A bench scale specified into an OEM control cabinet line must clear four evidence gates before ship: metrological (OIML R76 or equivalent), hazardous-area (ATEX 2014/34/EU or IECEx), EMC (EN 61326-1 industrial), and electrical integration (galvanic isolation, PE bonding, protocol conformance to the cabinet's PLC or MCC cabinet I/O).
The metrological gate is fixed by the legal-for-trade accuracy class, typically OIML R76 Class II or III, which defines the resolution step and the maximum number of verification intervals n. Industrial bench scales in this class commonly run 6,000 d to 35,000 d of resolution [S2][S4]. The hazardous-area gate is fixed by the cabinet's install zone, which dictates ATEX category (1, 2, 3) and gas/dust group. The EMC gate is fixed by the cabinet's intended operating environment, and the electrical-integration gate is fixed by the cabinet's I/O architecture, which the OEM must declare on the scale's datasheet.
Metrological evidence: OIML R76, accuracy class, and resolution
OIML R76 is the international recommendation that drives the test certificate issued by an OIML member state body, and it defines the relationship between the scale's capacity, readability, and accuracy class [S2]. Class II instruments are typically used for legal-for-trade applications where fine resolution is required, while Class III instruments are common for industrial process applications. The number of verification intervals, n, is the scale's capacity divided by the verification scale interval e, and it must fall within the limits set by R76 for the chosen class [S2].
Minebea Intec's Signum bench scale lists three resolution tiers on the same mechanical platform: the standard SG system reaches up to 35,000 d, the mechatronic SG system reaches up to 80,000 d or 150,000 d with electronic compensation, and the monolithic EMFC system reaches up to 350,000 d or 620,000 d with a built-in motorised calibration weight [S2]. Capacity on the Signum platform spans 0.6 kg to 65 kg, with readability from 0.001 g to 10 g depending on the model, and the supply comes in steel or stainless-steel variants [S2]. METTLER TOLEDO's ICS465k bench scale ships with 0.1 g readability as a high-resolution tabletop instrument [S6]. Rice Lake's bench-scale product line covers similar resolution tiers across its industrial range [S4].
Hazardous-area evidence: ATEX, IECEx, and zone-to-category mapping
ATEX 2014/34/EU and IECEx are the two parallel schemes for placing weighing equipment into explosive atmospheres, and a cabinet OEM that ships into both Europe and the rest of the world normally holds both [S2]. The scale's certificate of conformity must list the equipment group (II for surface industries), category (1, 2, or 3), gas group (IIA, IIB, IIC), dust group (IIIA, IIIB, IIIC), and temperature class (T1 to T6). The cabinet's install zone, not the scale's marketing brochure, dictates which category is acceptable: zone 0 requires category 1, zone 1 or zone 20 requires category 2, and zone 2 or zone 22 requires category 3.
The Signum datasheet lists ATEX, EAC, and OIML as the certifications carried by the platform, with Ex solutions available as a configured option rather than as standard [S2]. WEBOWT positions weighing indicators and controllers with explosion-proof process controllers in its product line, reflecting the same zone-coverage requirement that cabinet OEMs must verify on the supplier's certificate [S10]. A common audit failure is accepting a "factory Ex" label without a certificate number; the certificate number, the notified-body four-digit code, and the issued/revised date must all appear on the OEM's incoming-inspection record.
Electrical integration: protocol, isolation, and PE bonding
The scale-to-cabinet interface is normally RS-232, RS-485, USB, Ethernet, or a fieldbus protocol, and the chosen protocol must be declared on both the scale datasheet and the cabinet's I/O list [S9]. METTLER TOLEDO ships bench scales with a USB interface for connectivity and data collection in industrial weighing applications [S9]. The cabinet OEM must verify that the scale's serial protocol, default baud rate, and data frame match the PLC or access control module that reads it, and that the scale's ground stud is bonded to the cabinet PE bar with a conductor sized per the relevant wiring code.
Galvanic isolation between the scale's load-cell excitation and the cabinet's 24 VDC logic supply is required when the cabinet also powers solenoid valves, VFDs, or other switching loads, and the isolation rating (typically 500 V or 1500 V RMS for one minute) must be on the scale's datasheet. The power input to the scale indicator must be fused or current-limited at the cabinet's 24 VDC distribution block, and the indicator's own overcurrent protection is a secondary, not primary, means. For control cable routing, the scale's load-cell cable must be run in a dedicated conduit or tray separated from VFD output cables, with the shield grounded at the cabinet end only, to keep common-mode noise out of the millivolt-level load-cell signal.
EMC and environmental: IP rating, operating temperature, and verification
EMC compliance to EN 61326-1 for industrial environments is the baseline requirement for any weighing instrument integrated into an OEM cabinet that ships into the European market, and the declaration of conformity must list the specific test standard, not a generic "CE" mark. The scale's IP rating must match the cabinet's IP rating if the scale is mounted through the cabinet wall, and the Signum datasheet offers IP43 or IP65 protection depending on the configured variant [S2]. Operating temperature on industrial bench scales typically runs 0 to 40 °C for the regulated class, and the cabinet OEM must verify that the scale's operating range covers the cabinet's worst-case internal temperature, not just the ambient.
A practical comparison for the cabinet OEM runs along four axes: metrological class (OIML R76 Class II vs III), hazardous-area category (ATEX cat. 2 zone 1 vs cat. 3 zone 2), interface protocol (RS-232/USB vs Ethernet/PROFINET), and resolution tier (≤35,000 d vs ≥80,000 d) [S2][S9]. Class II with ATEX cat. 2 and Ethernet fits a legal-for-trade batching skid in a chemical plant; Class III with ATEX cat. 3 and USB fits a general-purpose weighing station in a food-packaging line. The wrong combination is the commonest audit finding: a Class III scale cannot be promoted to Class II by adding a higher-resolution indicator, because the load cell and the mechanical system set the class floor.
Documentation set the audit expects on file
The OEM's certification file for each cabinet build must contain the OIML R76 test certificate with the accuracy class and n max, the ATEX or IECEx certificate of conformity with the notified-body number, the EN 61326-1 EMC declaration, the scale's wiring and grounding diagram tied to the cabinet's PE bar, the PLC protocol conformance sheet, and the supplier's traceability record (serial number to certificate number) [S2]. A certificate is in scope only if the model code on the certificate matches the model code on the scale's nameplate, including any options that affect the certified configuration. Revisions to the certificate (issued, revised, superseded) must be tracked, and a scale shipped under a superseded certificate is a recurring finding in notified-body audits.
Two signals to track over the next planning cycle: the convergence of OIML R76 and IECEx certificate formats on machine-readable formats (currently PDF-only at most suppliers), and the move by several weighing OEMs to publish their ATEX and IECEx certificates on a public registry rather than behind a sales-login wall [S2][S10]. A practical next step for the cabinet OEM is to map its own I/O list to the scale's protocol datasheet and write the mapping into the cabinet's electrical drawing, not into a separate compatibility matrix, so that the protocol conformance check is part of the drawing review, not an afterthought.
