Specifying a new press today usually comes down to one procurement call: order a bare-shaft pump and build the power circuit around it, or buy a packaged hydraulic power unit that arrives with tank, motor, filtration, and valve block already assembled and tested.
Both routes use the same physical core, a positive-displacement hydraulic pump driven by an electric motor, but the on-site effort, commissioning risk, and total installed cost differ sharply. Standard industrial units are designed for 50-350 bar continuous operation, with special builds pushing 700 bar [S3].
What Each Option Actually Is
A bare-shaft pump, sometimes called a pedestal or frame-mount pump, is supplied as a pump element only, with an exposed input shaft but no motor coupling, no tank, no bell housing, and no valve integration; the installer must couple it to a driver, align the shaft on-site, plumb suction and return lines, and wire the motor [S5]. A packaged hydraulic power unit (HPU) bundles the pump, electric motor, reservoir, filtration, gauge block, and typically a directional/relief valve manifold into a single factory-assembled and leak-tested skid [S1][S2].
The functional difference is not about pressure or flow capability. Both routes can deliver the same kW to a press cylinder. The difference is where the engineering hours go: a bare-shaft configuration transfers assembly, alignment, flushing, and leak-check labour to the buyer, while a packaged HPU shifts that work to the OEM production line, where a 100 N input on a 1 cm² piston gives 100 bar, multiplied to 1000 N on a 10 cm² piston [S3].
Selection Criteria That Actually Decide the Call
Four decision variables tend to settle the choice on a new press project: (1) project timeline, (2) available engineering labour, (3) existing skid infrastructure, and (4) service access after commissioning. [S2]
On criterion 1, packaged HPUs ship in stock configurations within days from suppliers such as Continental Hydraulics, where stocked components allow fast delivery [S1]. Bare-shaft pumps share that lead time on the pump itself, but the installer still needs weeks to mount, align, plumb, flush, and certify the system [S5].
On criterion 2, a packaged HPU lets a small maintenance team receive a unit and connect two hydraulic lines plus a power lead; a bare-shaft pump needs a competent millwright or hydraulic technician for laser shaft alignment, bell-housing assembly, and reservoir fabrication if none exists.
On criterion 3, plants that already operate a fleet of presses with a standardised tank, motor cradle, and valve manifold often standardise on bare-shaft pumps for spares commonality. Greenfield press lines with no hydraulic infrastructure almost always default to packaged units, because the alternative is essentially building the HPU in-house.
On criterion 4, packaged units are designed around filter element access, drain plugs, and gauge ports visible from the front [S2]. Custom-built bare-shaft skids frequently bury the return filter under the valve block unless the spec forces it out.
Component-by-Component Comparison
The cost and risk line items differ by component, not by headline price. A packaged HPU carries a higher unit cost (typically 30-60% above a bare-shaft pump of equivalent displacement, depending on reservoir size and valve content) but eliminates separate purchases of the electric motor, coupling, bell housing, suction strainer, return filter, filler/breather, level gauge, and relief block [S2][S5].
On commissioning, packaged units are factory-flushed and tested, so oil cleanliness meets NAS 1638 class 7 or better before shipment on most reputable OEM skids. Bare-shaft installations need on-site flushing for 2-4 hours minimum, longer for large reservoirs, before the cylinder line can be connected without contaminating servo or proportional valves.
On efficiency, the difference is negligible if the same pump model is used. The QXEHX-type optimised gear pump platform used in newer packaged HPUs can run at higher shaft speeds, allowing a smaller displacement to maintain the same flow and reducing torque demand on the motor [S7]. That is a pump-design win, not a packaged-vs-bare win.
On service, both options use the same pump internals, so wear-parts stock is identical. The packaged HPU's advantage is that the filter, breather, and gauge cluster are in a known location on every machine; the bare-shaft skid is only as consistent as the integrator's drawing discipline.
Who Should Pick Each Option
Packaged HPU is the right call when: the press is a one-off or low-volume build, the maintenance team is small, the machine builder does not want to stock reservoir fabrications, or the press must ship inside 8-12 weeks including commissioning. It is also the right call when the press is bound for a customer site with strict cleanliness expectations, because factory flushing and a sealed reservoir give a measurable cleanliness edge. [S2]
Bare-shaft pump is the right call when: the press builder already runs a standard hydraulic skid that accepts a common pump footprint (SAE A, B, C flange), the engineering team has a certified alignment crew, the installation bay has a flushing rig, and total cost of ownership is more important than purchase order simplicity. It is also the better choice when the press will sit inside a larger hydraulic loop that already provides tank, cooling, and filtration, such as a servo press cell that needs only a controlled hydraulic supply rather than a full standalone unit.
The bare-shaft path is not for OEMs who are specifying their first press line and do not have a hydraulic test bench. Buying a bare pump and improvising the tank plumbing has ended more press commissioning schedules than any pump failure mode.
Use Cases Seen in the Field
For a stand-alone tablet press or compaction press shipped as a complete machine to a pharmaceutical or powder-metallurgy customer, the packaged HPU is the default: short commissioning windows, clean factory, and a service engineer who arrives to a labelled unit with one drawing. Integrating the unit with upstream powder feed and downstream powder new material handling is then a matter of plumbing the cylinder ports, not designing a hydraulic room. [S2]
For a press line embedded in a heavy-machining cell where the same central hydraulic room already feeds multiple machines via a ring main, the bare-shaft pump is the right pick. The press inherits the existing filtration, cooling, and reservoir, and the only new addition is the pump-and-motor module mounted on a local bracket. Heat, contamination, and tank sizing are no longer per-machine concerns.
For high-tonnage forging or stamping presses operating continuously above 250 bar, the volume and duty may justify a custom-engineered packaged unit from a supplier such as Danfoss, which offers both standard and custom-engineered power units plus motor-pump combinations for high-performance duty [S6]. A 20 l/min flow at 200 bar equates to roughly 6.67 kW of hydraulic power, so a 100-tonne press at 250 bar with a 200 mm bore cylinder running a 5-second cycle sits comfortably in the standard packaged range [S3].
Limitations, Failure Modes, and Sourcing
Packaged HPU limitations are mostly dimensional and acoustic: a self-contained unit consumes floor space, generates package noise (the pump, motor, and valve block are all in one enclosure), and cannot be easily relocated once the hydraulic lines are run. The standard acoustic treatment is a suction-side rubber mount and return-line muffler, but a quiet pump is the larger win [S7].
Bare-shaft pump limitations centre on alignment and contamination. Misaligned couplings are the single most common cause of premature pump bearing failure, and the fix is a laser alignment job that takes 1-2 hours with a trained crew [S5]. Inadequate flushing before commissioning is the second most common failure mode, and it shows up as stuck proportional valves or scored cylinder bores within the first 200 hours.
For sourcing, buyers in the UK are working in a fluid power equipment manufacturing market projected to reach £1.3 billion in 2026 with 5.5% annual revenue growth, which is the macro context for current lead times and capacity [S2]. Globally, packaged HPU and bare-shaft pumps draw from the same pump manufacturers (Bosch Rexroth, Parker, Eaton, Danfoss), so component availability is not a differentiator; delivery format is.
Standard HPUs in the industrial range operate at 50-350 bar with specialised builds reaching 700 bar, typically run on mineral or synthetic hydraulic oil (over 95% of modern power units, with biodegradable options available), and follow the basic circuit pattern of tank, pump, relief valve, directional valve, actuator, and return [S3].
Decision rule for the spec: choose packaged HPU if you want a sealed, tested, documented hydraulic source delivered to the press bay with one drawing; choose bare-shaft pump if you already have the rest of the hydraulic infrastructure and your team has the alignment and flushing discipline to commission it. A short shaft collar spec, a proper coupling guard, and a written flushing procedure are the minimum documentation required for a bare-shaft install to reach the same reliability as a packaged unit.
