Guard locking falls into two distinct engineering regimes under EN ISO 14119: a spring-applied, power-to-release (closed-circuit) or bistable lock with conditional unlocking for personnel protection, and a power-to-lock (open-circuit) magnetic lock with unconditional unlocking for process protection [S2][S4].
The selection pivots on a single arithmetic comparison: if the time an operator needs to open the guard and reach the hazard is shorter than the machine stopping time, safe guard locking for personnel is mandatory; if the access time is longer, process locking suffices [S2][S3].
Two Locking Principles, Two Safety Cases
EN ISO 14119 recognizes four physical arrangements but the safety argument collapses them into two operating principles [S4]. Closed-circuit current principle: a spring drives the bolt into the locked position, and energizing a solenoid retracts it; loss of power keeps the door locked. Open-circuit current principle: a solenoid (or permanent magnet plus solenoid) holds the bolt against a spring; loss of power releases the door. Bistable is treated as a closed-circuit variant because the lock state does not change on power removal [S2][S4].
Closed-circuit designs up to PL c are standard, and PL d is reachable with fault exclusion such as a mechanically secured safety bolt [S2]. Open-circuit magnetic locks cannot deliver conditional unlocking because the magnet cannot hold against a stop command, which is exactly why they are confined to process protection [S3][S4].
Conditional vs Unconditional Unlocking
Conditional unlocking requires the safety controller to verify that hazardous functions have stopped (safe torque off, zero speed, brake set) before releasing the bolt; unconditional unlocking releases on operator demand and the resulting guard-open event then generates the stop command [S2][S4].
Unconditional unlocking is acceptable only when the time from guard release to the operator reaching the danger zone exceeds the machine run-down time. DIN EN 415-5:2010-04, section 5.2.2.1.7, uses a one-second stop time as the packaging-machine threshold below which process locking is usually adequate [S3]. For personnel protection, dual-channel OSSD outputs must be used, with short-circuit detection that shuts outputs down without allowing unintended gate opening even under fault [S2].
Device Type 1-4 Coding and Tamper Resistance
EN ISO 14119 classifies interlocking devices into four types by actuation principle and coding level [S2]. Type 1 is mechanical, uncoded; Type 2 is mechanical, coded; Type 3 is non-contact (e.g. inductive), uncoded; Type 4 is non-contact, coded (typically RFID). Types 1 and 3 require additional manipulation protection because a simple magnet or screwdriver can defeat them [S2].
High-level coded actuators (Type 2/Type 4 with RFID, e.g. 1-of-many or unique code per ISO 14119 coding levels) are the baseline for personnel-protection applications where the standard is enforced strictly, because each actuator has an individual signature that defeats the bypass magnet trick [S1][S2]. In brownfield retrofits on packaging lines, mechanical Type 2 with a coded tongue remains common because it tolerates misalignment and washdown better than inductive Type 3.
Decision Matrix: Personnel vs Process Locking
The four decision criteria a specifier needs on a single page are: locking principle, unlocking behaviour, performance level, and dual-channel OSSD [S2][S3][S4]. Compare them side by side below.
Locking principle: personnel protection uses spring-applied, power-to-release (closed-circuit) or bistable; process protection uses power-to-lock (open-circuit) electromagnet. Unlocking behaviour: personnel protection is conditional on a verified safe stop; process protection is unconditional on operator request. Performance level: PL c minimum, PL d with fault exclusion for personnel; PL d or higher is typical where ISO 13849-1 risk assessment requires it, while process locks are often treated as non-safety SRP/CS since the safety function is upstream. Dual-channel OSSD: mandatory for personnel protection with short-circuit detection; not required for process-only magnetic holders [S2][S3][S4].
Rule of thumb on the access-time arithmetic: when access time minus stopping time yields a positive buffer, process locking is acceptable; when it is negative, only conditional-unlocking personnel locks satisfy EN ISO 14119, and the system must reach a defined safe state before the bolt retracts [S2][S3].
Integration With the Safety Control System
Guard locking for personnel protection is part of the safety-related parts of control systems (SRP/CS) covered by ISO 13849-1, so the lock's lock/unlock feedback contacts, door-position contacts, and the solenoid driver all roll into the same Performance Level calculation [S1]. The safety controller must explicitly drive the unlock command, and a single-fault tolerant architecture (Category 3 or 4 per ISO 13849-1) is the usual baseline for PL d [S1].
OSSD (output signal switching device) test pulses are required to detect cross-wiring and short circuits on the lock outputs, and a single OSSD pulse must not release the bolt; pulse widths of a few hundred microseconds are filtered out by the lock's solenoid driver, so the interlock stays physically engaged even if a channel drops [S2]. On brownfield retrofits, electromechanical locks with mechanical-coded actuators and separate force-guided position contacts are easier to validate against legacy wiring than RFID Type 4, which often needs a dedicated safety bus or safety over EtherCAT/PROFIsafe gateway.
Common Failure Modes and Misapplications
Operator bypass with a separately sourced magnet remains the single most common defeat on inductive Type 3 systems; the fix is either a coded Type 4 RFID actuator or a high-level coded mechanical actuator with a unique physical key pattern [S1][S2]. A second frequent error is specifying an open-circuit magnetic lock where the stop time of the connected hazard exceeds the access time, which the standard explicitly forbids because the door can release mid-run-down after a power dip [S3][S4].
Misalignment failures on mechanical Type 1/2 locks show up as nuisance trips after thermal growth or door sag; the practical fix is a tolerance analysis at the design stage plus periodic proof-test intervals of typically six to twelve months depending on the PL target and operating cycles per ISO 13849-1 service-life graphs [S1]. Stacking a process lock and a personnel lock on the same guard is a recurring misapplication, because two locks in series defeat the conditional-unlocking logic, and the safety controller will not be able to verify which bolt is actually engaged.
Documentation and Standards Trail
The primary normative references are EN ISO 14119:2014 (interlocking devices associated with guards, Type-B2 standard) and ISO 13849-1:2023 (safety-related parts of control systems, including PL a-e and Categories B, 1, 2, 3, 4), with DIN EN 415-5:2010-04 governing packaging-machine stop-time assumptions [S2][S3][S4]. For packaging lines, DIN EN 415-5:2010-04, section 5.2.2.1.7, anchors the one-second stop-time rule used to decide between process and personnel locking [S3].
