A flared trough screw conveyor is a U-trough variant whose top opening is flared outward, increasing the cross-section above the screw flight so cohesive, viscous, or bridging materials can enter and discharge without packing against the trough walls [S2][S3].
It is selected when the bulk solid is non-free-flowing (moist filter cake, dewatered sludge, animal-feed mash, ash with binder, sticky biomass) where a conventional U-trough would rat-hole or stall [S3][S5]. The geometry borrows from standard CEMA practice: diameters 6 to 24 inches, lengths up to 150 ft, and screw speed commonly 30 to 60 rpm (up to 150 rpm for certain free-flowing materials) [S1][S5].
Why a flared trough, not a standard U-trough
The top opening of a flared trough is wider than a U-trough, allowing sticky or viscous bulk materials to enter the trough more easily and reducing the bridging that occurs when cohesive solids arch over a narrow opening [S2]. Many mixing screw conveyors use flared troughs because the additional space above the screw creates more room for bulk materials to be mixed, so the screw is loaded primarily as a conveying element with a secondary kneading action rather than as a positive seal [S2].
For a standard horizontal screw, throughput is governed by Throughput = cross-sectional area x linear speed x bulk density x slope factor, and the cross-sectional area is the bottom portion of a circle at the percent fill the supplier specifies, typically 30% for normally flowing materials and 15% to 40% at the extremes [S1]. A flared trough raises the effective fillable volume above the flight and changes the geometry so the supplier must re-state the percent fill rather than simply re-using a U-trough rating [S1].
Inclined performance must also be re-rated: capacity drops roughly 5% at a 10-degree upward angle, 10% to 40% at 20 degrees, and 20% to 70% at 30 degrees because material falls back along the helix [S1]. Sticky and bridging materials fall back faster than free-flowing ones, so a flared trough is rarely paired with inclines above 15 to 20 degrees without a tubular housing or an alternative [S1][S2].
Geometry, components, and where the flared section actually helps
A typical screw conveyor consists of a trough, screw (auger), trough cover, discharge spouts, coupling and end shafts, bearings, hangers, and associated hardware; the flared section is a drop-in modification of the trough body, so all upstream and downstream components are shared with a standard unit [S5].
The flare is usually formed by bending the top flange outward, which keeps the lower curved section identical to a U-trough and preserves interchangeability of the screw, end flanges, and hanger bearings [S2]. KWS, a manufacturer reference, lists flared troughs alongside angle-flange, formed-flange, double-formed-flange, formed-channel, drop-bottom, and jacketed troughs, all available in carbon steel, abrasion-resistant steel, hot-dipped galvanized, and stainless steel, with ASME-coded jacketed and tubular variants available for pressure or heat-transfer service [S2].
Because the additional headroom above the screw is intended for material entry and mixing, hanger bearings are usually omitted in the flared segment, even though a 10-foot nominal hanger spacing is standard on the rest of the conveyor; this avoids the very contamination and bridging the flare is meant to prevent [S1][S2]. For more details on the basic screw conveyor architecture, the encyclopedia entry covers the same components, and the lead screw page is a useful reference for helical-pitch geometry shared with mixing screws.
Material selection for sticky service

The trough material needs to be smooth to prevent material sticking, and stainless steel is a common choice for shaftless screws handling moist or cohesive waste streams [S6]. For flared-trough service with sticky solids, the practical material matrix is: carbon steel for dry, non-corrosive applications; hot-dipped galvanized carbon steel for outdoor or mildly corrosive service; 304 stainless steel for food, feed, and mild chemical exposure; 316 stainless steel for chloride or acidic exposure; and abrasion-resistant steel (AR400-class) on the lower curved section when the bulk solid is gritty as well as sticky [S2][S6].
Surface finish matters as much as alloy: a polished trough reduces adhesion of wet sludge, soap, or dough-like materials, and a UHMWPE or PTFE liner is sometimes used in place of stainless when the corrosion risk is low but the adhesion risk is high [S2][S6]. In any lined configuration, the supplier should re-confirm the percent fill because the liner increases the inner diameter loss and reduces the available cross-section [S1][S2].
For cohesive waste, a shaftless screw is the standard alternative because it eliminates the center shaft on which sticky material would otherwise build up; the shaftless screw rides in a wear-lined trough and removes the tail bearing and seal as maintenance items [S5]. The flared trough and the shaftless screw are complementary rather than competing: the flare widens entry, the shaftless design removes the center-shaft hang-up, and they are sometimes combined in a single unit.
Selection criteria and comparison against alternatives
Decision criteria for choosing a flared trough versus the four common alternatives: 1) material cohesion (sticky, moist, fibrous, free-flowing), 2) mixing requirement (none, light, intensive), 3) incline angle (0 to 15 deg, 15 to 30 deg, vertical), 4) containment (open, dust-tight, pressure-tight), and 5) maintenance access (standard, drop-bottom, fully split) [S1][S2][S3].
U-trough: lowest cost, the default for free-flowing granular solids at 0 to 15 degrees, not recommended for fine powders because of leakage from the open top [S1]. Flared trough: modestly higher cost, suited to sticky/viscous materials and light mixing, kept near horizontal, can be fitted with a cover for dust control [S2]. Tubular housing: best for inclined runs above 15 degrees, weather-tight, and can be ASME-coded for internal pressure [S2]. Shaftless screw: best for sticky, wet, or stringy waste, eliminates the center-shaft build-up, rides in a wear-lined trough [S5]. Live bottom (variable pitch, mass-flow cone, or tapered flight): used to meter and feed large volumes, prevents surging at the feed end, and is often paired with a downstream inclined conveyor [S3][S5].
A flared trough should NOT be specified when the run is above 20 degrees with sticky material, when the bulk solid is fluidizable or explosive without inerting, or when the duty is sanitary food contact without a polished stainless surface and a wash-down-rated drive [S1][S2][S6]. A standard U-trough is cheaper and should be used instead whenever the material flows freely. For long inclined runs with cohesive material, a tubular housing with a properly rated screw is the better answer [S2].
Sizing rules, drive sizing, and operating limits

Standard CEMA auger diameters span 6 to 24 inches, conveyor length commonly reaches 40 ft and not uncommonly 150 ft, and throughput is bounded by the cross-sectional fill times pitch times rpm times bulk density times a slope factor [S1][S5]. A 30% fill is a typical starting point for normally flowing material, dropped to 15% to 20% for cohesive or sluggish solids, and raised to 40% only for very free-flowing, low-bulk-density granules [S1].
Linear speed equals pitch times rpm, and at 30 to 60 rpm with a standard pitch equal to one diameter, the linear speed is 30 to 60 diameters per minute; 150 rpm is reserved for free-flowing, non-degradable products and is not used with sticky or bridging materials because high tip speed generates heat and packs the material against the trough [S1]. Inclined operation up to 15 degrees is acceptable for most U- and flared-trough screws; above 15 degrees a tubular housing is preferred because the closed envelope reduces fall-back and lifts capacity by 10% to 70% relative to an open trough at the same angle [S1][S2].
Drive sizing is by nameplate horsepower at the worst-case fill, peak bulk density, and the steepest angle in the run, with a service factor of 1.25 to 1.5 typical for bulk-solids service; a 10-foot hanger-bearing spacing is the default because the screw must not touch the trough and metal-to-metal contact would generate wear particles and contamination [S1]. For very long runs, a comparison of belt, chain, and screw options is warranted, and a belt conveyor or chain conveyor will usually beat a screw on length above 150 ft or where the material is friable.
Real applications, failure modes, and sourcing signals
Flared troughs are most often quoted for: dewatered sludge and cake in municipal wastewater, wet animal-feed mash in feed mills, moist biomass and wood-chip fractions with binder, ash and lime hydrate, soap and detergent crutcher feed, and chemical pigments with residual solvent [S3][S5]. In each case, the flare widens the entry so the cohesive mass can drop in without ratholing, and the headroom above the flight lets paddles or cut flights fold the material rather than just push it [S2][S3].
Common failure modes to specify against: 1) center-shaft build-up on shafted designs in sticky service (use shaftless or live-bottom), 2) hanger-bearing contamination when bearings are placed inside the flared segment (omit hangers in the flared section, support externally), 3) trough wear at the lower curve when the material is gritty (use AR plate or a replaceable liner), 4) over-speed heating that fuses sticky material to the flight (cap at 60 rpm), and 5) under-rated drive on inclined runs (re-rate for the 20% to 70% capacity loss at 30 degrees) [S1][S5].
Sourcing signals: CEMA-compliant diameters of 6 to 24 inches, available trough materials of carbon steel, abrasion-resistant steel, hot-dipped galvanized, 304/316 stainless, and ASME-coded jacketed or tubular variants for heat-transfer or pressure service, all from established bulk-handling manufacturers, are the verifiable specification floor [S2][S5]. A related comparison on tall bucket elevator belt carcasses and pump-drive coupling selection will help engineers sizing a complete bulk-solids train. Trackable signals for a 2026 update: any new CEMA Standard 300 revision on trough geometry, ASME RTP-1 updates relevant to jacketed screw housings, and any OEM release of stainless sanitary flared-trough designs rated for 3-A or EHEDG wash-down duty.
