A bare LVDT physically must be 4 to 6 times the measured stroke length, with a typical useful stroke cap near 5 inches and a hard ceiling around ±120 inches (±0.5 m) [S3][S4]. When the application asks for several feet of travel (hydraulic cylinder position, dam gate lift, crane boom extension), a cable-extension LVDT replaces the long coil stack with a short-stroke LVDT core driven by a precision cable spool, and current designs reach 23 ft of stroke as a drop-in for failed rod-type sensors [S3].
The core engineering reason is geometric: the LVDT coil has to stay longer than the core's full range of motion or linearity collapses, which is why industrial LVDTs are described as excelling at "short stroke stuff where you need almost infinite" resolution [S4]. For everything past a few inches, the cable-extension LVDT is the only way to keep LVDT-class accuracy (sub-micron core resolution) at a long, human-scale measurement range.
Stroke Range and Physical Footprint
Bare LVDT stroke is bounded by coil length: a 3-inch coil yields roughly 0.8 inch of usable stroke before end-effects drive nonlinearity past 2% [S4]. Industrial LVDT bodies run from a few millimeters up to ±1 m of full-scale stroke, with the very largest commercial configurations reaching ±120 inches [S3][S7]. Cable-extension LVDTs sidestep that ratio by spooling a stainless cable onto a micrometer-threaded hub; the hub translates axially by 5 inches or less while the cable can pay out 23 ft, so the LVDT core itself never sees more than its native 5-inch window [S3]. For comparison shopping, see the displacement sensor overview and the dedicated LVDT sensor entry.
Accuracy, Linearity, and Edge-Zone Behavior
LVDT contact probes and LVDT-based linear transducers are specified for sub-micron resolution, but accuracy degrades near the end of the spindle travel because the core no longer overlaps both secondary coils symmetrically [S2]. Digital (optical/encoder) displacement sensors sidestep this by holding linearity across the whole range, not just the central band, and they offer better repeatability at the cost of needing an integrated electronics head [S5]. The CPI SL Series cable-extension design keeps the LVDT core centered in its 5-inch sweet spot regardless of cable position, so the high-accuracy zone is effectively extended to 23 ft; the mechanism does the linear-to-rotary-to-linear conversion rather than the LVDT itself [S3].
For non-contact alternatives, a laser displacement sensor or a confocal displacement sensor can match stroke length without a cable, but they need a clear optical path and a reflective (or diffuse-reflective for confocal) target. Where dust, oil mist, steam, or hydraulic oil film block the beam, the LVDT-in-a-cable-drum design wins on environmental immunity.
Signal Cable, Excitation, and Installation Trade-offs
AC LVDTs lose excitation voltage to cable impedance, and a typical max cable run is 50 to 100 ft; DC LVDTs tolerate slightly more but anything past 100 ft starts to drop the power supply rail on the signal lines [S1]. The fix is a signal conditioner or 4-20 mA / ±10 V transmitter mounted at the sensor head, which both limits cable effects and breaks ground loops; for industrial sites, shielded twisted pair with the shield grounded only at the receiving end, plus routing away from VFDs and motor power cables, is the standard practice [S1].
Cable-extension LVDT bodies are physically larger than a bare LVDT probe because the cable drum and threaded hub take real volume, so the displacement-position envelope has to allow for a drum housing typically 4 to 6 inches in diameter. For a sense of where these devices sit inside the broader position-measurement market, the displacement position reference page maps the options by stroke, mounting, and output type. Cable glands on the drum housing should be specified to the same ingress rating as the rest of the enclosure, since the cable exit is the most common leak path; the cable gland entry walks through the IP/IK sizing rules.
Decision Matrix: Cable-Extension LVDT vs Bare LVDT
Use the following four-criterion matrix for spec reviews. (1) Stroke length: bare LVDT ≤ 5 in for best linearity, up to ±120 in absolute max; cable-extension LVDT up to 23 ft with linear accuracy preserved across the full range [S3][S4]. (2) Accuracy: bare LVDT delivers sub-micron core resolution, but only inside the centered overlap zone; cable-extension LVDT keeps that zone intact regardless of cable payout [S2][S3]. (3) Environmental sealing: both are fully sealed and oil-immersible; bare LVDT is smaller and easier to flush-mount inside a hydraulic cylinder, cable-extension LVDT needs an external drum cavity [S3]. (4) Cable runs to the controller: both are limited to 50-100 ft of AC excitation cable without a head-mounted conditioner; plan the same 4-20 mA or ±10 V conversion either way [S1].
For sub-5-inch measurements where the target fits inside a probe (gauging, sortation, bearing clearance), a bare LVDT or a digital pencil probe is the cheaper, smaller answer [S2][S5]. For hydraulic cylinder rod position, ball-valve travel, dam gate lift, or any 1 m+ machine slide, a cable-extension LVDT is the only LVDT-family option that keeps the sensor in its linear sweet spot; the alternative is a magnetostrictive rod, a linear encoder, or a non-contact optical sensor, each with its own mounting and target requirements [S3][S8].
Limits, Failure Modes, and When to Walk Away
Cable-extension LVDTs have a finite cable-cycle life; the stainless cable kinks, frays, or stretches past spec after enough drum windings, and the spool hub can wear if the environment carries abrasive dust past the cable gland. Stroke lengths above 23 ft push the design out of standard product and into engineered specials, where lead time and calibration cost rise sharply [S3]. Bare LVDTs fail the other way: trying to use one past about 5 inches of stroke without a cable drum means accepting 2% or worse nonlinearity, which is the failure mode the eevblog thread on LVDT design ratios keeps surfacing [S4]. Both architectures share the cable-run limit of 50-100 ft of AC excitation, so remote-actuator applications past that distance need a head-mounted signal conditioner or a digital-bus output module at the sensor [S1].
Two trackable signals to watch: (a) extension of digital-output LVDT conditioners past 100 ft of excitation cable, which would let the bare LVDT stay in the running for medium-stroke applications; (b) cable-extension LVDT specials beyond the current 23 ft ceiling, which would push the technology further into long-stroke hydraulic and structural-monitoring niches [S1][S3].
