rather than devulcanization-to-equal-grade, and design for single-use, oil-contact service remains the commercial norm.
Where to Specify, Where to Avoid
Specify NBR for: hydraulic and pneumatic O-rings and rod seals in mineral oil, fuel-system seals (medium/high ACN for gasoline, diesel, biodiesel blends), oil-resistant gaskets and diaphragms, industrial rubber rolls and printing blankets, and NBR/PVC cable jacketing for moderate ozone exposure [S3][S5][S7]. Avoid NBR for: any service containing ketones, esters, or chlorinated hydrocarbons; outdoor exposure to direct sunlight or ozone without PVC or wax protection; continuous dry heat above ~120°C (move to HNBR, FKM, or silicone); and sub-~-30°C dynamic seals where a low-ACN grade cannot meet the Tg requirement [S2][S3][S7].
