A certified explosion-proof stepper motor must carry a Class/Division/Group marking, a T-code, and a torque envelope matched to the frame size; North American Class 1 Division 1 Group D units (e.g. Kollmorgen MX Series) ship from 1.27 to 9.82 N-m in NEMA 34 and NEMA 42 [S2][S6].
The two dominant construction philosophies in 2026 are flameproof enclosures (UL 674 in the US, ATEX/IECEx Ex d) and purged-and-pressurized enclosures (NFPA 496 Type X/Y/Z), which behave differently in spec, footprint, and ambient limits [S1][S4]. Engineers specifying a stepper for paint booths, chemical dosing skids, fuel-handling skids, or grain elevators need to map the hazardous-area classification to the certification string before the torque curve is even discussed.
UL 674 / NFPA Division and Group system for stepper motors
UL 674 governs explosion-proof motors in the United States, and the marking string follows the Class, Division, Group, T-code scheme [S4]. Class I covers flammable gases or vapors and runs Groups A through D by minimum ignition energy, with Group D (hydrocarbons, propane, fuels, solvents, ignition energy around 240 microjoules) the most common envelope for general refinery and fuel-handling service [S4][S5].
Class II covers combustible dust in Groups E (metal), F (coal/carbon), and G (grain, sugar, plastic, chemical dust), while Class III addresses ignitable fibers and flyings such as cotton lint, flax, and rayon [S4]. A Class 1 Division 1 Group D rating means the hazard is present under normal operations, and Division 2 means the hazard is confined in closed systems and only present through accidental rupture or unusual faulty operation [S4][S5]. For a stepper motor the Class/Division/Group string is the gating spec; T-code comes second.
ATEX and IECEx Zone markings for global builds
European and most international builds run ATEX 2014/34/EU plus IECEx, replacing the Division concept with Zones: Zone 1 (hazard likely during normal operation) for gases and Zone 21 for dust, with Zone 2 / Zone 22 reserved for abnormal-only exposure [S2][S5]. A representative ATEX/IECEx string on a Kollmorgen Goldline EB/EBH is "Ex II 2 G Ex d IIB T3 Gb" with a -40 to +40 degrees C ambient, file ITS12ATEX17548X, and IECEx ETL 12.0006X [S2].
The same vendor's AKME servo line carries "II 3G Ex ec mc IIC T4 Gc" for Zone 2 gas and "II 3D Ex tc IIIC T130 degrees C Dc" for Zone 22 dust, file TPS 25 ATEX 124440 0005 X [S2]. Zone marking changes the enclosure philosophy: Ex d (flameproof) contains an internal explosion, Ex e (increased safety) and Ex ec prevent arcs/sparking, and Ex tc keeps the surface below the dust layer ignition temperature [S2][S5]. Picking a Zone 1 stepper where only Zone 2 was required is overspend; the reverse is unsafe and non-compliant. For an overview of the directive structure see explosion-proof electrical equipment.
Purged-and-pressurized (NFPA 496) versus flameproof enclosures
NFPA 496 defines Type X, Type Y, and Type Z pressurization that converts the interior of an explosion-proof motor into a non-hazardous area by maintaining positive pressure with dry air or nitrogen [S1]. Empire Magnetics' PT Hazardous Area Step Motors use this approach: the motor body sits in the hazardous area, air lines plus a temperature-sensor cable run back to a controller in the safe area, a differential pressure switch on the return air line cuts drive power on pressure loss, and a purge delay runs before re-energizing [S1].
Purged-and-pressurized designs accept a wider range of stepper frame sizes than flameproof castings, because the enclosure does not have to contain an internal blast. The PT line scales from a 1.7-inch-diameter, 13 to 26 oz-in size, through 2.3-inch / 60 to 150 oz-in, 3.4-inch / 80 to 240 W (150 to 450 oz-in), up to 4.2-inch / 240 to 700 W (400 to 1600 oz-in) [S1]. Flameproof steppers are bounded by what the certification lab will accept on the test bench, which is why stock Class 1 Division 1 Group D steppers top out around 9.82 N-m (roughly 1390 oz-in) in the MX Series [S2][S6]. A side-by-side trade is below.
Comparison: NFPA 496 purged stepper vs. UL 674 flameproof stepper
On certification scope, NFPA 496 purge systems can be designed to meet Class I, II, and III, while UL 674 flameproof steppers are typically scoped to a single Class/Division/Group string on the nameplate [S1][S4]. On maximum torque, purge systems reach 400 to 1600 oz-in at the 4.2-inch frame, and UL 674 stock steppers reach 1.27 to 9.82 N-m (about 180 to 1390 oz-in) at NEMA 34/42 [S1][S2].
On ambient rating, purge systems track the motor insulation class (typically 130 to 180 degrees C winding limits with surface T-code controlled by the purge controller), whereas UL 674 explosion-proof motors are commonly rated to +40 degrees C (104 degrees F) ambient unless otherwise marked [S7]. On install complexity, the purge path needs a clean dry-air or nitrogen supply, a purge controller, a differential pressure switch, and a temperature set-point alarm; the flameproof path needs only approved conduit and seals [S1]. On field service, the purge stack can be re-validated on site, while flameproof joints, flame paths, and cable entries are inspected against the certification drawing. Engineers designing a hazardous-area control station typically pair a purged stepper with remote I/O in the safe area, while a flameproof stepper is more common in skid-mounted packages where space and utilities are limited.
T-code, surface temperature, and ambient ceiling
Surface temperature is the second gating constraint after Class/Group, expressed as a T-code that must stay below 80 percent of the auto-ignition temperature of the surrounding gas or dust [S4]. Common T-codes on explosion-proof steppers include T3 (200 degrees C), T4 (135 degrees C), and on dust lines T130 degrees C, all chosen so the housing never reaches the auto-ignition point even under overload or when insulated by a dust layer [S2][S4].
Most explosion-proof motors carry a maximum ambient of +40 degrees C (104 degrees F) unless the nameplate states otherwise, which is the baseline for hazardous-area builds in chemical and refinery service [S7]. For dust environments, the same motor often needs a higher T-code margin because the dust layer acts as insulation; the AKME dust marking "IIIC T130 degrees C Dc" illustrates the extra headroom a Zone 22 dust rating demands over a T4 gas rating [S2]. Specifying a Group D stepper with a T4 code in a propane-blending room is the typical safe choice; a T3 code on the same motor would be valid but warmer-running.
Frame size, torque, and speed envelope by product line
Flameproof stepper stock from Kollmorgen centers on the MX Series, NEMA 34 (MX9) and NEMA 42 (MX11), UL File E120721 and E32246 respectively, Class 1 Divisions 1 and 2 Group D, 1.27 to 9.82 N-m torque, up to 240 VAC input, and up to 3000 rpm [S2][S6]. For higher torque, the same vendor's Goldline EB/EBH brushless servo family extends the explosion-proof envelope to 0.84 to 158 N-m, up to 480 VAC, and up to 7500 rpm in the same Class 1 Division 1 Groups C and D certification envelope [S2].
Where the motion profile is fixed-speed constant-load and the certification is the bottleneck, the AC Synchronous X Series (NEMA 42 and 66, 1.77 to 10.59 N-m, 60/72 rpm) and the PMDC EP Series (NEMA 56C, 1.02 to 3.05 N-m at 1750 rpm) plug in without a separate drive/amplifier [S2]. Purged-and-pressurized PT steppers from Empire Magnetics run a different scale: from 13 oz-in (1.7-inch size) to 1600 oz-in (4.2-inch frame), with 80 to 700 W power points [S1]. The choice between a NEMA 34 flameproof stepper and a 3.4-inch purge stepper is usually decided by certification scope and available utilities, not by torque alone.
Limitations, failure modes, and selection pitfalls
Explosion-proof does not mean hazard-free: the motor reduces ignition risk, but proper installation, periodic inspection of flame paths, and re-validation of purge pressure and purge delay remain mandatory [S5]. A common pitfall is treating a TEFC or weatherproof motor as explosion-proof; these resist dust and moisture but are not certified to UL 674 or ATEX and are not legal in Division 1 service [S5].
Another pitfall is mis-grouping: a Group D motor is valid for propane and most refinery hydrocarbons but not for hydrogen (Group B) or acetylene (Group A), which carry lower minimum ignition energy [S4]. A third pitfall is ambient creep: a motor rated to +40 degrees C will trip its T-code margin in an unventilated cabinet in a hot climate, even if the electrical spec is otherwise right [S7]. Finally, note that an Ex d stepper with a stated T3 code still has to keep the cable entries and conduit seals at the same T-code, or the system marking collapses; specifying the motor without specifying the explosion-proof button stations and conduit seals is a common spec gap.
Applicable standards and certification file references
UL 674 is the US standard for explosion-proof motors; CSA is the Canadian equivalent; ATEX 2014/34/EU plus the IECEx scheme cover Europe and most international jurisdictions [S2][S4]. NFPA 496 covers purged and pressurized enclosures for electrical equipment in hazardous locations, and the NEC (NFPA 70) provides the matching installation rules [S1]. For dust environments, the IEC 60079-31 series (Ex tc) and the NEC Article 500/506 class/zone rules align the dust-side markings [S2].
Representative certification strings for stock stepper and servo motors in 2026: Kollmorgen MX9/MX11 stepper UL File E120721 / E32246 Class 1 Divisions 1 and 2 Group D; Goldline EB/EBH UL File E120721 or ATEX ITS12ATEX17548X Ex d IIB T3 Gb; AKME ATEX TPS 25 ATEX 124440 0005 X for Zone 2 gas and Zone 22 dust [S2]. For purge steppers, NFPA 496 Type X or Type Y is the standard reference, and the purge controller, differential pressure switch, and temperature switch are the named components on the loop drawing [S1].
Trackable signals to watch next: any new UL 674 revision aligning with IEC 60079-1 on flame path length, any expansion of NEMA 34/42 explosion-proof stepper torque envelopes above 10 N-m, and broader ATEX Zone 1 stock for steppers in the under-100 W range. Engineers sourcing a ex de GRP control station alongside a flameproof stepper should confirm the station's Ex e and Ex d component certs are file-compatible with the motor string before issuing a PO.
