Silicon steel selection is a two-axis problem: electrical grade (grain-oriented GO vs non-oriented NGO, plus the sub-grades within each) and lamination gauge (0.23 mm up to 0.35 mm for transformer cores, 0.50 / 0.65 mm for rotating machines). A misread on either axis shows up as watts-per-kilogram wasted as heat, not as a visible failure.
For rotating machines, builders screen on B50 (magnetic flux density at 5000 A/m), typically 1.50–1.70 T for NGO grades used in EV traction motors and industrial drives [S2]. For transformers, the design induction sits at 1.7 T / 50 Hz and core loss is the single number that drives the part number. The relationship is governed by the Steinmetz equation P = k·f^α·B^β, and the constants are what the mill qualifies per grade.
GO vs NGO: pick the steel family first, the grade second
GO (grain-oriented) silicon steel is rolled with a sharp Goss texture {110}<001> and is anisotropic — flux flows easily along the rolling direction. It is built for transformer cores, wound or stacked, operating in the rolling direction [S3]. NGO (non-oriented) has a near-random texture and is roughly isotropic in the plane, which is why it is the default for rotating machines where flux crosses the lamination in multiple directions [S3]. Fives' strip processing line families confirm the split: APL/ACL/DCL/FCL lines feed GO and NGO finishing; HAPL/CAPL/BAL/I-BAL feed stainless; CAL/CGL/CAGL/CGPL/CCL feed carbon [S3].
Use GO when the flux path is unidirectional and the duty is sinusoidal at 50/60 Hz (power and distribution transformers, chokes). Use NGO when the flux path rotates or reverses (induction motors, reluctance machines, EV traction motors, large generators). Mixed or skewed flux paths that don't justify GO texture premiums but need lower loss than commodity 50W470 — high-Si NGO grades around 2.0–3.5 wt% Si — are a common middle ground [S2].
Thickness, core loss and the 0.23 / 0.27 / 0.30 / 0.35 mm gauge ladder
Thinner lamination cuts eddy-current loss roughly with the square of thickness, which is why domain-refined 0.23 mm and laser-scribed 0.27 mm grades command a premium at 1.7 T / 50 Hz. The standard gauge ladder for wound transformer cores is 0.23 / 0.27 / 0.30 / 0.35 mm; 0.50 mm and 0.65 mm remain in use for large hydro generators and lower-frequency traction alternators where stamping cost, stacking factor and mechanical handling matter more than watts-per-kg [S2].
Core-loss values for typical GO grades at 1.7 T / 50 Hz land in bands such as 0.85–0.95 W/kg for 0.23 mm domain-refined (HiB), 0.95–1.05 W/kg for 0.27 mm laser-scribed, and 1.05–1.20 W/kg for conventional 0.30 mm CGO; conventional 0.35 mm is closer to 1.30–1.50 W/kg and is now mostly specified for distribution transformers under 1 MVA [S2]. NGO grades carry separate part numbers keyed on a W-per-kg at 1.5 T / 50 Hz — common industrial designations include 50W470, 50W600, 50W800, 50W1000 and 50W1300, where the trailing number is the loss in W/kg [S2]. Stacking factor typically runs 0.95–0.97 for 0.35 mm gauge, 0.94–0.96 for 0.27 mm, dropping further as gauge gets thinner.
Si content, insulation coating and annealing windows
Silicon content is the main lever for resistivity and magnetic softness. Conventional GO sits at roughly 3.0–3.4 wt% Si; high-grade HiB can push past 3.4 wt% [S2]. NGO spans roughly 1.0–3.5 wt% Si — higher Si cuts loss but worsens punchability, so motor-lamination producers trade Si for stamping tool life.
Insulation coatings are not interchangeable. GO is shipped with a forsterite (Mg2SiO4) glass film from the high-temperature anneal plus a phosphate-based tension coating (C-5, S, or the newer chrome-free T or L types) that puts the strip under compressive stress to lower no-load loss. NGO is shipped with a semi-organic or inorganic insulation (chromate, phosphate, or chrome-free equivalents) chosen for interlaminar resistance — typical target is ≥ 20 Ω·cm² per lamination at 1 MPa contact pressure. Anneal selection (full decarburising anneal for NGO vs the two-stage 800 °C decarburisation + 1200 °C high-temperature anneal for GO) is fixed by the mill route and is not a buyer choice [S3].
Decision matrix: pick by duty, not by catalogue
Step 1 — flux topology. Unidirectional 50/60 Hz → GO family. Rotating or reversing → NGO family. Step 2 — design induction. GO cores are designed near 1.7 T to balance loss vs magnetising VA. NGO motor designers target B50 from the torque-per-ampere curve, often 1.4–1.6 T. Step 3 — gauge ladder. 0.23 / 0.27 mm GO if watts-per-kg dominates the TCO; 0.30 / 0.35 mm GO if core cost dominates. 0.35 / 0.50 mm NGO for industrial motors, 0.27 / 0.30 mm for high-speed EV traction motors where fundamental frequency pushes 700–1000 Hz. Step 4 — coating. C-5 or equivalent for wound cores; chrome-free for any food-contact or toy end-product; inorganic for large hydro stator cores. Step 5 — stacking factor, burr height, and weld- or bond-access plan. [S1]
Material choice is wider than just silicon steel — packaging the right lamination against a linear guide or crossed-roller guide for winding machines is the kind of cross-discipline gate that breaks first in production.
Failure modes and what the spec sheet does not tell you
Three real failure modes show up in service. (1) Magnetostriction noise: GO grades, even at 1.7 T, can produce 90–110 dB at the second harmonic of mains in wound cores; switching to domain-refined or tension-coated grades is the standard fix. (2) Burr-driven shorts: punching burr over 25–30 µm on 0.27 mm gauge will lift interlaminar resistance and add 5–10% to no-load loss. [S2]
Worked check for an EV traction motor at 800 Hz fundamental: pick a 0.27 mm NGO grade with low-loss thin-gauge variant, B50 ≥ 1.55 T, designed B at peak torque around 1.4 T to keep iron loss under ~10 kW at the rated point. Worked check for a 1000 kVA distribution transformer: 0.30 mm HiB GO, C-5 coating, design 1.70 T, target no-load loss under 1.0 W/kg.
Standards, sourcing and what to ask the mill
GO grades are commonly traded under GB/T 2521, JIS C 2553, ASTM A876 and IEC 60404-1 designations. NGO electrical steel sits under GB/T 2521, JIS C 2552, ASTM A677 and IEC 60404-1. Ask the mill for the test method and induction level behind the published loss number — a 50W470 quoted at 1.0 T / 50 Hz is not the same grade as 50W470 quoted at 1.5 T / 50 Hz. For corrosive or wet-end applications — pumps, hydroelectric stators, submerged service — silicon steel is the wrong family; switch to silicon-bearing but corrosion-engineered alloy steel plate, as outlined in our best steel for water treatment guide. [S3]
Watch for two non-magnetic substitutes. Specifying them in place of electrical steel is a category error, not an upgrade.
Logistics, mill lead times and verification gates
Mill lead time for HiB GO 0.23 mm typically runs 6–10 weeks ex-works Asia, with 0.30 / 0.35 mm NGO often available in 3–5 weeks ex-stock for standard widths (1000 / 1200 / 1250 mm) [S2]. Third-party verification should cover thickness profile (target ±0.020 mm for 0.30 mm gauge), surface insulation resistance (≥ 20 Ω·cm² at 1 MPa), core loss at the quoted (B, f) point, and a decarburisation / grain-size cross-section on first article. A useful second-article gate is the Epstein-frame test per IEC 60404-2 on every heat, not just the development batch.
Watch also for chrome-free tension-coating approvals at major transformer OEMs — they are migrating line by line through 2025–2026 and the move reshapes the coating suffix on every new RFQ.
