In an AMCW phase-shift rangefinder the measured phase is proportional to 2·time-of-flight·f_mod, which means the unambiguous distance equals c/(2·f_mod) and the longitudinal resolution improves as f_mod rises; the two figures are coupled by a single design knob, the modulation frequency [S3].
Choosing f_mod therefore means trading unambiguous range against millimetre-class precision, and the most common solution documented since 2019 is multi-frequency modulation combined with pulse time-of-flight, a hybrid that has demonstrated 3 mm precision over 1.5 km in fibre [S4].
Why the Single-Frequency Limit Exists
For a sinusoidally amplitude-modulated laser the phase of the returned light repeats every 2π, so beyond one modulation wavelength the meter cannot tell whether the target is at d, d + c/(2f), or d + 2c/(2f); this periodicity defines the unambiguous range and is the defining ambiguity of the phase-shift method [S3]. RP Photonics summarises the trade directly: "higher modulation frequencies can result in a higher spatial resolution", at the cost of a shorter unambiguous window [S3].
The LiDAR literature puts the same constraint in terms of AMCW geometry: the unambiguous range varies with 1/f_mod and the resolution scales with f_mod, so simply lowering f_mod is not an option when both figures matter [S1]. The two limits can be expressed as a ratio, so the design problem is normally framed as "how many frequencies, and at which spacing".
Multi-Frequency Schemes: Coarse-Fine vs Staggered
Two multi-frequency architectures dominate the published work. Coarse-fine ranging uses a low-frequency "coarse ruler" and a high-frequency "fine ruler" with a large frequency ratio, but demands a flat system response across the full band; staggered multi-frequency ranging uses a small frequency difference between rulers and avoids the wideband response requirement, which is why staggered has become the default in recent carrier-phase designs [S2].
Carrier-phase implementations published in 2022 used a multi-frequency modulation depth and stagger coefficient chosen by simulation, then demonstrated linearity and 1 cm precision at 20 dB SNR over a 300 m range, with simultaneous velocity extraction from the carrier [S2]. Direct trade-off values are visible in the table below.
Comparison of Disambiguation Strategies
A direct comparison of the main approaches documented in the source material, against the four engineering criteria that matter on a spec sheet: [S1]
Single-frequency AMCW: unambiguous range = c/(2f_mod), resolution scales with f_mod, hardware = one modulator + one detector, motion sensitivity = none of the published sources flag this as a concern for static targets [S3].
Coarse-fine dual frequency: unambiguous range ≈ product of the two c/(2f) windows (Chinese-academy scheme, 300 m demonstrated), resolution = finer ruler, hardware = wideband response required across the coarse-fine gap, motion sensitivity = high if rulers are time-shared [S2].
Staggered multi-frequency: unambiguous range ≈ beat wavelength set by smallest Δf, resolution = highest carrier in the stack, hardware = one laser + one modulator with simultaneous transmission, motion sensitivity = low because all rulers are co-transmitted [S2].
Hybrid TOF / phase-shift: unambiguous range set by the pulse repetition interval (1.5 km in fibre demonstrated), resolution = phase-shift term, hardware = RF-modulated pulsed laser via a frequency-shifted feedback loop, motion sensitivity = the design explicitly aims to combine long unambiguous distance with RF phase accuracy [S4].
Hybrid TOF/Phase-Shift and Chirped Approaches
The hybrid method reported by Yang et al. (2019) uses a falling-edge RF-modulated pulse from a frequency-shifted feedback loop; the TOF envelope provides the long unambiguous distance while the RF carrier provides fine phase, and the experimental result is 3 mm precision at 1.5 km in-fibre, corresponding to a relative precision of 2×10⁻⁶ [S4]. That relative figure is a useful benchmark: it implies the unambiguous range was set by the pulse structure rather than by c/(2f_mod) of the carrier alone.
Chirped amplitude modulation is an alternative route that sweeps f_mod across a band rather than stacking discrete tones; a 2023 paper in Optics Express shows that as the modulation frequency sweeps, the unambiguous distance window sweeps with it, so a single chirped sweep can disambiguate without a second fixed frequency [S1]. For practical laser diodes, Optics for Hire notes that direct current modulation is feasible "in the megahertz domain or even higher", and electro-optic modulators reach "many megahertz or even multiple gigahertz", giving the designer the band needed for both coarse and fine rulers [S5][S3].
How Far Does Each Frequency Reach?
Working backwards from common modulation frequencies gives the unambiguous range directly: at 10 MHz the unambiguous window is c/(2·10⁷) ≈ 15 m; at 1 MHz it is ≈ 150 m; at 100 kHz it is ≈ 1.5 km; and at 1 GHz the same formula yields 0.15 m, which is why sub-millimetre phase-shift meters have to be used over short paths or paired with a coarse ruler [S3]. RP Photonics gives a representative example for radar-class signals: at 6 GHz, "very small distance changes can be measured", with the ambiguity window of roughly 0.025 m making it a fine ruler only [S3][S6].
The relationship is also visible in a published phase-difference system with about 1.5 GHz of modulation bandwidth, where the wide bandwidth is used specifically to suppress phase-difference drift and keep the fine ruler stable enough to close the gap with the coarse ruler [S8]. For industrial laser distance meters, the same trade-off is reflected in the laser distance meter design envelope, where typical f_mod values of a few MHz to a few hundred MHz are chosen so that c/(2f) lands inside the instrument's rated measurement range. Surveying and construction variants covered in the construction machinery and equipment family typically use the lower end of that band, trading resolution for a 100–300 m unambiguous range, and then rely on a coarse pre-measurement (often a separate pulsed channel) to extend the absolute range.
Selecting f_mod on a Real Spec Sheet
A defensible spec starts by fixing the required unambiguous range, then back-calculates the lowest f_mod in the set, then picks the highest f_mod from the required millimetre-class resolution, and finally verifies that the ratio of the two fits within the detector, modulator, and laser-diode bandwidth. The MDPI/Aerospace Information Research Institute group demonstrates the procedure: choose stagger coefficient, modulation depth, and SNR such that the resulting precision target (1 cm at 20 dB SNR over 300 m) is met before committing to a hardware build [S2]. For diode lasers the upper limit is set by signal distortion, "the optical signals in semiconductor lasers become distorted when these lasers are modulated at high frequencies", so a 1.5 GHz-class modulator or an external EOM is often the practical answer [S2][S3].
When the application is moving targets, the time-sharing of multiple rulers becomes unsafe: "if multiple frequencies are transmitted through time-sharing, the position of the target will change during the measurement process, and the results from multiple gauges cannot be aligned", which is why simultaneous multi-frequency transmission is the default in the recent carrier-phase literature [S2]. The same rule shows up in the dual-frequency RF-modulated pulse design, where the long unambiguous window of the pulse is intentionally paired with the RF phase to avoid the alignment problem during scanning [S4].
Limitations and Failure Modes
Three failure modes recur in the published work. First, harmonic generation when the modulation frequency is switched suddenly degrades phase detection in switched multi-frequency systems, so simultaneous transmission is preferred over time-sharing for moving targets [S1]. Second, reducing f_mod to remove ambiguity also reduces resolution, so the disambiguation must come from a second, lower-frequency ruler rather than from a single tone [S3]. Third, semiconductor lasers distort at high modulation frequencies, so an external electro-optic modulator is often needed when the design demands hundreds of MHz or more [S2][S3].
A practical way to think about the boundary is the following: the phase-shift method is well suited to medium distances with diffuse reflection, but it loses its advantage when the target is a weak diffuse reflector at long range or when the required resolution drives f_mod so high that the unambiguous window is shorter than the target's expected stand-off distance [S3]. The same constraint is reflected in the spec of a laser distance sensor for industrial positioning, where the unambiguous range is typically quoted as half the modulation wavelength and the fine-resolution figure is quoted in millimetres or sub-millimetres.
Trackable Signals and Verifiable Next Nodes
Three verifiable signals can be monitored over the next review window. First, the publication trail of carrier-phase multi-frequency systems targeting the 1 cm @ 300 m class with simultaneous velocity output, where the simulation-driven design of stagger coefficient and modulation depth is the documented path [S2]. Second, hybrid TOF/phase-shift systems extending beyond the 3 mm @ 1.5 km fibre benchmark reported in 2019 into free-space and field-deployable hardware [S4]. Third, chirped AMCW LiDAR moving from the Optics Express 2023 demonstration toward integrated silicon-photonics modulators, where a single sweep removes the need for a stacked-ruler architecture [S1]. For complementary hardware selection criteria (measurement range, accuracy, principle, beam divergence, laser class, IP rating), the RP Photonics buyer's guide lists 22 laser rangefinder suppliers and a structured selection checklist that lines up directly with the f_mod-vs-range trade-off above [S3].
