Polycarbonate's headline spec — a notched Izod impact strength of 600–900 J/m for high-molecular-weight resin — is the figure that puts it at the top of the amorphous-thermoplastic pack and explains its dominance in safety glazing, riot shields, and machine guards [S2].
What the same datasheet also shows is a tightly bounded chemical envelope: PC tolerates weak acids, weak bases, and neutral oils, but degrades against strong bases, hydrolyses in high-pressure steam, yellows under prolonged UV, and stress-cracks in contact with several organic solvents [S2]. The selection decision is therefore not "PC vs. nothing" but "does the service environment stay inside PC's chemical and thermal box, and if not, which additive package pushes it back inside".
Core Mechanical and Thermal Specs Engineers Anchor On
The three numbers most engineers quote first are notched Izod 600–900 J/m (high-MW unfilled), heat-deflection temperature around 130°C unfilled and ~140°C with glass-fibre reinforcement, and a flexural modulus above 2400 MPa [S2]. Together they put PC in a band where acrylic fails in impact, ABS falls short in heat, and glass wins on modulus but loses on fracture behaviour. Polycarbonate solid sheet is roughly 30× stronger than acrylic and 200× stronger than glass of equivalent thickness, which is why it dominates bullet-resistant and forced-entry applications [S4].
On the low-temperature side, PC stays ductile down to about -45°C and tolerates a continuous service window that spans the full -45°C to ~130°C range for unfilled grades, with reinforced grades pushing the upper end higher [S2]. Density sits at 1.18–1.22 g/cm³ and the coefficient of linear expansion is 3.8×10⁻⁵ cm/°C — close enough to aluminium to allow co-moulded assemblies in some designs, but well above steel or glass, so thermal-expansion mismatch is a real fastener and seal design constraint [S2].
Advantages That Justify Specifying PC
Impact strength is the headline: PC is "virtually unbreakable" relative to glass and most other transparent plastics, which is why it has displaced glass in skylights, window glazing, sign faces, riot shields, enclosures, food-processing sight glasses, medical-device housings, and aerospace transparencies [S4][S5]. The same toughness extends to electrical and electronic parts — PC carries a UL temperature index of 120–140°C after glass-fibre reinforcement and a Comparative Tracking Index that keeps it inside most low-voltage insulation specifications [S2].
Optical clarity is the second pillar: unfilled PC is a near-colourless amorphous polymer with light transmission close to glass, refractive index high enough for ophthalmic and CD/DVD-grade optics, and tintability across the full visible range [S2][S5]. Dimensional stability is the third — low mould shrinkage, low creep below 100°C, and tight tolerances after moulding make PC a go-to for precision instrument housings, and the inherent UL94 V-2 flammability rating is reached without halogenated additives for many unfilled grades [S2]. To see how PC fits into the broader engineering-plastics comparison and the standard modified grades (anti-static, conductive, glass-filled flame-retardant, UV-stabilised, food-contact, chemically resistant), see Polycarbonate types and classifications: aromatic vs aliphatic vs modified.
Disadvantages and Failure Modes to Engineer Around
UV degradation is the most-cited weakness: PC yellows and loses transmission under prolonged solar exposure unless a UV-stabilised cap layer or coextruded protective skin is specified [S1][S2]. In outdoor service expect roughly 25 years of useful life from a quality panel when the UV cap is intact, and far less when it is not [S1]. Hydrolysis is the second hard limit — PC is not suitable for repeated high-pressure steam sterilisation or for hot-water immersion service, and high-temperature humid environments demand a hydrolysis-stabilised grade [S2].
Chemical resistance is a boundary condition, not a single number: PC is attacked by strong bases, by several organic solvents, and it is inherently unsuitable for food-contact applications in many jurisdictions without an explicit food-grade certification [S3][S2]. Flammability is another moving target — unfilled PC reaches UL94 V-2 without additives, but for V-0 or specific fire standards a flame-retardant additive package is required, and that package can compromise impact and optical clarity [S2][S3]. Scratch and abrasion resistance sit at the lower end of engineering plastics — harder than ABS in direct comparison, but still well below coated glass or hard-coated acrylic, so any field-touching surface typically needs a hard-coat or replaceable film [S2]. Cost rounds out the list: PC is roughly double the price of ABS and runs above acrylic and most commodity plastics, which is acceptable in safety-critical parts but pushes designers back to cheaper resins in commodity housings [S1][S3].
Comparison Table: PC vs Acrylic vs ABS vs Glass on Decision Criteria
For spec work, the four criteria that most often decide the resin choice are impact strength, heat-deflection temperature, scratch/mar resistance, and indicative cost. Polycarbonate leads on impact (600–900 J/m notched Izod), matches acrylic on optical clarity, runs roughly 50–100% above ABS on raw cost, and sits between glass (best scratch, worst impact) and acrylic (worst impact of the three polymers) on the toughness axis [S1][S2][S3][S4]. Heat-deflection temperature puts PC at ~130°C unfilled, ahead of ABS (~100°C) and acrylic (~95°C) but well below glass and most engineering thermosets [S2]. Scratch resistance runs the other way: glass and hard-coated acrylic out-perform PC, which is why PC machine guards and sight glasses almost always ship with a hard-coat or sacrificial film [S2].
Where this matters in practice: pick PC where unbreakability, optical clarity, and a -45°C to 130°C service band are mandatory — riot shields, food-processing sight glasses, safety enclosures, medical-device housings, outdoor electrical junction boxes with UV cap, and riot/forced-entry glazing [S4][S5]. Pick acrylic where optical purity and scratch resistance matter more than impact, and where the part is not safety-critical. Pick glass or chemically-toughened glass where scratch, chemical, or thermal endurance dominate and weight is acceptable. Avoid PC for repeated steam-sterilisation, strong-base wash-down, or any application requiring an unqualified food-contact grade [S2][S3].
Standards, Modification Routes, and Sourcing Watch-Points
Most PC grades reach UL94 V-2 flammability without additives, V-0 with brominated or phosphorus-based FR packages, and the reinforced grades carry a UL Relative Thermal Index of 120–140°C — these are the datasheet numbers to anchor a safety-file argument [S2]. Dielectric constant of 3.0–3.2 and arc resistance of ~120 s make PC a standard choice for low-voltage insulators, relay housings, and connector bodies, with the explicit caveat that wet, high-temperature service needs a hydrolysis-stabilised grade [S2]. The published modification routes — anti-static PC, conductive PC, glass-filled flame-retardant PC, UV-stabilised weatherable PC, food-grade PC, and chemically-resistant PC — correspond to the actual spec bands engineers request for the failure modes listed above [S2].
For sourcing in 2026, two signals are worth tracking: a regional supply chain still anchored around bisphenol-A and diphenyl-carbonate via melt transesterification, and an increasing fraction of post-consumer recycled (PCR) PC grades entering the construction and electronics supply chains — both are factors that move lead-time and price more than they move the published datasheet numbers. For context on how PC price and grade selection interact with broader industrial-equipment spec work, see the heat exchanger 2026 spec bands analysis. One final reliability note: PC's weakness under high-pressure steam, strong bases, and prolonged UV is not a manufacturing defect — it is the chemistry of the carbonate linkage — so any datasheet promise of "all-chemical" or "all-UV" PC should be treated as a marketing claim until a specific additive package, cap-layer thickness, and test method are quoted alongside it.
