An HRG scheme at the mine substation limits line-to-ground fault current to about 5 A, low enough that a single ground fault will not trip the upstream breaker and shut a conveyor, pump or hoist [S3][S7].
That 5 A ceiling is the design target: the neutral-grounding resistor (NGR) is sized so the bolted line-to-ground current stays under 10 A, and a per-feeder ground-fault relay (GFR) handles detection and selective tripping [S1][S3].
Why HRG Fits a Mining MCC Architecture
Mine power is fed from long, radial feeders with high motor density, and a single solidly-grounded ground fault on a 480 V or 1000 V MCC bus will pull thousands of amps, trip the main, and black out a section [S1]. HRG trades that trip for a controlled, resistor-limited fault and an alarm, which is exactly the behaviour mine operators want for ventilation, dewatering and conveyor systems that cannot stop on a whim [S1][S7].
Eaton's HRG product line explicitly markets the scheme as a way to "continue to operate with temporary or permanent ground faults," a direct acknowledgement of the mining use case where unplanned trips cost production and ventilation time [S4][S7]. Bender's mine-specific guidance reaches the same conclusion: the NGR restricts ground-fault current to a level that protects the resistor, the cable and the motor winding without forcing a trip [S2].
Component Stack: NGR, GFR, CT, Pulser
A working HRG + ground-fault relay package on a mining MCC is built from four building blocks, each with a defined job [S1][S5]:
1. Neutral-Grounding Resistor (NGR): connected between the transformer secondary neutral and earth; sized to limit the bolted line-to-ground current to roughly 5 A on 480 V systems and typically under 10 A on 1000 V systems [S1][S3]. Bender notes the resistor is the single point whose failure takes the whole scheme down, so its thermal rating (10 s or extended) is a real spec line [S1].
2. Zero-Sequence CT (or three-phase summating CT): installed on each MCC branch feeder; the GFR uses the residual current to decide whether the branch has a ground fault [S1][S5].
3. Ground-Fault Relay (GFR): set well below the NGR-limited ceiling (typical pickup 1-3 A primary, time delay coordinated with the upstream) so a branch fault can be selectively identified and either tripped or annunciated [S1][S5].
4. Ground-Fault Locator / Pulser: optional wiggler that injects a coded low-frequency signal through the NGR so a portable receiver can pinpoint the faulted feeder in a long MCC lineup without walking the mine [S1].
The IEEE 142-2007 "Green Book" is the standard mine specifiers cite when they justify HRG on continuity-of-service grounds, and Bender's HRG technical note references it directly for the list of system benefits [S1].
HRG vs Solidly Grounded vs Ungrounded: A Decision Matrix
Three wiring choices compete for the same MCC bus, and they behave very differently on the first ground fault [S1][S3][S7]:
Solidly grounded: maximum fault current (often 10-40 kA on a 480 V MCC), instantaneous trip on the first ground fault, high arc-flash incident energy, and exposed personnel risk at the fault point [S1][S3].
HRG: roughly 5 A limited by the NGR, no auto-trip on the first fault, low arc-flash energy at the fault point, but the unfaulted phases ride at line-to-line voltage until the fault is cleared, which stresses the winding insulation [S1][S3].
HRG wins on continuity of service and on personnel touch-voltage, at the cost of needing a separate GFR on every MCC branch and the discipline to actually repair the fault instead of letting it ride for weeks, a real-world failure mode veteran electricians flag in the field [S1][S3].
Where It Fits, Where It Does Not
HRG is the right call for a 480 V or 1000 V mine MCC bus feeding medium-voltage downstream transformers, large induction motors (compressor, SAG mill, pump, fan), and conveyor starters where a single trip would idle a crew or a face [S2][S7]. Bender lists mining, healthcare, data centres and process plants as the core HRG verticals, and the mining application note pairs the scheme with a feeder-by-feeder GFR so the source of the fault can be located without a full substation walk-down [S2].
HRG is a poor fit on the portion of the mine load that requires line-to-neutral single-phase loads, because during a ground fault the neutral shifts and any L-N connected equipment sits at line-to-line voltage, which is why the IEEE 142-2007 framework and NEC 250.36 both require line-to-neutral loads to be served through an isolation transformer in an HRG system, a hard rule, not a recommendation [S1][S3].
Sizing, Settings, and Failure Modes
Resistor sizing: pick the NGR so the bolted L-G current at the transformer secondary is in the 1-10 A band; the 5 A figure is the most commonly cited single value for 480 V mine MCCs and lines up with Bender's "typically 10 A or less" guidance [S1][S3].
Coordination: GFR time delays are graded so the branch relay trips (or alarms) before any substation-level ground-fault element, which is what gives HRG its selective-detection reputation [S5].
Failure modes: a shorted NGR turns the system into a solidly grounded system with no warning; an open NGR silently turns it into an ungrounded system; both states defeat the scheme, so resistor continuity is monitored separately on every modern HRG panel [S1][S7]. Bender's HRG technical note flags this as the single reliability risk that HRG designs must actively manage [S1].
Standards, Sourcing, and Field Reality
IEEE Standard 142-2007 (Green Book) is the umbrella recommendation; NEC 250.36 covers high-impedance grounded neutral systems in the 480-1000 V range and lists four hard conditions: qualified persons only, continuity of power required, ground detectors installed, no line-to-neutral loads served [S1][S3]. The Chang 2016 paper on low-voltage HRG in industrial plants documents exactly the per-MCC-branch GFR topology that mining specifiers use, with each motor starter cubicle carrying its own ground-fault element rather than relying on a single main-level relay [S5].
On the supply side, the HRG + GFR + zero-sequence CT package is sold as an integrated panel by Eaton's low-voltage power distribution group, and as a configurable relay + CT + resistor kit by Bender for both grounded and ungrounded mine feeders [S2][S4][S7]. Eaton's PSEC video on HRG is one of the better walk-throughs of the scheme, covering trip vs alarm-only operating modes and the NGR thermal rating question in roughly 5 minutes [S4].
For deeper reading on the relay side, the ground-fault relay fundamentals page covers how the GFR sits inside an MCC cubicle and why the CT ratio and tap setting drive pickup accuracy, while the insulation-resistance testing page explains how commissioning crews verify that an HRG system's first-fault performance matches the coordination study.
Trackable signals worth watching over the next procurement cycle: the rollout of arc-flash-resistant MCC buckets with integrated GFRs from the major low-voltage OEMs, and the slow migration of mine power studies from NEC 250.36 minimums to IEEE 1584-2018 incident-energy calcs that already assume HRG where it is installed.
