Compact ball-screw linear modules exported from China landed between US$500 and US$1,800 FOB per piece in the May 2026 reference listing for the TIAYO Compact Linear Module Unit, with 1944×220×138 mm envelope, ISO 9001:2000 quality management, and a published repeatability of ±0.01 mm [S2].
The same listing ties price to two physical limits: maximum horizontal payload of 150 kg and maximum vertical payload of 55 kg, with servo-motor drive and an effective stroke window common to compact stages [S2]. Light-load linear modules sized for warehouse cranes, shipboard cranes, and building cranes sit on the lower end of the negotiation band and are typically quoted at MOQ of 1 piece on Made-in-China [S4].
What a Linear Module Actually Costs in 2026
Reference transactions place a single-axis compact ball-screw linear module in the US$500–US$1,800 FOB band, with branded compact units (TIAYO or OEM) most often clearing between US$900 and US$1,400 at small quantities [S2]. For light-load configurations, the entry price undercuts the mid-band because the carriage, screw diameter, and bearing stack are downsized to match a few-hundred-newton working load [S4].
Bulk pricing inverts the usual assumption that industrial automation is a high-ticket purchase: a 1-piece MOQ is standard for the light-load segment on Made-in-China, and a 50-piece factory order typically negotiates another 10–20% off the single-piece list [S2][S4]. Cross-check on Alibaba's medical-rail-system supplier index shows C7-grade ball-screw modules with 50–4000 mm effective stroke still quoting in a similar band, indicating the published range reflects the market rather than a single brand premium [S3].
Selection Criteria That Move the Quote
Five specification gates lock the part before RFQ: effective stroke length, repeatability class, payload (horizontal vs vertical), drive type (servo stepper pneumatic), and the required linear guide profile. Stroke is the dominant cost lever: each 500 mm of added effective length on a ball-screw module pulls in another linear guide rail segment, a longer screw, and a longer bellows cover, all of which scale roughly linearly with the 50–4000 mm range seen in the supplier index [S3].
Repeatability is the second lever: the compact TIAYO unit publishes ±0.01 mm, which corresponds to a ground C7-class ball screw in a 20 mm or 25 mm diameter format. Buyers who need ±0.005 mm or tighter should expect a price uplift of 30–60% over the compact benchmark, and a lead-time penalty because the screw has to be selected and pre-loaded rather than off-the-shelf [S2]. For a deeper look at how the guide profile inside a module changes its price/load ratio, the linear guide reference walks through the rail-width and block-length trade-offs that sit under every module spec sheet.
Comparing the Main Linear Module Types
Three architectures dominate 2026 sourcing: ball-screw modules (the TIAYO pattern, 150 kg horizontal / 55 kg vertical, ±0.01 mm) [S2]; belt-driven modules for long stroke and high speed at lower precision; and linear motor modules where the published benchmark is stroke length and force density rather than payload mass. The ball-screw version is the only one of the three with a published FOB band on the reference listings [S2][S3].
On four decision criteria, the comparison reads: cost (ball-screw compact is lowest at US$500–US$1,800 [S2], linear-motor is highest), repeatability (ball-screw ±0.01 mm [S2], belt-drive typically ±0.05 mm or wider, linear-motor ±0.005 mm with closed-loop encoder), stroke (ball-screw practical limit around 2 m in compact form, linear-motor extends further with stacked rails), and maintenance (ball-screw needs periodic lubrication and bearing audit, belt-drive needs belt-tension checks, linear-motor is essentially maintenance-free on the drive element). For buyers who already use a linear actuator architecture, the module simply packages the same drive and guide elements inside a pre-engineered frame.
Real Use Cases and Sourcing Reality
Compact ball-screw modules of the type priced in the reference listing are specified into PC, LCD, PCB, and PDP assembly cells, plus biotechnology and semiconductor front-end equipment where the 150 kg horizontal payload envelope is sufficient [S2]. Medical rail systems on Alibaba's supplier index use the same C7 ball-screw format at 50–4000 mm stroke, indicating the part family is interchangeable across factory automation, medical imaging gantries, and pick-and-place cells [S3].
Light-load modules (a separate SKU class) are aimed at warehouse cranes, shipboard cranes, goods-yard cranes, building cranes, and workshop cranes, where the carrying capacity is sized for tooling positioning rather than primary structural lifting [S4]. Order pattern: 1-piece MOQ is normal for evaluation units, with engineering samples typically shipped within 7–15 days ex-China and production runs of 50+ units moving to 25–35 day lead time [S2][S4].
Limits, Failure Modes and Standards to Watch
The published TIAYO specs do not declare an IP rating, cleanroom class, or ATEX/IECEx zone rating, so any buyer pushing the module into wet, dusty, or explosive atmospheres needs to request a sealed bellows option and verify certification documents lot by lot [S2]. Vertical payload is the structural bottleneck: the 55 kg vertical figure is roughly 37% of the 150 kg horizontal figure, because the same ball-screw and guide pair must hold the load against gravity without ratcheting [S2].
Quality management on the reference compact unit is documented to ISO 9001:2000, not the 2015 revision, so procurement teams with a hard 9001:2015 mandate should request a current certificate before PO release [S2]. For higher precision or heavier load, an upgrade to a crossed roller guide format inside the module typically buys both a stiffer moment load rating and a tighter straightness budget, at a price premium of 2–3x over the compact ball-screw benchmark. Engineers who also need position feedback should look at integrating a linear encoder on the carriage rather than relying on the servo motor's rotary encoder, because the latter measures screw rotation, not carriage position, and cannot detect belt or coupling slip.
