Three Korean-built orchard aerial work trucks in the LNS-H200, LNS-H250 and LNS-J500 series deliver working heights of 2.1 m, 2.4 m and 1.4 m respectively on rubber-track chassis with 200 kg deck load and 24–36 V DC battery drives, targeting orchard-pruning and livestock-barn maintenance crews [S1][S2][S4].
For canopy work above 3 m, buyers must step out of the orchard-platform category entirely and into truck-mounted or tractor-mounted aerial work platform configurations that cover the 12–36 m working-height band, where FOB prices in June 2026 cluster between US$ 1,200 and US$ 26,680 per unit [S5].
Working-height tier and deck capacity
Agricultural buyers fall into two distinct height tiers: orchard maintenance at 1.4–2.4 m platform lift, and tall-tree or trellis canopy work at 6–14 m platform height, with 200–450 kg deck load typical across both bands [S6]. The LNS-H200 lifts 2.1 m max on a 244×154.5×188 cm body with a 188×122 cm workbench, dual DC 24V 1,600 W motors, four 24V-330AH batteries, and a 200 kg load rating that includes the operator [S1]. The LNS-H250 lifts 2.4 m max on a larger 261×133×183 cm body, 220×104 cm workbench, dual DC 36V 2,000 W motors, and six 36V-240AH batteries [S2]. The LNS-J500 is the smallest of the three, lifting 1.4 m on a 190×104×148 cm body, 120×106 cm workbench, dual DC 24V 1,500 W motors, and four 24V-240AH batteries with an independent-drive powertrain for unstable ground [S4].
For the 6–14 m band, ANSI A92.22 compliance on mobile elevating work platforms (MEWPs) is the hard regulatory gate for U.S. orchard and greenhouse operators, while CE marking plus EN ISO 12100 documentation cover the European equivalent [S5][S6]. All three orchard units run rubber caterpillar tracks sized 180×60P×55 (H200), 180×72P×51 (H250), and 180×60P×45 (J500), giving ground clearance and flotation that pneumatic tyres cannot match on soft orchard soil [S1][S2][S4].
Drivetrain: track vs wheel, and why orchard trucks differ from road-going boom lifts
Rubber-track drivetrains dominate low-rise orchard aerial work vehicles because the underfooting is soft, wet, and uneven, and a low centre of gravity prevents tip-over when the workbench is extended to 200 kg at full reach [S1][S2][S4]. The LNS-H200 and LNS-H250 both publish a 2.3–2.4 km/h maximum travel speed, a deliberate cap that keeps the loaded platform inside the stability envelope of the track footprint; the smaller LNS-J500 runs 3.1 km/h forward and reverse because its 1.4 m lift keeps the centre of gravity lower [S1][S2][S4].
For truck-mounted booms in the 12–30 m band, wheeled chassis dominate because the truck must travel on public roads between sites, and the 4WD vs 2WD gate becomes a procurement decision: 2WD suffices on paved orchard lanes, while 4WD is mandatory for muddy track access during harvest [S5][S6]. A 12 m JQ5050JGK-12 carries a 200 kg (2-person) basket on a Dongfeng-class chassis, and the 30 m HOWO hydraulic mobile platform uses a Sinotruk-class chassis with customisable upper body, which is a fundamentally heavier vehicle class than any LNS orchard unit [S5].
Power source: DC battery vs diesel stage-V
Battery-electric DC drives (24V or 36V) are the standard power source for low-rise orchard aerial work vehicles because they eliminate engine exhaust inside greenhouses, livestock barns, and enclosed pruning tunnels [S1][S2][S4]. The LNS-H200 ships with a 24V 20A digital charger and four Longest 12165 cells; the LNS-H250 uses a 36V 20A digital charger with six Longest 6240 cells; the LNS-J500 pairs a 24V 20A digital charger with four Longest 6240 cells [S1][S2][S4]. None of the three publishes a continuous-duty amp-hour draw, which is a real procurement gap for buyers trying to size a solar or generator backup for multi-shift operations.
For 12–36 m truck-mounted booms, diesel Stage V / Euro VI engines on the host chassis remain the default because the platform’s hydraulic pump draws continuous power that current orchard-class 24/36V battery packs cannot supply for a full working day [S5]. Buyers specifying electric boom lifts above 32 m should look at the Shandong Beijun telescopic electric boom lift, which sits at the top of the mainstream commercial band as a purpose-built electric platform vehicle rather than a truck conversion [S5].
Stability, levelling, and orchard-floor constraints
Front, rear, left and right automatic levelling sensors are standard on the LNS-H200, LNS-H250, and LNS-J500, which is a direct response to the uneven, sloped terrain of orchard and vineyard working environments [S1][S2][S4]. The LNS-J500 also markets an independent-drive powertrain as a stability feature for unsafe road surfaces, in addition to the four-corner levelling system [S4]. For truck-mounted booms in the 12–30 m band, stability is handled instead by hydraulic outriggers and stabiliser mass, with outrigger span scaling roughly with working height: 12 m platforms use narrow outriggers, 30 m platforms need wide-span outriggers plus significant ballast [S5].
The hard procurement lesson is that low-rise orchard platforms rely on track footprint plus auto-levelling to stay upright, while tall boom trucks rely on outriggers plus chassis mass; mixing the two concepts (e.g. bolting a 14 m boom to a 200 kg-class orchard track chassis) does not work because the track footprint is too small for the moment arm of a 14 m boom at full extension [S5][S6].
Pricing, supply ability, and lead-time gates
FOB price for truck-mounted and tractor-mounted aerial work platforms in June 2026 clustered between US$ 1,200 and US$ 26,680 per unit, with the cost floor set by 4–16 m aluminium scissor platforms at US$ 800–7,525 per unit [S5]. Published supply ability varies by an order of magnitude: Yangzhou Yixiang publishes 100 sets/month, Dongfeng CLW publishes 20 sets/month on the DF 145 line, and Okorder-listed JQ-series suppliers publish 10 sets/month, which sets realistic 12-week delivery expectations for full-fleet buyers [S5].
Korean orchard-class units from LNS do not publish a per-unit FOB price on the Komachine catalogue, which is a procurement gap that should be filled directly with the manufacturer before issuing a tender; Komachine lists the H200, H250, and J500 as separate SKUs (142782, 142781, 142783) under the Agricultural Aerial Work Vehicle series [S1][S2][S4]. For municipal or rental fleets running aerial work truck units on public roads, the truck-mounted (non-detachable) HOWO and Dongfeng pattern remains the default configuration because it self-deploys without a secondary tractor [S5].
Selection criteria: who this is for, and who it is not for
Low-rise orchard aerial work vehicles (1.4–2.4 m lift, 200 kg deck, tracked DC drive) are the right tool for apple, pear, and cherry pruning crews working in 2–4 m canopy orchards, for greenhouse maintenance teams, and for dairy barn builders who need a stable elevated platform on uneven concrete [S1][S2][S4][S6]. They are the wrong tool for citrus or macadamia orchards with 5–8 m canopy, for trellis wine grape work at 2.5–3.5 m, and for any task that requires a worker to reach above 3 m: in those cases, a 6–14 m MEWP-class unit with ANSI A92.22 compliance is the minimum [S6].
Buyers should also weigh remote-control operation as a procurement gate: the LNS-H200, LNS-H250, and J500 all ship with wireless remote control, which lets a single operator position the platform from the ground while a second worker is on the bench, a meaningful productivity gain for pruning crews [S1][S2][S4]. For buyers evaluating related categories, the diesel aerial work truck specs for road construction sites reference provides a useful contrast on chassis and engine selection, while port aerial work truck spec gates covers the corrosion and wind-load gates that matter for coastal orchard operations.
Limitations and failure modes
The 200 kg deck rating on all three LNS orchard units is the binding constraint and includes the driver’s mass, so a 90 kg operator can only load 110 kg of tools, picking bags, or a second worker on the bench [S1][S2][S4]. None of the three publishes a wind-rating, which is a procurement gap for exposed hilltop orchards; buyers in coastal or ridge-top sites should request a manufacturer wind-rating letter before accepting delivery.
Battery run-time is the other binding constraint: the LNS-H200’s four 24V-330AH cells, the LNS-H250’s six 36V-240AH cells, and the LNS-J500’s four 24V-240AH cells determine shift length, and none of the three catalogues a continuous-load amp draw, so realistic shift length must be measured on-site rather than read off a spec sheet [S1][S2][S4]. For 12–30 m truck-mounted booms, the parallel constraint is road-legal axle load: a 30 m HOWO with full stabiliser ballast can exceed standard agricultural vehicle GVW limits on narrow farm lanes, so route survey is a procurement gate, not an afterthought [S5].
Two trackable signals to watch through Q4 2026: published continuous-duty amp-hour draw for the LNS orchard platform series (the single biggest specification gap on the current Komachine data sheets), and the next refresh of the JQ5050JGK series, which has held a 200 kg basket rating across the 12 m, 14 m, 16 m, and 18 m variants since the 2024 model year [S1][S2][S4][S5].
