An unamplified solid-state pressure sensor typically delivers an output in the tens of millivolts at full scale, with span and offset that drift noticeably across temperature, per published sensing-engineering references [S6].
The same die, once paired with analog signal conditioning and a calibration table, can ship as a 0.5–4.5 V ratiometric output, a 4–20 mA loop-powered pressure transmitter, or a digital I2C/SPI word; the difference is the output stage, not the sensing element [S7][S8].
Three Output Tiers, One Sensing Die
Merit Sensor describes a clean three-level taxonomy: an uncompensated sensor is a MEMS die bonded on a ceramic substrate with wire bonds to metal traces, no signal conditioning, no laser-trimmed resistors; a passively compensated sensor has laser-trimmed resistor networks that pull span and offset closer to nominal; a fully compensated sensor has active signal conditioning that delivers a corrected output across the operating range [S4].
Analog Devices frames the same problem in measurement terms: Full-Scale Output (FSO) is defined as the difference in sensor outputs between maximum and minimum applied pressure, and a sensor must be compensated before it can be used as a calibrated instrument [S3]. In other words, the raw die output is not a measurement; it is an input to a measurement. The output stage you buy is the degree to which the vendor has already done that conversion for you.
Raw mV Output: Bare Die for OEM Integration
A raw-output pressure sensor module is essentially a wheatstone bridge on a silicon die, plus mechanical packaging, with no onboard amplifier, no temperature compensation, and no calibration data stored. East Sensor notes that millivolt output sensors typically consume less power than amplified units, which makes them attractive for battery-powered or low-duty-cycle applications [S2].
The tradeoff is electrical: a typical raw output sits in the tens of millivolts FSO, and the host board must add an instrumentation amplifier, a precision reference, an ADC, and temperature compensation to turn it into a usable reading. Merit Sensor gives the canonical example of variable-air-volume building controls, where the sensor is integrated into a control board and the MCU runs compensation in firmware, so buying an uncompensated die is the rational cost decision [S4].
PCB's piezoelectric quick-reference reminds us that a separate class of sensors, the charge-mode and IEPE/ICP dynamic pressure sensors, are likewise raw at the element level; the charge-mode version needs an external charge amplifier, and the ICP version needs a constant-current source to bias the internal FET amplifier, before any usable signal appears [S1][S9].
Amplified Output: Longer Cables, Better SNR, No Calibration
An amplified pressure sensor adds a fixed-gain instrumentation stage to the die, typically producing a 0–100 mV, 0.5–4.5 V, or 0–5 V ratiometric output referenced to a 5 V or 3.3 V supply. The amplification is analog only; there is still no temperature compensation of span or offset, and the calibration coefficients are not applied. [S2]
Renkeer's transducer reference makes the layering explicit: a pressure transducer is built upon a pressure sensor by integrating signal amplification, filtering, calibration, and temperature compensation, with each step being an optional add-on rather than a fixed requirement [S7]. Amplification by itself is just the first of those four steps. The benefit is that the output now drives a 4–20 mA pressure transmitter front end, or a PLC analog input, over cables that would otherwise pick up noise on a 10 mV signal.
For process instrumentation, the next decision is what physical variable to read and at what accuracy; the pressure measurement reference is the right starting point when the application is regulated, while the pressure gauge and pressure calibrator pages cover the on-site verification side of that same loop. Amplified-only outputs are also the natural input to a pressure switch trip amplifier, where the threshold detection is what matters, not the absolute accuracy.
Fully Compensated Output: Calibrated and Ready to Ship
Fully compensated pressure sensors ship with factory calibration coefficients stored either in onboard laser-trimmed resistors (passive) or in a non-volatile memory that an onboard ASIC or external MCU applies to the digital output. The corrected output covers zero offset, span, and a temperature-error function over the specified compensation range, typically 0–70 °C for commercial parts, -40 to +125 °C for industrial and automotive grades [S4][S5].
WF Sensors' side-by-side comparison puts numbers on the two compensation methods. Hardware compensation (thermistor networks, op-amp bias stages, diode linearizers) is real-time, uses no CPU, and handles high-frequency dynamics; software compensation (polynomial or lookup-table correction on an MCU) trades latency and CPU load for flexibility and the ability to model higher-order errors [S5]. Either method lands you at the same endpoint, a calibrated output, but the engineering cost differs.
The practical cost of full compensation, per Merit Sensor, is calibration time: each sensor must be calibrated individually, the equipment takes a long time to reach the required temperatures, and the specialized fixtures are not cheap, which is why a fully compensated sensor costs noticeably more than the same die in amplified or raw form [S4].
Decision Matrix: Raw vs Amplified vs Compensated
The decision reduces to four criteria: integration cost at the host, accuracy required over temperature, signal-chain length, and production volume. [S1]
1) Host integration cost. Raw mV is the cheapest part and the most expensive integration; amplified mV/V or 0.5–4.5 V is the middle ground; fully compensated with digital output (I2C, SPI, or 4–20 mA) is the most expensive part and the cheapest integration [S2][S4][S7].
2) Accuracy over temperature. A raw silicon bridge drifts on the order of -0.19 %FS/°C on span alone; an amplified-only sensor inherits that drift; a fully compensated industrial-grade part is typically specified at ±1 %FS total error band over 0–60 °C, with tighter grades available [S6].
3) Cable run. Raw mV should stay on the host board or under a few hundred millimeters of shielded cable; amplified 0.5–4.5 V can run several meters; 4–20 mA current loop can run hundreds of meters in industrial environments [S2][S7].
4) Volume and packaging. For high-volume automotive fuel-rail duty, Merit Sensor recommends fully compensated parts, because per-unit inline calibration is impractical at that throughput; for low-volume HVAC controllers where the sensor is integrated into a control board, uncompensated dies are the right call [S4].
Where Each Tier Breaks
Raw mV outputs fail any time the host cannot dedicate an instrumentation amplifier, a precision reference, and a temperature channel. They also fail when the customer-side packaging introduces mechanical stress to the die, because that stress shifts the zero point and invalidates any calibration the vendor might have done at the wafer level; Merit Sensor explicitly recommends buying uncompensated and recalibrating after final assembly in that case [S4].
Amplified-only outputs fail any time the application spans more than a few degrees Celsius. A 50 °C rise on a silicon bridge with -0.19 %FS/°C TC span is a 9.5 %FS shift, which is well outside what a process instrument can tolerate without correction. Fully compensated parts fail any time the calibration coefficients assume a temperature range narrower than the field deployment, or when the host assumes a plug-and-play sensor but ships one with active ASIC compensation that still depends on the supply rail being stable and within the ASIC's specified range [S5].
Dynamic piezoelectric measurements follow a different path entirely. PCB Piezotronics' quick-reference guide draws a hard line: ICP-style sensors with onboard microelectronics and charge-mode sensors with external charge amplifiers are the only two viable options for measuring turbulence, cavitation, blast, and engine dynamics, with the ICP variant capped at 356 °F (180 °C) and the charge-mode UHT-12 element rated up to +1,200 °F (+650 °C) [S1]. Kistler's PE-vs-IEPE comparison reinforces that the output-stage decision in dynamic pressure is not about compensation but about impedance conversion and low-noise cable discipline [S9].
Verification and Field Reality
For static or slow-changing process pressures, the verification chain is a pressure calibrator against a dead-weight or electronic reference, and a pressure gauge for the local readout. The compound accuracy spec, often written as ±2 °C or 2 % of reading, is where the fully compensated sensor's real-world error budget is decided; a separate spec-map article on that exact format is worth a read alongside this one [S10].
For dynamic pressures, a single static calibrator is not the right tool; bandwidth, resonance, and charge-amplifier time constant are the parameters that matter, and PCB's frequency-response and range guidance for ICP and charge-mode sensors is the practical reference [S1]. The output-stage choice, raw mV, amplified mV/V, or fully compensated and calibrated, should be made after that verification path is chosen, not before, because the output has to land in something the verification stack can read.
Three signals worth tracking: first, the spread of 0.5–4.5 V ratiometric outputs into more 3.3 V-native industrial MCUs, which would shift amplified-only designs toward digital I2C/SPI at the same price; second, the migration of compensation polynomials from on-die laser-trimmed resistor networks to on-board NVM-driven ASICs, which lowers per-unit calibration fixture cost; third, the renewed interest in charge-mode piezoelectric elements for high-temperature combustion and turbine work, where the +1,200 °F (+650 °C) UHT-12 ceiling still has no semiconductor equivalent [S1][S4][S5].
