Seven-wire and 19-wire prestressing steel strands are calibrated against ISO 15630-3, with verification loads of 0.80 × specified characteristic breaking force (Fu) on the wire and full-strand tensile tests to confirm 0.1% proof-force, elongation at fracture, and stress-at-1% extension [S5].
Two strand families dominate site work: galvanised messenger and guy strands for utility/cable stay applications, and uncoated or unbonded prestressing strands embedded in concrete decks, silos, and bridge girders, where corrosion of the helical wire bundle is the dominant degradation mode [S5][S2].
Construction and Material Spec Bands
A standard 7-wire strand is built from six outer helical wires cold-drawn over one straight king wire, with common nominal diameters of 9.53 mm (3/8"), 12.7 mm (1/2"), 15.24 mm (0.6"), and 17.8 mm (0.7"), and breaking-force bands running roughly 102–261 kN depending on grade and diameter [S5].
19-wire compacted and semi-compacted strands push the cross-section up into the 18–28 mm range for stay-cable and rock-anchor duty, while galvanised guy / messenger constructions typically follow ASTM A475 common grades (Utilities, Common, Siemens-Martin, High-Strength, Extra-High-Strength) with zinc coating classes A through E governing coating mass per unit length [S5].
Calibration Procedure and Acceptance Bands
Calibration of a finished strand reel is performed on a calibrated hydraulic tensile bench: the strand is gripped with serrated wedges over a free length of at least 500 mm, loaded to 0.80 Fu, held for a short dwell, then ramped to failure to confirm Fu, Agt (total elongation at maximum force), and E-modulus near 195 GPa [S5].
Acceptance bands for the 1% extension force typically sit within ±5% of the nominal value declared by the mill, and relaxation loss on Grade 1860 (270 K) strand is generally required to stay below 2.5% after 1000 h at 0.70 Fu and 20 °C. Lot rejection usually triggers on a single tensile failure, on Agt below 3.5%, or on visible surface defects longer than one wire diameter [S5].
Non-Destructive Testing and Corrosion Monitoring
Metal Magnetic Memory (MMM) has been validated on unstressed 7-wire strands as a passive magnetisation technique: a sensor scans the strand surface for self-magnetic-flux-leakage peaks (Hpy) whose gradient and zero-crossing position map directly to corrosion pits and stress concentrations, with defect localisation accuracy reported in the centimetre range in controlled coupon tests [S2].
For in-service prestressing tendons inside ducts, the practical field mix is grout-condition inspection at anchor ends, MMM scans at accessible windows, and selective breakout coupled with remaining-diameter gauging. On galvanised messenger / guy strands, a coating-thickness gauge reading below the ASTM A475 class-specified g/m² (Class A ≈ 230 g/m², Class C ≈ 460 g/m²) is a typical repair-or-replace trigger [S2][S5].
Maintenance Intervals and Storage Discipline
On-site storage drives most early-life strand failures: reels must be lifted off the ground on timber bearers, stored under tarpaulins with ventilation, and rotated first-in-first-out, because white rust on galvanised stock can drop fatigue life sharply within weeks of moisture ingress [S5].
Routine inspection intervals for stay cables and external tendons are commonly set at 2 years for visual survey and 5–7 years for magnetic / MMM scan, with anchor-zone greasing and HDPE sheath replacement scheduled in the same window. For alloy steel sheathing and anchorage components, hardness and tensile re-qualification after any in-service over-load event is a standard insurance item.
Who This Guide Is For — and Where It Does Not Apply
This guide fits civil and structural engineers, prestressing-yard QA staff, and stay-cable / rock-anchor inspectors handling 7-wire or 19-wire prestressing steel strand per ISO 15630-3 or galvanised guy / messenger strand per ASTM A475. It does not cover stainless or compacted hybrid strands for offshore lazy-wave risers, nor does it address 1×3 or 1×7 elevator / control cables that follow separate EN 81 rope schedules. [S1]
Users working on LNG or cryogenic pipework should treat the calibration numbers above as ambient reference only; below -40 °C, Charpy and relaxation behaviour of cold-drawn wire changes materially, and a separate low-temperature QA plan is mandatory [S5].
Failure Modes and Field Limits
The four dominant failure modes are (1) pitting corrosion at the inter-wire contact gaps where capillary water sits, (2) stress-corrosion cracking at anchor wedges where the galvanising is locally stripped, (3) fatigue wire breaks at deviator saddles with under-radius supports, and (4) relaxation loss exceeding the design budget on long, continuously-loaded tendons [S2][S5].
A practical field limit: if more than 5% of outer wires in a one-metre gauge length show visible section loss, or if a single pit depth exceeds 0.5 mm on a 5 mm wire, the affected reel should be quarantined and the lot re-tested before any further stressing.
