Demolition crews increasingly specify wet-mix shotcrete machines for tunnel support, with robotic arms delivering 20–30 m³/h of sprayed concrete to keep operators out of unsupported headings [S5].
Output bands now cluster around 30 m³/h (compact YG-3016 class) and 40 m³/h (YG-4016 class), both with 0.4 m³ hoppers, 90 mm concrete pipes, 50 mm nozzles, and 16 m spray height, while pressure-rated units push main-pump pressure to 15–20 MPa for long-distance conveying [S5].
Wet-mix vs dry-mix: the rebound and dust trade-off
Wet-mix shotcrete cuts rebound from roughly 30% (typical dry-mix) to under 10%, and inside tight demolition headings it cuts dust load enough to keep a crew productive without respirator-grade ventilation at every face [S5][S7].
Dry-mix rigs remain useful for small one-off demolition patches: the material is conveyed dry and water is added at the nozzle, so the package is lighter, the compressor (3–15 m³/min) sets the output, and setup is faster when the patch is a few square meters of overhead concrete [S3][S4]. For a full tunnel cross-section, however, dry-mix loses on rebound cost and on consistent quality, which is why wet-mix has become the default in 2026 underground specs [S5].
Conveying reach is a hard separator: the MEYCO Piccola and MEYCO GM 090 each deliver up to 500 m horizontally with 100 m lift, while a mid-size Aliva 262 stops at 40 m horizontal and 10 m vertical, a direct cap on how far a demolition face can sit from the pump station [S2].
Output, pressure, and aggregate: the three number gates
Output target is the first gate: 4–8 m³/h suits patch repair, 20–30 m³/h suits one-boom robotic tunnel crews, and 30–40 m³/h suits truck-mounted or carrier-mounted rigs working full tunnel sections [S4][S5][S6].
Pressure is the second gate. Concrete discharge pressure on a YG-3016/4016 wet-mix rig is 7.5 MPa, but the main pump circuit (the one that pushes concrete to the nozzle, not the accelerator circuit) is rated 15–20 MPa for long-distance and high-altitude pumping [S5]. For a demolition retrofit where the pump sits 200–400 m back from the face, the higher-pressure pump is mandatory; the lower-pressure discharge figure is a downstream rating, not a conveying rating [S4][S5].
Aggregate size is the third gate. Most wet-mix rotors and pumping cylinders accept up to 15 mm crushed stone; pushing 20 mm aggregate through a standard rotor (350–480 mm diameter) raises block risk and accelerates wear-plate consumption [S3][S5]. On demolition jobs where shotcrete must bond to rough, scabbled concrete, mix-design discipline on the 15 mm limit matters more than chasing higher output.
Air, hose, and compressor matching
Dry-mix and small wet-mix rigs are air-thirsty: published data shows air consumption of 3–4 m³/min at 0.4–0.6 MPa for small rotors, 7–8 m³/min mid-size, and 10–15 m³/min for production rotors at the same pressure band [S3].
Hose inner diameter scales with output: 38 mm for the smallest, 51 mm for mid, 64 mm for production rigs, and dual 51/64 mm options on heavier units [S3]. A common demolition mistake is pairing a 40 m³/h pump with a 38 mm hose, which chokes flow and inflates rebound. The right rule is to size the hose to the rotor diameter (350–480 mm) and to the cited m³/min figure, not to the hose already on the truck [S3][S4].
Working air pressure sits in a narrow 0.4–0.6 MPa band for dry-mix rotors and 0.5–0.8 bar for the wet-mix projection circuit, so the on-site compressor must be sized for both peak m³/min and sustained pressure, or the nozzle will starve at the top of every cycle [S3][S4].
Robotic arm vs handheld: where each earns its slot
Robotic shotcrete arms (360° nozzle rotation, 240° swing, 2900 mm boom telescopic stroke, 20 m³/h theoretical pumping, 7.5 MPa pumping output) are now standard for large demolition-support headings because they keep the operator out of the unsupported zone and double output vs handheld [S1][S6].
The Hitech-style demolition robot platform adds a shotcrete attachment alongside breakers, scalers, scabblers, and buckets, so one base machine handles drill-scale-spray in a single mobilization, which is decisive in narrow tunnel sections where bringing in a separate shotcrete pump is logistically painful [S1]. Handheld shotcrete still fits small patch work, repair crews, and confined corners where the boom cannot reach; its motor-power and hose-size limits make it the wrong tool for full cross-section demolition rehab [S10]. For a related take on mobility and output match across road and concrete work, see the shotcrete selection map for concrete work.
Decision matrix: wet robotic, wet handheld, dry handheld, dry robot-mounted
Four configurations cover nearly every demolition shotcrete brief, and lining them up on the same criteria makes the pick straightforward: [S1]
Configuration A, wet-mix robotic (e.g. truck-mounted YG-4016 or 20 m³/h boom unit): output 20–40 m³/h, rebound under 10%, dust low, main-pump pressure up to 20 MPa, reach 16 m vertical / 25 m horizontal, 360° nozzle rotation, best for full tunnel cross-section and slope stabilization where a crew can be kept off the face [S5][S6].
Configuration B, wet-mix handheld: output 4–8 m³/h, low dust, requires a separate compressor at 10–15 m³/min, fits patch repair and overhead detail work in demolition, cheaper to mobilize but bottlenecks on output [S4][S10].
Configuration C, dry-mix handheld (small rotor, 350 mm, 0.4–0.6 MPa, 3–4 m³/min air, 38 mm hose): output 1–3 m³/h, rebound 25–30%, fits very small patches and one-off demolition where compressor air, not pump flow, is the binding constraint [S3].
Configuration D, dry-mix robot-mounted attachment: combines the Hitech-style demolition robot base with a shotcrete attachment for initial tunnel stabilization, output band lower than wet robotic but uniquely useful where a single modular platform must drill, scale, and spray in one pass [S1].
Standards, safety, and what to verify before signing
Noise from a working shotcrete rig is typically specified at ≤90 dB(A) under ISO 4871, and the electrical enclosure is commonly IP54 per IEC 60529, both numbers worth confirming in the OEM data sheet for any demolition tender [S4].
For demolition use, the binding constraints are not exotic standards but four on-paper numbers: theoretical pumping capacity in m³/h, maximum aggregate size in mm, maximum conveying distance in m (horizontal and vertical), and the main-pump pressure in MPa, not the concrete discharge pressure which is a downstream figure [S5][S6]. Get those four in writing, match them to your face area and rebound target, and the machine choice is mechanical, not subjective.
