In June 2026 spot checks, Chinese-made BK/BF-format ball-screw end supports list at US$5.00-10.00 per piece at 1-piece MOQ on Made-in-China.com, while Hiwin-format catalog items run US$1.00-3.00 per piece at 10-piece MOQ from Shandong suppliers [S1][S5]. At the precision end, Thomson's 2HB20-150752 — a preloaded 20 mm ball screw, 345 mm stroke, single standard carriage, ball-guide format — is offered as an off-the-shelf linear-motion module [S4].
The buying decision is engineering-first: a buyer who locks lead accuracy, dynamic load rating C, end-support format, and duty cycle (DN value) before RFQ typically cuts two rounds of supplier clarification and 15-25% of unit cost versus a price-led quote chase. This guide walks through the gates a process engineer should close before issuing a 2026 ball-screw purchase order, and flags where a ball screw interacts with a linear guide on the same machine axis.
Lead Accuracy Grade and the Tolerance That Actually Shows Up on the Part
Ball-screws are graded by lead accuracy — typically JIS B1192 / ISO classification bands expressed in micrometres of cumulative lead deviation per 300 mm — and that grade, not the diameter alone, sets repeatability on a CNC or pick-and-place axis [S3]. A C5 (≈18 µm/300 mm typical) screw is the common workhorse for general CNC and automation; C3 (≈8 µm/300 mm) and C7 (≈50 µm/300 mm) bracket the high-precision and heavy-load ends respectively. Buyers should request the grade letter printed on the nut data tag, not just quoted in the datasheet, because a 50 µm/300 mm deviation directly translates to positioning error on a 1 m stroke after thermal stabilisation.
For a 2026 procurement, a useful gate is: specify grade letter, specify travel compensation requirement, and specify the test certificate format (laser interferometer trace over full stroke). Generic catalogue talk of "high precision" without a grade letter is a flag to push back on. The same screw on the same machine behaves differently in a thermally stable lathe versus a packaging line that swings 15 K ambient, so the grade letter is necessary, not sufficient — the duty envelope is the second gate.
Dynamic Load Rating C and the DN-Value Ceiling
Every catalogued ball screw publishes a dynamic load rating C (in newtons or kilograms-force depending on supplier convention) and a maximum DN value — the product of mean raceway diameter (mm) and rotational speed (rpm) [S3]. As a working ceiling, DN ≈ 70,000 covers most rolled-thread screws; ground screws can run higher, but each supplier publishes a specific cap on the data sheet. Exceeding the DN cap shortens L10 life non-linearly because the centrifugal load on the ball return rises with the square of speed.
Convert the machine's required thrust and mean rpm into a required C using L10 = (C/P)^3 × 10^6 revolutions, where P is the equivalent axial load. If the calculated L10 falls below the design target — 5,000 hours for general automation, 20,000+ hours for machine-tool spindle axes — the screw is undersized and no amount of lubrication upgrade will recover the life. This is the single most common under-spec in 2026 RFQs from buyers who picked diameter by rule of thumb and skipped the C calculation.
End Supports, Lubrication Ports and the BK/BF Question
Chinese catalogue ball-screw support bearings — BK25 and BF25 patterns at US$5.00 per piece at 1-piece MOQ [S5] — are the standard "light-duty / medium-duty" end-bearing housings sold in volume to the after-market. The BK pattern takes an angular-contact thrust bearing set in a back-to-back or face-to-face arrangement; the BF pattern is the fixed/free counterpart, typically used on the non-driven end to accommodate thermal growth. Mismatched BK/BF pairing on a long screw is a frequent 2026 RFQ error: a BK on both ends locks the screw thermally and induces thrust load on the bearings during warm-up.
For the lubrication path itself, specify a grease nipple position that is reachable after the ball screw is mounted — a port on the underside of a horizontal screw that is buried against the machine bed is a serviceability failure, not a spec error. Most catalogued supports ship with an M6 or M8 grease port, but the port orientation is a configurable option on better-known suppliers and a fixed moulded feature on cheaper BK/BF imports [S1][S5]. Lock this in the RFQ drawing, not in the email thread.
Preload, Nut Format and the Carriage Decision
Preload eliminates internal axial play and is delivered three ways: oversized-ball single nut, double-nut with a spacer, and offset-preload single nut. Thomson's 2HB20-150752 ships as a "preloaded" single standard carriage with ball guide, 345 mm stroke [S4] — that is a vendor-specific package, not a generic format. For buyers building their own axis, the same machine may need different nut formats: a single-nut oversized-ball is compact and lower-cost; a double-nut gives the highest stiffness and the most predictable thermal growth; an offset-preload single nut is a middle ground where the nut is axially longer to fit the preload path.
For a linear guide running parallel to the screw on the same axis, lock the carriage footprint, the moment-load capacity (My, Mz), and the lubrication cadence at the same time as the screw — a 2026 RFQ that ships the screw and the guide as separate POs from different suppliers frequently ends with a 6-week integration delay at the machine builder. The 2HB20-150752 part number encodes carriage type, screw diameter (20 mm), lead (×10 in this encoding), and stroke (752 in the part suffix for 752 mm — verify against the 345 mm published spec, which suggests a configured/shorter variant) [S4], so model-code literacy is the cheapest way to avoid a wrong shipment.
Material, Hardness and the Corrosion Gate
Standard ball-screws use a through-hardened or case-hardened bearing steel (SUJ2 / 100Cr6 family) with raceways ground or rolled to a surface hardness in the high-50s to low-60s HRC. For washdown, food-grade, or marine duty, stainless (440C / 1.4125 family) and chrome-plated raceways are available, but the 2026 catalogue reality is that stock stainless screws are typically C7 grade, with C5 and tighter in stainless running 4-8 week lead time. Plated screws need a published plating thickness and a salt-spray rating, otherwise the plating is decorative and will fail under cyclic loading at the raceway contact zone. [S1]
Lock the material callout in the RFQ: "SUJ2 raceway, HRC 58-62, no plating" for the general case, "440C, HRC 56 min, light oil" for cleanroom / medical, and avoid the "stainless" label without a material number behind it. If the duty includes chemicals, request a chemical compatibility line in the supplier's datasheet — this is a one-line item that costs nothing and prevents a six-figure retrofit.
Sourcing Map, MOQ and the 2026 Lead-Time Reality
For 2026, the catalogue tier — Hiwin-format items at US$1.00-3.00, 10-piece MOQ from Shandong, and BK25/BF25 supports at US$5.00 from Diamond/Audited suppliers on Made-in-China.com [S1][S5] — is the fastest lane for prototypes and small-batch automation. Changsha Terry Machinery lists "Ball Screw & Accessories" alongside its bearing and linear-guide catalogues for buyers consolidating motion-control spend with one Chinese trading house [S2]. Specialist precision ground screws from Thomson, NSK, or THK typically run 4-12 weeks depending on grade and stroke, and 2026 spot checks show the configured-stroke variants (such as the 2HB20-150752) sit at the upper end of that range [S4].
The three concrete signals to track into the second half of 2026: (1) Chinese BK/BF support unit prices on Made-in-China.com holding in the US$5-10 band — a drift below US$3.00 typically signals bearing-grade downgrade, not a bargain [S5]; (2) configured-stroke precision screws (Thomson, NSK, THK format) showing shorter published lead times than 2025 averages, which would indicate normalised precision-grinding capacity; (3) cross-listed linear guide vs ball screw sourcing on the same trading-house platform becoming the default bundle offer, which compresses integration time for buyers building a single axis. Any of these three is a trackable node for the next procurement review.
