Pneumatic conveying blowers for industrial bulk-solids transport are normally specified in the 5 to 100 m3/min airflow band at discharge pressures from 0.4 bar(g) for simple dilute-phase lines up to roughly 2.5 bar(g) for longer or dense-phase routes, with PD Roots blowers covering the lower half of that pressure range and oil-flooded screw compressors covering the upper half [S1][S4][S10].
The two numbers engineers must get right are volumetric flow in m3/min (or ICFM at inlet conditions) and discharge pressure in bar(g); the blower rating is the simultaneous point on a Q-H curve, not a single maximum, and any miss translates directly into either line plugging below pickup velocity or wasted power and pipe erosion above it [S1][S4].
Required inputs that drive a sizing calculation
A pneumatic conveying calculator combines the bulk material identity, feed rate in kg/min or lb/min, bulk density, pipe internal diameter, horizontal run, vertical lift, number of elbows, ambient air temperature, and site elevation above sea level to estimate both the airflow in ICFM and the system pressure in bar(g) [S1]. The cross-sectional area of the pipe multiplied by the target conveying velocity in m/s gives the first-cut volumetric flow, and the calculator then layers in friction loss per metre, equivalent length of fittings, and the static head of the vertical lift to arrive at the discharge pressure the blower must overcome [S1].
Elevation matters because atmospheric pressure drops with altitude, lowering air density and forcing the blower to deliver a higher inlet cubic feet per minute to achieve the same mass flow at the discharge; for a site at 1000 m the correction is already a few percent and climbs to roughly 12 percent at 2000 m, which is why PD blower ratings are normalised to standard conditions of 20 deg C, 14.7 psia, 36 percent relative humidity, and 0.075 lb/ft3 [S4]. Bulk density, particle size distribution, shape, and moisture content all sit on top of the geometric inputs because they set the pickup and suspension velocities; ignoring tackiness in a spice or starch line is the most common root cause of valve smearing and line plug events on commissioned systems [S2].
Conveying velocity sets the m3/min target
Dilute-phase conveying requires a minimum air velocity of about 15 m/s to keep the material suspended through the pipeline, and the typical design window for fine powders and granules in this regime runs from 700 to 1000 m/min (roughly 12 to 17 m/s), with very high attrition above that band and line-plugging risk below it [S5][S9]. A worked example in the engineering literature holds 60 m3/min of free air available against that 15 m/s minimum pickup velocity, which immediately fixes the pipe cross-section for a given line diameter [S5].
The relationship is direct: CFM (or m3/min) equals pipe cross-sectional area in ft2 (or m2) times the conveying velocity in ft/min (or m/min), and the same formula lets the engineer back-solve the pipe diameter once a target flow and a suspension velocity have been agreed with the process group [S1]. For dense-phase service the instantaneous flow per cycle is computed from the hourly throughput divided by cycles per hour, so the blower still has to deliver the full cycle's worth of air in roughly half the cycle time when the system is pulsing, which is why dense-phase ratings often look oversized in steady-state terms but make sense when you watch the cycle clock [S7].
Pressure in bar(g): friction, lift, and phase selection
PD blowers are used extensively in dilute-phase applications where the bulk material is conveyed in suspension and the required pressure does not exceed 15 psig (about 1.03 bar(g)), which makes them the default air mover for plastic pellets, flour, and many chemical powders on runs under a few hundred metres [S4]. When the line gets longer, the vertical lift climbs, or the material requires dense-phase transport, the system pressure can rise into the 1.5 to 2.5 bar(g) band, and oil-flooded screw compressors typically replace or supplement the Roots unit because the volumetric efficiency of a PD blower collapses as the pressure ratio climbs [S10].
The pressure-side of the calculation is a sum of three terms: distributed friction loss through the pipe (a function of velocity squared, pipe roughness, and gas density), concentrated loss at each elbow and fitting (counted as equivalent length), and the static head from vertical lift, which for a 20 m lift is roughly 0.2 bar of working pressure on top of the friction budget before any margin is added. Up-sizing the blower to the next frame, rather than running it flat out at its published rating, widens the flow band at lower pressure, reduces heat rise across the unit, and trims bearing wear over the service life of the machine [S8]. PD blowers are limited in how they can be capacity-controlled because they are cooled by the mass flow passing through them: throttling the discharge to choke the flow causes overheating, so usable control methods are staging multiple units, running a VFD on the motor within a defined speed window, fitting a blow-off valve on the discharge, or changing the sheave ratio on a belt drive [S4].
Dilute phase versus dense phase: a criteria comparison
For non-abrasive pellets and granules on short, low-lift lines, dilute-phase Roots blower service at 0.4 to 1.0 bar(g) and 15 to 25 m/s is the lowest-cost route, with the trade-off being higher pipe-wall wear and product attrition from particle-to-particle collision at the high end of the velocity band [S2][S9]. For abrasive minerals, glass batch, and fly ash, the design goal shifts to surviving the conveying, which means pushing the velocity down to the lowest speed that still moves the material and accepting the larger pipe diameter and higher flow that implies [S2].
For cohesive or fragile products (specialty chemicals, spices, pharmaceutical powders) and for longer runs above roughly 500 m, dense-phase conveying uses a higher solids-to-air ratio at lower velocity, which can drop the airflow requirement per tonne conveyed but pushes the pressure into the 1.5 to 4 bar(g) band and requires pulse-driven blowers or compressor packages sized on the instantaneous cycle flow rather than the hourly average [S7]. On a per-line cost basis the screw-compressor option for a 2.5 bar, 40 m3/min duty pulls around 7.3 kW per m3/min for an 8-bar derated unit, while a higher-pressure compressor package climbs above that specific power as the pressure ratio increases [S10]. The selection matrix therefore has three decision criteria that line up cleanly: target pressure in bar(g), required flow in m3/min, and allowable conveying velocity, with material abrasiveness and pickup velocity sitting in front of all three as gating inputs [S1][S2][S9].
Limitations, failure modes, and the BVS check
The single most common commissioning failure on pneumatic conveying lines is line plugging where the dynamic air pressure reaches its minimum value, which by definition is the point furthest from the blower and almost always at a horizontal-to-vertical transition or just after a long-radius elbow [S4]. The second is over-heating of a PD blower caused by operating it against a throttled discharge or at very low mass flow, since the rotor clearances are tight and the impellers rely on through-flow for convective cooling [S4]. The third is pipe-wall erosion on abrasive service, which is a function of velocity to the third power and accelerates sharply above the 1000 m/min mark [S9].
The vendor guidance in the published quick-sizing sheets is consistent on the mitigation: keep the velocity in the design band, upsize the blower one frame to give headroom, and run a BOV or VFD rather than a discharge damper for capacity control [S3][S4][S8]. For dense-phase service the equivalent guidance is to size the instantaneous cycle flow from the cycle time, not the hourly tonnage, and to verify the assumed pickup velocity in a conveying lab against the actual bulk density, particle size, and moisture of the lot that will run on the line [S3][S7].
Standards, sourcing, and the next verification step
Blower ratings are normally quoted to standard reference conditions of 20 deg C, 14.7 psia, 36 percent RH, and 0.075 lb/ft3 air density, and any site correction for altitude or temperature has to be applied on top of the published curve before comparing the operating point to a competitor's data [S4]. Capacity-control selection on a PD blower is restricted to VFD speed range, blow-off valve, sheave change, or staging parallel units, because discharge throttling trips the thermal limit of the rotors [S4]. For screw-compressor packages above roughly 2 bar(g) the practical specific power is around 7 kW per m3/min for an 8-bar derated unit on a 2.5 bar, 40 m3/min duty, which is a useful sanity check against vendor quotes [S10].
