The 2026 Mfrbee export listing for the HS-2022 impact drill shows a 13 mm chuck, 0–3000 rpm / 0–1100 rpm two-speed no-load range, 50/60 Hz mains and 13 mm maximum drilling diameter, packed in a colour box at a 500-piece MOQ [S1]. A second Mfrbee SKU in the same window quotes 230 V, 1050 W, 0–1140/0–3000 min⁻¹ with 13 mm steel and 16 mm concrete capacity at 16.5 kg per 5-piece export carton [S2]. Those two data points set the floor and the ceiling for what "impact drill" means in a 2026 B2B RFQ.
Intop's 800 W impact drill ships in the same MOQ band (500 pieces, Ningbo port) and the same carton-based export pack, signalling that 800 W is the de-facto entry tier for the Chinese-OEM impact-drill market in 2026 [S6]. On the cordless side, the Ningbo 21 V platform quotes a 10 mm keyless chuck, 16 N·m maximum torque and a 16+1 torque-collar with fast charger, listed on the Made-in-China supplier index [S3]. A separate Made-in-China 2026 launch line lists 10 mm-spec impact driver drills at US$11.02–12 per piece FOB at 50-piece MOQ — the price floor for low-voltage units in the current catalog [S4]. For the wider tool-class context, see the angle grinder vs demolition hammer comparison, which separates impact-drill duty from rotary-hammer duty.
Define "Impact Drill" Before You Spec
An impact drill in the 2026 export catalog is a single-chuck drill-driver whose gearbox adds an axial hammer action for masonry work — not a rotary hammer. The HS-2022 SKU explicitly classifies as a Core Drill with impact mode, 13 mm max drill diameter, 50/60 Hz universal motor and 0–3000 rpm top no-load speed [S1]. The 1050 W 230 V SKU keeps the same 13 mm chuck ceiling but bumps concrete capacity to 16 mm, the standard tell that the impact mechanism (not raw power) drives the masonry rating [S2].
Cordless units diverge structurally: a 21 V, 10 mm chuck, 16 N·m class drill with a 16+1 mechanical clutch is a driver-first impact drill, not a hammer-first rotary hammer [S3]. If the bit shank is 10 mm and the concrete rating is not published, treat it as a wood/steel driver with light masonry assist only. The same chuck / concrete-rating gate is explained in the rotary hammer buying guide 2026, where SDS-Plus shanks and a third hammer mode are the differentiators.
Selection Criteria That Actually Move the Quote
Four specifications separate one impact-drill SKU from another in 2026: chuck size, input wattage (or platform voltage for cordless), no-load speed band, and published masonry capacity. The HS-2022 hits 13 mm / 0–3000 rpm / unspecified wattage / 13 mm max [S1], while the 1050 W SKU hits 13 mm / 0–3000 rpm / 1050 W / 16 mm concrete [S2]. The 800 W Intop sits below both on wattage but uses the same 500-piece MOQ and Ningbo port flow [S6], so wattage is the price lever, not the chuck ceiling.
Cordless: 21 V platform, 10 mm chuck, 16 N·m torque, 16+1 clutch and a fast charger in the carton — that is the complete data sheet on the Made-in-China Ningbo supplier page [S3]. Below that, the US$11.02–12 tier compresses the BOM by dropping to a 10 mm ball-bearing structure and 50-piece MOQ [S4]. The criterion is not "is it cordless" but "what chuck and what clutch positions" — a 10 mm / 16+1 cordless unit cannot be cross-quoted against a 13 mm / 1050 W corded unit on a concrete job.
Corded 230 V vs 21 V Cordless: Who Each Is For
The 230 V corded class (800–1050 W, 13 mm chuck, 0–1100 / 0–3000 rpm two-speed) is for trades that drill masonry, brick and structural steel on site where a generator or mains outlet is available — the 16 mm concrete rating on the 1050 W SKU is the use-case anchor [S2]. The 800 W Intop is the lighter version for shop fit-out and intermittent masonry, not for daily concrete production [S6].
The 21 V, 10 mm, 16 N·m cordless class is for assembly, furniture fitting, light steel framing and overhead drilling where cord drag is the real cost [S3]. The price-floor 10 mm ball-bearing units at US$11.02–12 are retail / promotional SKUs, not contractor daily-use tools [S4]. If a project needs 16 mm concrete production, a 21 V / 10 mm cordless will not get there — specify the 230 V / 13 mm / 1050 W class instead [S2]. For battery-platform cost modelling, the same MOQ-versus-rail logic that runs in our roller conveyor buying guide (size the line, then the unit) applies here: size the chuck and duty cycle first, the battery or cord second.
Wattage, RPM and Concrete Rating — the Live Comparison
Stacking the four reference SKUs side-by-side against chuck, wattage, top no-load rpm and concrete rating: HS-2022 hits 13 mm / n.a. W / 3000 rpm / 13 mm [S1]; the 1050 W Mfrbee SKU hits 13 mm / 1050 W / 3000 rpm / 16 mm [S2]; Intop 800 W sits at 13 mm / 800 W / n.a. rpm published / n.a. concrete published [S6]; and the 21 V Ningbo cordless sits at 10 mm / 21 V platform / n.a. rpm / n.a. concrete, 16 N·m torque [S3]. The two decision gates are chuck size (10 mm vs 13 mm) and concrete rating published (13–16 mm vs not published). Wattage is a price/specifier handle, not a capability gate — the 800 W and 1050 W units share the same 13 mm chuck and MOQ structure [S2][S6].
MOQ and packing also follow the wattage tier: 500-piece MOQ, colour-box unit pack, Ningbo port for both 800 W and 1050 W corded SKUs [S1][S2][S6]; 50-piece MOQ for the price-floor 10 mm ball-bearing cordless SKU [S4]. Order quantity therefore scales with build value, not with chuck size — a 13 mm 800 W unit and a 13 mm 1050 W unit can sit on the same PO.
Limitations, Failure Modes and What the Catalog Will Not Tell You
Three limitations show up directly in the published data. First, the 21 V / 10 mm / 16 N·m cordless platform does not publish a concrete rating at all [S3] — treating it as a masonry tool is a spec error. Second, the HS-2022 lists "Core Drill" as the drill type alongside its impact rating [S1], so a buyer who reads the spec literally will expect a core-drill duty cycle that a 13 mm keyless-chuck impact drill cannot deliver; treat "Core Drill" as a category tag, not a capability claim. Third, the 1050 W SKU publishes a 16 mm concrete figure but no impact energy in joules [S2] — for production masonry, cross-check against the SDS-Plus rotary-hammer class covered in the rotary hammer buying guide 2026, where impact energy is published.
Two further failure modes are typical but not in the spec sheet: gearbox heat soak on the 0–3000 rpm top gear during continuous steel work, and chuck slip on the 10 mm cordless platform once bit shanks wear past 9.5 mm. Neither is mitigated by wattage — both are mitigated by duty-cycle derating (drop a gear, change the bit). The 16+1 clutch on the 21 V Ningbo unit is the published protection for the second failure mode [S3].
Sourcing, Standards and Carton-Level Cost
All four reference SKUs originate from Zhejiang / Ningbo, China, with 500-piece MOQ for the corded 13 mm class and 50-piece MOQ for the entry cordless class [S1][S2][S4][S6]. The 1050 W SKU quotes 48 × 37.5 × 27.5 cm outer carton holding 5 pieces at 16.5 kg total — a 3.3 kg per-unit shipping weight that drives the air/sea break-even [S2]. Payment terms on the corded class are L/C or T/T, FOB Ningbo, matching standard 2026 B2B tooling-quote practice [S1][S2][S6].
No supplier in the 2026 sample publishes IEC/EN 60745-1 or IEC/EN 60745-2-1 conformity on the public SKU page; if CE / UKCA / GCC conformity is required for the destination market, request the test report at the RFQ stage — the 230 V / 50 Hz universal-motor rating is the only electrical spec universally published [S1][S2]. For total landed-cost modelling on adjacent power-tool categories, see the angle grinder price 2026 guide, which uses the same FOB-Ningbo carton math.
Next signal to track: the 21 V cordless supplier index on Made-in-China still shows 10 mm as the dominant chuck ceiling with no 13 mm cordless SKUs in the 2026-04 launch feed [S4] — if a 13 mm cordless impact drill enters the catalog at the same 50–500-piece MOQ band, the corded 13 mm / 800 W tier will reprice first. Watch the 2026-Q3 launch feed on the same supplier index for the SKU shift.
